Linksys EC1000 Manual de usuario

A Division of Cisco Systems, Inc.

Model No.

WIRED

Gigabit ExpressCard Adapter

EC1000

User Guide

Gigabit ExpressCard Adapter

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco

rights reserved. Other brands and product names are trademarks or registered trademarks of their respective

holders.

How to Use this User Guide

The user guide to the Gigabit ExpressCard Adapter has been designed to make understanding networking with

the Gigabit ExpressCard Adapter easier than ever. Look for the following items when reading this User Guide:

In addition to these symbols, there are definitions for technical terms that are presented like this:

Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like

this:

Figure numbers and descriptions can also be found in the "List of Figures" section.

This exclamation point means there is a caution or

warning and is something that could damage your

property or the Gigabit ExpressCard Adapter.

word: definition.

This checkmark means there is a note of interest and

is something you should pay special attention to while

using the Gigabit ExpressCard Adapter.

This question mark provides you with a reminder about something

you might need to do while using the Gigabit ExpressCard Adapter.

Figure 0-1: Sample Figure Description

EC1000-UG-51123 KL

WARNING: This product contains chemicals, including lead, known

to the State of California to cause cancer, and birth defects or other

reproductive harm. Wash hands after handling.

Gigabit ExpressCard Adapter

Table of Contents

Chapter 1: Getting to Know and Connecting the Gigabit ExpressCard Adapter 1

The Front Panel 1

Chapter 2: Setup and Installation of the Gigabit ExpressCard Adapter 2

Overview 2

Setup and Driver Installation 2

Hardware Installation 4

Uninstalling the Driver 5

Appendix A: Troubleshooting 6

Appendix B: Glossary 8

Appendix C: Specifications 13

Appendix D: Regulatory Information 14

Appendix E: Warranty Information 20

Appendix F: Contact Information 21

Gigabit ExpressCard Adapter

List of Figures

Figure 1-1: Front Panel’s LEDs 1

Figure 1-2: Front Panel’s Ethernet Port 1

Figure 2-1: Driver Installation 2

Figure 2-2: Start the Installation 2

Figure 2-3: File Location 3

Figure 2-4: Select Folder 3

Figure 2-5: Setup Being Performed 4

Figure 2-6: Installation Complete 4

Figure 2-7: Uninstall Driver 5

Figure 2-8: Confirm Uninstall 5

Figure 2-9: Uninstall Complete 5

Chapter 1: Getting to Know and Connecting the Gigabit ExpressCard Adapter

The Front Panel

Gigabit ExpressCard Adapter

Chapter 1: Getting to Know and Connecting the Gigabit

ExpressCard Adapter

The Front Panel

The Adapter's LEDs, where information about network activity is displayed, and Ethernet port are located on the

front panel.

10 Orange. The 10 LED lights up when the Adapter is connected to a 10Mbps network.

100 Green. The 100 LED lights up when the Adapter is connected to a 100Mbps network.

1000 Blue. The 1000 LED lights up when the Adapter is connected to a Gigabit network.

Ethernet Port The Ethernet port connects to the Ethernet port on your network device, such as a router,

using an Ethernet cable.

Figure 1-1: Front Panel’s LEDs

Figure 1-2: Front Panel’s Ethernet Port

Chapter 2: Setup and Installation of the Gigabit ExpressCard Adapter

Overview

Gigabit ExpressCard Adapter

Chapter 2: Setup and Installation of the Gigabit ExpressCard

Adapter

Overview

This chapter will take you through all the steps necessary to set up, configure, and install the Adapter. The steps

are also available to use the Utility to uninstall the driver for the Adapter, if you should ever need to do so. After

you set up the Adapter with the Setup Utility, you will install the Adapter into your Notebook PC.

Setup Utility

1. Insert the Setup Utility CD into your PC's CD-ROM drive.

2. The Setup Utility's Welcome screen should appear on your monitor. If it does not, this means the Setup Utility

is not automatically running as it should. Start the Setup Utility manually by clicking the Start button,

selecting Run, and typing d:\autorun.exe (where "D" is your PC's CD-ROM drive).

Click the Install button to continue this Setup Utility and install the driver. Click the Uninstall tab and button

to uninstall the driver. Clicking the User Guide button opened this User Guide. To contact Linksys, click the

Setup and Driver Installation

1. If you haven’t already done so, click the Install button. The Welcome screen will appear. Click the Next button

to continue the installation.

Figure 2-1: Driver Installation

Figure 2-2: Start the Installation

IMPORTANT: Connecting the Adapter before instructed may result in a malfunctining Adapter.

Chapter 2: Setup and Installation of the Gigabit ExpressCard Adapter

Setup and Driver Installation

Gigabit ExpressCard Adapter

2. The Choose Destination Location screen will appear next. To install the driver in the default folder location,

click the Next button, or click the Browse button to choose a different destination location.

When installing the driver in a different folder, select a folder location from the screen that appears. Then,

click the Next button.

Figure 2-3: File Location

Figure 2-4: Select Folder

Chapter 2: Setup and Installation of the Gigabit ExpressCard Adapter

Hardware Installation

Gigabit ExpressCard Adapter

3. The driver files will be copied onto your PC.

4. This screen will appear when the installation is complete. Click Finish to finish the installation.

Click the Exit tab to exit the Utility.

The setup is complete.

Hardware Installation

1. Make sure that your Notebook PC is turned off.

2. Locate your PC’s ExpressCard slot (usually located on the side). Insert the pin end of the Adapter into the slot

with the LEDs facing up. Make sure that the Adapter seats firmly in place.

3. Connect an Ethernet cable to the Ethernet port on the Adapter, then connect the other end to the Ethernet port

on the switch or other networking device.

The setup and installation are complete.

Figure 2-5: Setup Being Performed

Figure 2-6: Installation Complete

Chapter 2: Setup and Installation of the Gigabit ExpressCard Adapter

Uninstalling the Driver

Gigabit ExpressCard Adapter

Uninstalling the Driver

This process is used to uninstall the driver from your computer if you should need to do so.

4. Click the Uninstall tab. The Welcome screen will appear. Click the Uninstall button to continue.

5. You will be asked to confirm that you want to uninstall the driver. Click OK to continue the process or click

Cancel if you do not wish to uninstall the Adapter.

6. This screen will appear when the Adapter is uninstalled. Click Finish to exit the screen.

Figure 2-7: Uninstall Driver

Figure 2-8: Confirm Uninstall

Figure 2-9: Uninstall Complete

Appendix A: Troubleshooting

Gigabit ExpressCard Adapter

Appendix A: Troubleshooting

This appendix provides solutions to problems that may occur during the installation and operation of this product.

Read the description below to solve your problems. If you can't find an answer here, check the Linksys website at

www.linksys.com.

1. Windows doesn't detect new hardware with the Adapter hardware connected, or it continues to

detect the adapter each time I restart the PC.

• You might not have correctly or securely installed the adapter into your computer. Check that the adapter

is securely inserted into the appropriate ExpressCard slot.

• Refer to the PC’s User Guide.

2. Windows can't locate the driver for the Adapter

• You may have inserted the wrong Driver CD into your PCs CD-Rom drive.

• The Driver CD may be defective or files may be missing, or you may be pointing Windows to the wrong

drive. Ensure that the driver CD includes the files “yk51x86.inf” and “yk51x86. sys”.

3. The Windows Logon screen doesn't appear after restarting the computer (Windows 98SE).

• Click on Start, then Log Off. Log back in. If this doesn't solve the problem, your PC’s manufacturer may

have disabled Windows' networking. Contact your computer's manufacturer for help. If using Windows

2000, refer to your Microsoft documentation.

4. On the Access Control Tab, User Level Access is selected, but Shared Level Access is grayed out and

not accessible (Windows 98SE).

• You previously had your primary network logon set to Client for NetWare Networks. On the Configuration

tab of the Network Properties window, ensure that your primary network logon is set to Client for

Microsoft Networks.

• Your personal web server PC or Microsoft Front Page may require you to choose a user level for security

reasons.

5. In Network Neighborhood I can see myself but no other computers.

• Make sure that the cables are connected correctly. Make sure you are getting Link or Activity lights on

both the Adapter and your switch or router if you are using one. Try changing to a new cable that you

know is working.

• Make sure that the other PC is turned on.

• Enable UPnP in Windows if your OS supports it.
