Section - C8 - 302B
Form 403987
JAN - 2007
Models 85660, 85661, 85662,
85663, 85664 & 85665©
ELECTRIC VENT VALVE ASSEMBLIES
For use with Electric FlowMaster™ Pumps on
Drum Covers 85474 (120 lb.) and 85475 (400 lb.)
1/2 NPTF
Lube Outlet
2-way normally open solenoid valve
to be wired in parallel with motor on
Electric FlowMaster™ Pump (See Pump
Manual for Wiring Diagram)
1/4 NPTF
Model Power Drum
Source Size
85660 230 VAC 120 lb.
85661 230 VAC 400 lb.
85662 120 VAC 120 lb.
85663 120 VAC 400 lb.
85664 24 VDC 120 lb.
85665 24 VDC 400 lb.
© Indicates change
Model Chart
Page Number - 2 Form 403987
Models 85660, 85661, 85662, 85663, 85664 & 85665
ELECTRIC VENT VALVE ASSEMBLIES
1
2
3
4
5
6
7
89
10
11
12
13
14 13
15 16
17
18
20
21
ASSEMBLY INSTRUCTIONS
1) Fasten pump to drum cover.
2) Assemble Adapter (Item 8), Check Assembly (Item
9) and Adapter Union (Item 10) together. Fasten
assembly into pump outlet.
3) Assemble Adapter (Item 11), Tee (Item 12), Elbow
(Item 18) and two Adapters (Item 13) to Solenoid
Valve (Item 14). Position Tee (Item 12) and Elbow
(Item 18) as shown in illustration.
4) Assemble, but do not tighten, Bracket (Item 17)
to drum cover with Hex Head Screws (Item 15),
Lockwashers (Item 20) and Hex Nuts (Item 21).
5) Assemble Solenoid Valve subassembly to pump by
connecting Adapter (Item 11) to Adapter Union (Item
10) hand tight.
6) Hand tighten Hex Flange Screws (Item 16) to fasten
Solenoid Valve (Item 14) to Bracket (Item 17).
7) Align Bracket (Item 17) and Solenoid Valve (Item
14) and then securely fasten Hex Flange Screws
(Item 16), Adapter Union (Item 10) and Hex Head
Screws (Item 15).
8) Assemble Nut (Item 6) and Gasket (Item 5) to Vent
Tube (Item 7). Insert Vent Tube (Item 7) through
drum cover and secure with Vent Fitting (Item 3).
Align Vent Fitting (Item 3) as shown in illustration
and tighten Nut (Item 6) securely against bottom of
drum cover.
9) Assemble Safety Unloader (Item 1) into pump outlet.
Align as shown in illustration.
10) Assemble Hose Assembly (Item 2) to Safety
Unloader (item 1) and to Vent Fitting (Item 3).
11) Assemble Hose Assembly (Item 4) to Elbow (Item
18) and to Vent Fitting (Item 3).
MODELS 85660, 85662 & 85664
for 120 Lb. Drums
Page Number - 3
Models 85660, 85661, 85662, 85663, 85664 & 85665
ELECTRIC VENT VALVE ASSEMBLIES
Form 403987
ASSEMBLY INSTRUCTIONS
1) Fasten pump to drum cover.
2) Assemble Adapter (Item 8), Check Assembly (Item
9) and Adapter Union (Item 10) together. Fasten
assembly into pump outlet.
3) Assemble Adapter (Item 11), Tee (Item 12), Elbow
(Item 18) and two Adapters (Item 13) to Solenoid
Valve (Item 14). Position Tee (Item 12) and Elbow
(Item 18) as shown in illustration.
4) Assemble, but do not tighten, Bracket (Item 17) to
drum cover with Hex Head Screws (Item 15), Spacers
(Item 19), Lockwashers (Item 20) and Hex Nuts (Item
21). Place Spacers (Item 19) between Bracket (Item
17) and drum cover.
5) Assemble Solenoid Valve subassembly to pump by
connecting Adapter (Item 11) to Adapter Union (Item
10) hand tight.
6) Hand tighten Hex Flange Screws (Item 16) to fasten
Solenoid Valve (Item 14) to Bracket (Item 17).
7) Align Bracket (Item 17) and Solenoid Valve (Item 14)
and then securely fasten Hex Flange Screws (Item
16), Adapter Union (Item 10) and Hex Head Screws
(Item 15).
8) Assemble Nut (Item 6) and Gasket (Item 5) to Vent
Tube (Item 7). Insert Vent Tube (Item 7) through drum
cover and secure with Vent Fitting (Item 3). Align Vent
Fitting (Item 3) as shown in illustration and tighten Nut
(Item 6) securely against bottom of drum cover.
9) Assemble Safety Unloader (Item 1) into pump outlet.
Align as shown in illustration.
10) Assemble Hose Assembly (Item 2) to Safety Unloader
(item 1) and to Vent Fitting (Item 3).
11) Assemble Hose Assembly (Item 4) to Elbow (Item 18)
and to Vent Fitting (Item 3).
1
2
3
4
5
6
7
89
10
11
12
15 16
17
18
19
20
21
MODELS 85661, 85663 & 85665©
for 400 Lb. Drums
© Indicates change
Page Number - 4 Form 403987
Models 85660, 85661, 85662, 85663, 85664 & 85665
ELECTRIC VENT VALVE ASSEMBLIES
Americas:
One Lincoln Way
St. Louis, MO 63120-1578
USA
Phone +1.314.679.4200
Fax +1.800.424.5359
Europe/Africa:
Heinrich-Hertz-Str 2-8
D-69183 Walldorf
Germany
Phone +49.6227.33.0
Fax +49.6227.33.259
© Copyright 2007
Printed in USA
Web site:
www.lincolnindustrial.com
Service Parts
Item Description Qty. Part No.
No.
1 Safety Unloader 1 272722
2 Hose Assembly 1 272711
3 Vent Fitting 1 272717
4 Hose Assembly 1 270726
5 Gasket 1 31010
6 Nut 1 12538
7 Vent Tube 1 See Below
8 Adapter 1 12213
9 Check Assembly 1 81938
10 Adapter Union 1 66645
11 Adapter 1 14612
12 Tee 1 272719
13 Adapter 2 272720
14 Solenoid Valve 1 See Below
15 Hex Head Screw (5/16-18 x 1-1/8) 2 271620
16 Hex Flange Screw (M6 x 1 x 12) 4 272718
17 Mounting Bracket 1 272716
18 Elbow 1 12134
19 Spacer (used in 400 lb. kits only) 2 271622
20 Lockwasher (5/16) 2 66246
21 Nut (5/16-18) 2 51026
© Indicates change
Asia/Pacific:
51 Changi Business Park
Central 2
#09-06 The Signature
Singapore 486066
Phone +65.6588.0188
Fax +65.6588.3438
Model Power Drum Vent Pipe Solenoid Valve
Source Size Item No. 7 Item No. 14
85660 230 VAC 120 lb. 67290 525-32084-1
85661 230 VAC 400 lb. 67241 525-32084-1
85662 120 VAC 120 lb. 67290 525-32098-1
85663 120 VAC 400 lb. 67241 525-32098-1
85664 24 VDC 120 lb. 67290 274899
85665© 24 VDC 400 lb. 67241 274899
