Lilliput BM230 Manual de usuario
User Guide
1
IMPORTANT SAFETY INSTRUCTIONS
The device has been tested for conformance to safety
regulations and requirements, and has been certified for
international use. However, like all electronic equipment, the
device should be used with care. Please read and follow the
safety instructions to protect yourself from possible injury and to
minimize the risk of damage to the unit.
Please do not place the display screen towards the ground to avoid
scratching the LCD surface.
Please avoid heavy impact.
Please do not use chemical solutions to clean this product. Simply wipe
with a clean soft cloth to maintain the brightness of the surface.
Please do not block any vent hole.
Please follow the instructions and trouble-shooting to adjust the product.
Internal adjustments or repairs must be performed by a qualified
technician.
Please keep user guide for future reference.
Please unplug the power and remove the battery if long-term no-use, or
thunder weather.
FEATURES
Support multiple signal inputs 3G-SDI, HDMI, DVI and VGA.
Multiple View Display supports quad view split from different input singles
simultaneously.
2
Ultra HD 4K screens containing 8.3 million pixel (3840×2160), so the
resolution is four times that of Full HD.
3D LUT for Accurate Color Reproduction and Color space display
(Native/Rec.709/User1~User3).
Support to upload 3D LUT table via USB port.
Equip HDR function.
Image flip offers great convenience for user’s user to place the monitor
with various mounting methods under different conditions. Users can view
the monitor normally no matter what mounting angles.
Perfect size for both suitcase and rack mount.
Wireless HDMI function for optional.
Contents
1. PRODUCT DESCRIPTION .......................................................................... 3
2. SUN SHADE INSTALLATION ...................................................................... 8
3. MENU SETTING .......................................................................................... 9
4. ACCESSORIES ....................................................................................... 24
5. PARAMETERS ........................................................................................ 27
3
6. TROUBLE SHOOTING ............................................................................ 28
4
1. PRODUCT DESCRIPTION
Front
1. Speaker
2. SDI
Signal switch to SDI mode when light on.
3. HDMI 1 ~ 4
Signal switch to HDMI mode when light on.
4. DVI
Signal switch to DVI mode when light on.
5. VGA
Signal switch to VGA mode when light on.
5
6. MENU
Press to enter menu.
Press to enter option in the menu.
7. ◄
Select option in the menu.
Decrease the option value.
Before enter the menu, single press to activate volume, press again to
decrease the volume.
8. ►
Select option in the menu.
Increase the option value.
Before enter the menu, single press to activate volume, press again to
increase the volume.
9. EXIT
Back or exit.
10. F1~F4 User definable buttons
Default function options：
F1：Color Space F2：Display Mode
F3：Safety Marker F4：Aspect
（functions can be customized by long keep pressing any one of the
4 buttons）
11．Power indicating light (green light: working).
12．Earphone jack
6
Back
7
1. Handle (Only available for BM230/BM280)
2. VESA 75×75 & VESA 100×100 mounting port
3. USB port
4. TALLY port
5. VGA input port
6. DVI input port
7. HDMI input port×4。
HDMI 1 & HDMI 2 : HDMI2.0, support 4K 60Hz
HDMI 3 & HDMI 4: HDMI1.4, support to 4K 30Hz
NOTE: HDR is only available under HDMI 1 signal input.
8. Audio L/R
9. SDI input/output ports
10. DC IN (XLR) terminal
Connects the DC power supply to the monitor.
Pin number Signal
①
GND
②③
……...
8
④
+15V
11. Power switch
"II" is battery power, "o" is power off, "I" is DC power.
2. SUN SHADE INSTALLATION
1. Put the sun shade on the suitcase, and match the magnets on both sides.
2. As shown below after finished.
9
3. MENU SETTING
Please check whether the device is connected well or not.
3-1. F1~F4 user definable shortcut buttons
Long keep pressing any one of the 4 buttons for 3-5 seconds to activate
shortcut menu setting. Option selected will be highlighted as white. option
will be highlighted as yellow, unavailable option will be highlighted as gray.
Select option via "◄/►" buttons.
Then press "MENU" button to confirm to set as default option.
Shortcut functions can be customized to meet user’s needs as following:
NO. Shortcut Menu when long press any F shortcut button
1 Center Marker
2 Safety Marker
