Lightolier ProSpec 37109 Manual de usuario

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

ProSpec™120V/277V Track Lighting 37109

Page 1 of 2 Mini HID, Cylinder, 20W T4 CMH

Features

1. Track Attachment Fitting: Molded polycarbonate, rotates into track.

2. Locking Lever: Steel pin. Locks and detaches unit.

3. Track Adaptor Housing: Die-cast aluminum.

4. Ballast Housing: Extruded aluminum housing with die-cast aluminum

end caps.

5. Ballast: Electronic HID.

6. Tension Pivot Mounts: Allows for 350° horizontal and 180° vertical

rotation with tensioned mounts for controlled aim.

7. Lamp Housing: 0.04" (1.02mm) aluminum.

8. Lampholder: GU6.5 base ceramic body socket with nickel-plated contacts.

18 AWG leads with fiberglass outer sleeve (inside of housing).

9. Protective Glass: 0.13" (3.18mm) tempered glass.

10.Cover Housing: 0.04" (1.02mm) aluminum.

11. Knobs: Painted steel knurled knob secures cover to housing.

Accessories

Holder: 8195, holds one accessory

Diffusion/ Special Filters: AF25 series

Color Filters: ADF25 series

Accessories not requiring 8195 holder

AL35HC HEX Cell Louver

ALF35FR Frosted Softening Lens

Electrical

Electronic Ballast (Thermally Protected)

Input Voltage: 120V/277V Total Harmonic Distortion: <10%

Power Factor: >0.99 ANSI Code: M (C) 156

Input Power: 24W Do not use on dimming circuit

Max Input Current: 0.20A@120V/0.09A@277V

Finish

All painted finishes are baked powder or enamel.

Markings

UL, cUL

8 5/8

[219 mm]"

3 27/32

[97 mm]"

9 9/32

[235 mm]"

7 7/32

[183 mm]"

3 7/16

[87 mm]" 2 1/2

[64 mm]"

1 5/8

[41 mm]"

3 13/16

[97 mm]"

3 7/16

[ 87 mm]"

Catalog No. Finish Mounting Lamp Reflectors (Sold Separately)

37109WH

37109BK

White

Black

ProSpec®120V/277V

track systems only.

20W T4 CMH (M156) GU6.5 Base

Not included

24MHT4RS Clear spot reflector

24MHT4RNF Clear narrow flood reflector

24MHT4RF Clear flood reflector

24MHT4RSCCZ Champagne Bronze spot reflector

24MHT4RNFCCZ Champagne Bronze narrow flood reflector

24MHT4RFCCZ Champagne Bronze flood reflector

Job Information Type:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

ProSpec™120V/277V Track Lighting 37109

Page 2 of 2 Mini HID, Cylinder, 20W T4 CMH

8558 9000

GE CMH20T/GU6.5

14°

Lamp

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

Aiming Angle: 0° 30° Horizontal 30° Vertical 45° Vertical

L Beam length DDistance

W Beam Width AAiming Angle

CDistance to center beam FC Footcandles

Land W are the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.

Lamp data shown is typical. Consult lamp manu-

facturers for availability and performance.

CBCP = Center Beam Candle Power.

D FC L W D C FC L W D C FC L W D C FC L W

10' 5.8' 115 2.3' 2.0'

12' 6.9' 80 2.8' 2.4'

14' 8.1' 59 3.3' 2.8'

16' 9.2' 45 3.7' 3.2'

5' 5.0' 251 1.8' 1.2'

6' 6.0' 175 2.1' 1.5'

7' 7.0' 128 2.5' 1.7'

8' 8.0' 98 2.8' 2.0'

4' 6.9' 139 2.9' 1.4'

5' 8.7' 89 3.6' 1.7'

6' 10.4' 62 4.3' 2.1'

7' 12.1' 45 5.0' 2.4'

10' 178 1.7' 1.7'

12' 123 2.1' 2.1'

14' 91 2.4' 2.4'

16' 69 2.8' 2.8'

Note: For Champagne Bronze (CCZ), multiply FC values by 0.64. CCZ Champagne Bronze reector "warms" the beam to 2700K.

D FC L W D C FC L W D C FC L W D C FC L W

10' 5.8' 115 2.3' 2.0'

12' 6.9' 80 2.8' 2.4'

14' 8.1' 59 3.3' 2.8'

16' 9.2' 45 3.7' 3.2'

5' 5.0' 251 1.8' 1.2'

6' 6.0' 175 2.1' 1.5'

7' 7.0' 128 2.5' 1.7'

8' 8.0' 98 2.8' 2.0'

4' 6.9' 139 2.9' 1.4'

5' 8.7' 89 3.6' 1.7'

6' 10.4' 62 4.3' 2.1'

7' 12.1' 45 5.0' 2.4'

10' 178 1.7' 1.7'

12' 123 2.1' 2.1'

14' 91 2.4' 2.4'

16' 69 2.8' 2.8'
