Lightolier Lytespan 6280 Manual de usuario

Lytespan®Track Li htin System 6280

Pa e 1 of 2 Par Rin Lytespot®

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Company www.li htolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the ri ht to chan e details of desi n, materials and ﬁnish.

© 2002 Genlyte Thomas Group LLC (Li htolier Division) • A0902

General Description

Minimal, functional form with cleanly detailed yoke and attractive Iampholder,

uses 150W PAR-38 side pron lamp for maximum compactness. Permanently-

tensioned trunion mountin allows Lytespot to remain ﬁxed at any an le. Unit

adjusts horizontally up to 350°, vertically up to 90°. Re ressed sprin clips

retain ﬁlters, spread lenses, louver and adjustable ”barn door”. Wall Washer

Accessory may be used to provide smooth, medium to hi h intensity wash of

li ht without “scallops”, snap onto ﬁxture housin for easy assemblin .

Finish

All painted ﬁnishes baked enamel.

Electrical

Porcelain medium side-pron base connector encased in socket boot. No. 18

braided SF-1 leads.

Labels

UL; C.S.A.; I.B.E.W.

Catalog No. Finishes Mo nting Lamps Accessories

6280 Matte White 150W PAR-38/3

6281 Matte Black

6487 Matte White

6488 Matte Black

4 3/4” Dia Series Color Filters, Heat Filter, Spread Lens, Louver

(see Li htolier Speciﬁcation Sheets AF, AF2AS, AL4CC, 7650).

All Lytespan Track

Systems

Wall Washer

Accessory

Lytespan®Track Li htin System 6280

Pa e 2 of 2 Par Rin Lytespot®

Lightolier a Genlyte Thomas Company www.li htolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the ri ht to chan e details of desi n, materials and ﬁnish.

© 2002 Genlyte Thomas Group LLC (Li htolier Division) • A0902

Job Information Type:

Lighting Data

For 120W PAR-3813 FL (Ener y Savin ), multiply F.C. above by 1.0. (L) and (W) remain the same.

(FC) is the initial footcandles at the center of the beam.

(L) and (W) are to the point that the candlepower drops to 50% of maximum
