LEGO® PORSCHE 911

#10295 LIGHT KIT

INSTALLATION GUIDE

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

Light My Bricks

LEGO® PORSCHE 911 #10295 LIGHT KIT

INSTALLATION GUIDE

Hi There!

We’re here to help you get started on the LEGO®

Porsche 911 (10295) Light Kit.

This PDF details the instructions for the LED light kit only.

If you run into any issues, please refer to the

troubleshoot-ing section towards the end of this guide.

Have fun and enjoy!

INSTALLATION GUIDE

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

PACKAGE CONTENTS 3

PACKAGE CONTENTS: LEGO PIECES:

4 x White 30cm Bit Lights

3 x White 15cm Bit Lights

2 x Warm White Large 30cm Bit Lights

2 x Warm White 30cm Headlight

1 x 6-Port Expansion Boards

1 x 8-Port Expansion Boards

2 x Adhesive Squares

1 x NC Push Board

1 x 15cm Connecting Cables

1 x 30cm Connecting Cables

1 x USB Power Cable

(Power Source not Included)

• 1 × Trans Clear Plate 2x2 w/ Rounded Bottom

• 1 x Trans Clear 1x1 Round Plate

• 1 × Dark Bluish Grey 1x2 Tile

• 1 × Black 2x6 Plate

• 2 × Black Brick 1x1 Modiﬁed w/ Stud on One Side

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

CONTENTS 4

Contents

Before You Begin 5

Instructions 8

Final Product 25

Troubleshooting 26

Contact 32

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 5

Before You Begin

Laying cables in between

and underneath bricks

Cables can ﬁt in between and underneath

LEGO® bricks, plates, and tiles providing

they are laid correctly between the

LEGO® studs. Do NOT forcefully join

LEGO® together around cables; instead

ensure they are laying comfortably in

between each stud.

CAUTION: Forcing LEGO® to connect over

a cable can result in damaging the cable

and light.

Connecting Cable

Connectors To Expansion

Boards

Take extra care when inserting connectors

to ports of Expansion Boards. Connectors

can be inserted only one way. With the

expansion board facing up, look for the

soldered “=” symbol on the left side of the

port. The connector side with the wires

exposed should be facing toward the

soldered “=” symbol as you insert into the

port. If a plug won’t ﬁt easily into a port

connector, do not force it.

Incorrectly inserting the connector can

can result in bent pins inside the port or

possible overheating of the expansion

board when connected.

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 6

Before You Begin

Connecting Cable

Connectors To Strip Lights

Take extra care when inserting connectors

to ports on the Strip Lights. Connectors

can be inserted only one way. With the

Strip Light facing up, ensure the side of

the connector with the wires exposed is

facing down. If a plug won’t ﬁt easily into

a port connector, don’t force it. Doing so

will damage the plug and the connector.

Connecting Micro Cable

Connectors To Micro

Expansion Board Ports

Take extra care when inserting the

micro connectors to micro ports of Micro

Expansion Boards. Connecting Micro Bit

Lights to Micro Expansion Boards is similar

to connecting lights and cables to Strip

Lights. With the expansion board facing

up, ensure the side of the connector with

the wires exposed is facing down. If a plug

won’t ﬁt easily into a port connector, do

not force it. Use your ﬁngernail to push the

plastic part of the connector to the micro

port.

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 7

Before You Begin

Installing Bit Lights Under

Lego® Bricks And Plates

When installing Bit Lights under LEGO®

pieces, ensure they are placed the correct

way up (Yellow LED component exposed).

You can either place them directly on top of

LEGO® studs or in between.

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 8

INSTRUCTIONS

To ensure a smooth installation of

your light kit, please read and follow

each step carefully. If you run into

any issues, please refer to the online

troubleshooting guide.

8INSINSTRUCTIONSTRUCTIONS

LEGEND:DISCONNECT DIRECTIONAL

LEGENDE:TRENNEN DIRECTIONAL

LÉGENDE:DÉCONNECTER DIRECTIONNEL

LEGGENDA: SCOLLEGARE

CONNECT / RECONNECT

VERNINDEN / WIEDERVERBINDEN

CONNECTER / RECONNECTER

CONNETTI / RICONNETTI

TURN / FLIP

WENDEN / KIPPEN

TOUR / INCLINAISON

ROTARE / INCLINARE DIREZIONALE

TWIST / BRAID

DREHEN / VERDREHEN

TORSION / TRESSER

TWIST / TRECCIA

POWER ON / TEST

EINSCHALTEN / TESTEN

POWER ON / TEST

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 9

Legend DISCONNECT CONNECT /

RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO PORSCHE 911 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 10

Legend DISCONNECT CONNECT /

RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

White 15cm Bit Light
