LG V-C9352WA Manual de usuario

VACUUM CLEANER

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE UNIT, READ THE

"SAFETY PRECAUTIONS" IN THIS MANUAL.

MODEL : V-C9352WA

V-C9363WA

V-C9364WAU

V-WA266ND

CONTENTS

-2-

SAFETY PRECAUTIONS. ...................................................................................3

CAUTIONS...........................................................................................................3

DESCRIPTION ....................................................................................................4

SPECIFICATIONS ...............................................................................................5

DISASSEMBLY................................................................................................5~8

TROUBLESHOOTING...................................................................................9~11

BLOCK DIAGRAM.............................................................................................12

SCHEMATIC DIAGRAM.....................................................................................12

EXPLODED VIEW .....................................................................................13~16

REPLACEMENT PARTS LIST ....................................................................17~18

APPENDIX.........................................................................................................19

SAFETY PRECAUTIONS

CAUTIONS

-3-

BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND

OBSERVE EACH POINT CAREFULLY.

BEFORE ATTEMPTING TO SERVICE OR ADJUST ANY PART OF THE VACUUM CLEANER, DISCONNECT

THE ELECTRICAL POWER SUPPLY CORD FROM THE WALL OUTLET.

1. Motor exchange

1) Separate the Body Cover and Body Base by

unfastening the screws.

2) Disconnect lead wires.

3) Remove the old motor and replace it with a new

one.

2. In case of exchanging other parts, refer

to the exploded view.

1. Empty the dust tank, when the dust thank is full.

1) If the dust thank is full, intake power will be

reduced.

2. Filter

1) The filter is composed of Air filter and Exhaust

filter.

2) Never use the vacuum cleaner without filters.

It may harm to the motor and cleaner does not

work properly.

3) After cleaning, separate the Air filter and clean it

using water and brush.

NOTE: Reuse of Air filter

• Never wash the filter in a washing machine or in a

dishwasher.

• Never use hot water for washing the filter.

• Reuse the filter after drying it completely in the

shade for a day.

• Do not dry near fire or direct sun ray.

3. Avoid suction such materials as:

1) Inflammable liquids such as benzene, alcohol or

solvents.

2) Burning objects such as cigarette butts or hot

ash.

3) Bulky objects such as vinyl, paper etc.

4) Sharp and hard objects as pins, needles, stones,

small toys etc.

4. Attachments

• Main spray nozzle: Shampoo cleaning for carpet

and floor.

• Window master: Shampoo cleaning for window.

• Small shampoo nozzle: Shampoo cleaning for

sofa and chair etc.

• Carpet/Floor nozzle: For cleaning wooden floor,

the room floor and carpet.

• Carpet master: For carpet cleaning

• Crevice tool: For cleaning any crevice, inside

corners window frames. (However,

do not use the crevice tool more than

20 minutes.)

• Dusting brush: For delicate vacuuming of fabrics

on the furniture, curtains, etc.

• Upholstery Nozzle: For vacuuming the dust on the

upholstery.

5. Close supervision is necessary when this

vacuum cleaner is used by or near children.

Children's cardlessness may cause damage to

the cleaner or injure persons.

6. Air exhausted from the vacuum cleaner is

normally warm.

But if extraordinarily hot air is exhausted, check

if the tube, hose or air filter is clogged or not.

7. Electric shock could occur if used outdoors or

on wet surfaces.

DESCRIPTION

-4-

Optional

Carpet Master Carpet/Floor Nozzle

Spray Nozzle

Frame Brush

Crevice Tool

Shampoo Bottle

Brush Dusting Brush

Upholstery Nozzle

Window Master

Small Shampoo Nozzle

Shampoo Button

Inlet Dust

Switch Button

Power Cord

Red Mark

Yellow Mark

Hose

Hose Handle Dust Tank

Clamp

Shampoo

Tank Cap

Spray Nozzle

Shampoo

Lever

Pipe

Cover

Shampoo Tank

Cord Reel Button

Handle

SPECIFICATIONS

-5-

• MODEL : REFER TO THE COVER PAGE

• POWER SOURCE : ON RATING PLATE

• POWER CONSUMPTION : ON RATING PLATE

• CAPACITY : WATER 5.0 , DRY 6.0

• CORD LENGTH : 6m

• HOSE LENGTH : 1.8m

• NET WEIGHT : 9.5Kg

• PACKING WEIGHT : 15Kg

• NET DIMENSION : 493 x 361 x 398 (W x D x H)mm

• PACKING DIMENSION : 565 x 385 x 565 (W x D x H)mm

• This specifications are subject to change according to

the buyer's request.

• ATTACHMENTS

F/HOSE ASSY.............................................................1EA

STAINLESS PIPE........................................................2EA

CARPET MASTER.......................................................1EA

CARPET/FLOOR NOZZLE..........................................1EA

WINDOW MASTER .....................................................1EA

SMALL SHAMPOO NOZZLE.......................................1EA

MAIN SPRAY NOZZLE................................................1EA

CREVICE TOOL ..........................................................1EA

DUSTING BRUSH .......................................................1EA

UPHOLSTERY NOZZLE..............................................1EA

SHAMPOO BOTTLE....................................................1EA

DISASSEMBLY

1. Open the Top Cover Assy.

1) Separate flexible hose assy. 2) Grasp clamps and open the Top Cover Assy by

lifting.

NOTE: Before attempting to service or adjust any part of the vacuum cleaner, disconnect the electrical power

supply cord from the wall outlet.

•Almost all the parts of this vacuum cleaner can be assembled with a screw driver and each connecting

component easily fits each other.

Disassemble one by one referring to the exploded view.

•If possible, don't disassemble except for the necessary parts. It is not necessary to disassemble the parts that

are not detailed in the exploded view.

-6-

3) Separate Dust Tank and Shampoo Tank.

2. Body Base Assy Replacement

1) Separate Exhaust Cover Assy.

2) Remove seven screws fastening the Body Cover

Assy on the Body Base Assy.

3) Separate Body Cover Assy by lifting.

Dust Tank

Shampoo Tank

-7-

3. Motor Assy Replacement

•Lift the motor assembly in direction of the arrow.

•Stripe off lead wires.

4. Cord Reel Assy Replacement

•Lift the Cord Reel Assy from the body base in

direction of the arrow after stripping off lead wires.

5. Pump Assy Replacement

1) Take out the Snap Ring and pull out the pump

tube.

2) Take out buttons on button setting.

Snap

Ring

Snap

Ring

-8-

3) Remove two screws fastening Button Setting and

separate the button setting on body base.

4) Remove four screws fastening the Pump on the

Body Base.

5) Separate E-ring using pump nipple.

Button Setting

-9-

TROUBLESHOOTING

1. SWITCH ON BUT MOTOR DOES NOT RUN

Checking Cause Solution

2. SWITCH ON, MOTOR DOES NOT RUN BUT BUZZES

Check the power

source. Poor plug insertion

Power cord cut

Interior lead wire cut

Motor(stator armature)

coil cut or damaged

Poor contact carbon

brush defaced

Poor switch contact point

Insert again

Repair or exchange

Exchange the lead wire

Exchange the motor

Exchange or repair

Exchange the switch

Motor armature cut Exchange the motor

Exchange the motor

Remove the foreign

matters

Ball bearing defacement

Impeller hindrance

(Caused by foreign matters)

-10-

3. SWITCH OFF BUT MOTOR RUNS

4. WEAK SUCTION POWER

5. SWITCH ON BUT PUMP DOES NOT OPERATE

Low rotation speed

Motor armature cut

Carbon brush defaced Exchange the carbon

brush or the motor

Exchange the motor

Remove the foreign

matters

Inquire to the Power utility

company

Foreign matters attached

to the impeller

Low voltage

Poor connection Repair

Exchange the switchPoor switch

Motor runs normally,

but suction power is

weak.

Hose and extension wands

are clogged with foreign

matters

Remove the foreign

matters in the hose or

extension wands

Poor connection Repair

Exchange pumpNo-pumping

Air filter is clogged. Clean the Air filter.
