OWNER'S MANUAL

ROBOT CLEANER

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

R5T-AUTO

MFL71751926

Rev.00_082423

www.lg.com

TABLE OF CONTENTS

This manual may contain images or

content that may be different from the

model you purchased.

This manual is subject to revision by the

manufacturer.

SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE...........................................................3

WARNING............................................................................................................3

CAUTION .............................................................................................................8

BEFORE USING

Parts and Specifications ..................................................................................10

Charging............................................................................................................12

OPERATION

Control Panel ....................................................................................................15

Cleaning ............................................................................................................15

SMART FUNCTIONS

Using LG ThinQ Application............................................................................18

MAINTENANCE

Regular Cleaning..............................................................................................21

TROUBLESHOOTING

Before Calling for Service................................................................................25

SAFETY INSTRUCTIONS

ENGLISH

SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

The following safety guidelines are intended to prevent unforeseen

risks or damage from unsafe or incorrect operation of the appliance.

The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as

described below.

Safety Messages

WARNING

• To reduce the risk of explosion, fire, death, electric shock, injury or

scalding to persons when using this product, follow basic

precautions, including the following:

Technical Safety

• Read all safety warnings and instructions. Use only manufacturer’s

recommended attachments.

• If the power supply cord is damaged, it must be replaced by an LG

Electronics service center or dealer in order to avoid a potential

hazard.

This symbol is displayed to indicate matters and operations

that can cause risk.

Read the part with this symbol carefully and follow the

instructions in order to avoid risk.

WARNING

This indicates that the failure to follow the instructions can

cause serious injury or death.

CAUTION

This indicates that the failure to follow the instructions can

cause the minor injury or damage to the appliance.

SAFETY INSTRUCTIONS

• This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

responsible for their safety. Children should be supervised to ensure

that they do not play with the appliance.

• Do not allow children or pets to to play with or hang on the appliance.

• Do not allow children or pets to to sit on the appliance.

• Do not use the appliance on a wet surface.

• Place the cords from other appliances out of the area to be cleaned.

• Do not operate the appliance in a room where an infant or child is

sleeping.

• The appliance only is intended for domestic use such as household

cleaning. Do not use it for commercial, experimental or industrial

purposes.

• Do not use in commercial applications such as workshops or garages

or around indoor swimming pools, or wet areas, etc.

• Before using this appliance, clear the floor of objects such as candles,

power cords, fragile objects, clothing, loose papers, and pull cords for

blinds or curtains.

• For your safety, do not remove the battery from the appliance. If you

need to replace the battery of the appliance, take it to an authorized

LG Electronics service centre or dealer for assistance.

• Do not stare into the laser beam.

• Potential dazzling visual effects may be caused by exposure to the

direct laser beam particularly in low ambient light.

Battery

• Never use the battery, adapter, and the home station from other

appliances with this appliance. Use only the battery and the home

station provided by LG Electronics.

• Never use the battery, adapter, and the home station from this

appliance with other appliances.

SAFETY INSTRUCTIONS

ENGLISH

• Keep the batteries out of the reach of children. Swallowing the

batteries can lead to chemical burns, perforation of soft tissue, and

death. Seek medical attention immediately. Severe burns can occur

within 2 hours of swallowing.

• Unplug the power cord if the appliance will not be used for an

extended period of time and store it in a safe place away from heat

and children.

• Do not use modified or damaged batteries.

• When disposing of the battery or the appliance, remove the battery

from the appliance and safely dispose of it.

• Do not use the battery if it is leaking or has changed shape. If battery

fluid comes into contact with skin or eyes, thoroughly wash the

affected area immediately with clean water and seek medical

attention.

• Do not disassemble or short-circuit the battery. Do not crush or

dismantle the battery.

• Do not heat or place the battery near any heat source or direct

sunlight. Do not subject the battery to mechanical shock.

• Have the battery replaced when it is no longer able to hold a charge.

For replacement, contact an authorized LG Electronics service centre

for alternative battery options.

• When disposing of this appliance, follow regulations for disposal of

rechargeable lithium-ion batteries.

• Follow all local ordinances and regulations when handling or

disposing of the battery.

Battery Specifications

Model Name

INR18650F9M-4S1P

Type

Rechargeable Lithium-ion Battery

Rated Capacity

DC 14.4 V, 3200 mAh

SAFETY INSTRUCTIONS

Installation

• Charge, store and operate this appliance in room temperature

environments only.

• Do not use a multiple socket outlet such as a power board, an

extension power cable or adapter with this appliance.

• Place the home station on a firm, level surface.

• Charge and store the appliance in a well-ventilated place.

• Do not store the product body, power cord or home station near

heating devices or open flames.

• Do not operate or store the appliance at temperatures below 5 °C or

above 38 °C.

• This appliance is designed to be plugged into a standard outlet only.

The appliance may not be used with any type of power converter.

• Do not plug the appliance into a damaged or loose outlet.

• Dispose of all packaging materials (such as plastic bags and

styrofoam) away from children. The packaging materials can cause

suffocation.

Operation

• Read all instructions before using the appliance, and save these

instructions.

• Do not handle the power cord, plug, home station or product body

with wet hands.

• Wipe any moisture or dirt off the cord or plug with a dry cloth.

• Never unplug the appliance by pulling on the power cord. Always grip

the plug firmly and pull straight out from the outlet.

• Never attempt to operate this appliance if it is damaged,

malfunctioning, partially disassembled, or has missing or broken

parts, including a damaged cord or plug. Take it to an authorized LG

Electronics service centre or dealer for assistance.

• Do not apply excessive force to the power cord to bend it, or place it

under a heavy object as this will damage it.

• Do not plug the appliance into a damaged or loose outlet.

SAFETY INSTRUCTIONS

ENGLISH

• Push the power plug firmly into the wall outlet so that it is not loose.

• Before using the appliance, remove any wire or string on the floor.

• Do not cover the power cord with a rug or carpeting.

• If the product makes a strange noise or emits an odour or smoke,

discontinue use and contact an LG Electronics customer information

centre.

• Only qualified technicians or service personnel from LG Electronics

may disassemble, repair or modify the appliance.

• Never insert a sharp metal object such as a pin, nail or knife in a hole

or gap in the product body or the home station.

• Do not clean up liquids with this appliance. Make sure that no water,

beverage or detergent gets inside the product body or the home

station.

• Do not use the appliance to clean up blades, thumb tacks, sawdust,

sharp objects, or hot or cold ashes.

• Keep clothing and hair, fingers, or other parts of the body away from

openings and moving parts.

• Do not use in an enclosed space where vapors are present from paint

thinner, mothproofing substances, flammable dust or other

explosive or toxic materials.

• Do not touch the charging terminals on the appliance or the home

station, or insert an electrified object inside the appliance or the

station.

• If the earth leakage breaker is tripped when the product is put on the

home station, immediately remove the appliance from the home

station. Contact an LG Electronics customer service centre.

• Do not use or store a heating device or flammable substance (ether,

benzene, alcohol, chemicals, combustible sprays, insecticide, air

freshener or cosmetics) in close proximity to the appliance.

• Do not attempt to clean up liquids (water, beverages), smelly

substances (candy, chocolate, pet excrement), metal objects (blades,

pins), flammable substances, surfactants, or glass shards with this

appliance.

SAFETY INSTRUCTIONS

• In the event of a gas leak (natural gas, propane gas, etc.), do not

operate this or any other appliance. Open a window or door to

ventilate the area immediately.

• Never allow any water, beverage or detergent to get inside the

battery.

• Make sure to unplug the power cord when cleaning or maintaining

the home station.

Maintenance

• Turn the power supply off immediately if any abnormal sound, odor,

or smoke is generated from the appliance by removing it from the

Home Station and turning off the main switch on the rear side of the

appliance.

• Do not spray or use inflammable materials, surfactants, or drinking

water in the vicinity of the appliance.

- Inflammable materials: gasoline, thinner, etc.

- Surfactant: detergent, articles for bath, etc.

CAUTION

• To reduce the risk of explosion, fire, death, electric shock, injury or

scalding to persons when using this product, follow basic

precautions, including the following:

Installation

• Remove any cables or string from the floor before starting.

• Make sure the appliance is not put on a table or desk, with the power

ON.

Operation

• Do not use the appliance around a banister, staircase or any other

dangerous place.

SAFETY INSTRUCTIONS

ENGLISH

• Do not use the appliance when the dust bin is completely full.

• Use a protective cover on the chair leg, table leg or other narrow

pieces of furniture to reduce the possibility of collision or scratch.

• Do not put water, detergent, etc. into or onto the appliance.

• Ensure that liquids do not seep into the appliance. If liquid gets inside

of the appliance, turn off the power supply and take it to the

authorized LG Electronics service center or dealer for assistance.

• Remove thin mats or carpets that may be damaged.

• Do not turn over the robot mop and wet the mop pad with water

while the mop pad is attached to the robot mop.

• Wet floors can pose a slip hazard. Allow floors to dry completely

before allowing anyone to walk on them.

• Do not clean carpets with the robot mop. The carpet may get wet or

stick to the velcro, causing damage to the carpet.

• Do not clean a coated floor with the robot mop. Cleaning a coated

floor repeatedly could cause the coating to peel off.

• Do not use on PVC and PU mats for infants and children as friction

may cause the motor to overheat.

• Do not fill the water tank with liquid other than room temperature

water. Liquids such as hot water, detergent, fabric softener or aroma

oil must not be used.

• Close the door to prevent the robot vacuum cleaner from entering

the bathroom before using it.

BEFORE USING

Parts and Specifications

Front View

LIDAR Sensor

Control Panel

Infrared sensor for charging

Side View

Bumper

Ventilation Port

Bottom View

Cliff Detection Sensors

Charging Terminals

Side Brush

Brush

Brush Cover Release Buttons

Rear View

Dust Bin and Water Tank Release Button

Main Power Switch

Tabla de contenidos

Otros manuales de Aspiradora de LG

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario

Nobles

Nobles 608669 Manual del producto
