LG 32LQ630B6LB Manual de usuario
1. Model Name: 32LQ630BPSA
2. Suffix: TR
3. Part No: MFL71833920
4. REV REV00
5. Number of pages 16
6. Folded/Unfolded 3 Folded
7. Trim size (W x H)_Unfolded (mm) 296 x 420 (+/- 5)
8. Trim size (W x H)_folded (mm) 148 x 105 (+/- 5)
9. Bindery -
10. Color (Cover) -
11. Paper (Cover) -
12. Weight (cover) (g/m2)-
13. Color (inner) 4 (CMYK)
14. Paper (inner) Wood free
15. Weight (inner) (g/m2)70 (+/- 10)
16. Coating No
17. Thomson No
18. Sub-material No
[Country Name]
LGEIL: India
LGEKR: Korea
Changes the Country name. LGEMA: Poland
Printed in [Country Name] LGEND: China
Others: Each Country name.
[Restriction of Hazardous Substances ]
Hazardous substances on this product should be satisfied by substance regulation of Level A-I, A-II, SVHC according to LG(52)B—5011 standard.
(1) Hazardous substances test report should be submitted when part certification test and first mass production.
(2) Especially, Don’t use or contain lead (Pb) and cadmium (Cd) in ink.
REV07
REV06
REV05
REV04
REV03
REV02
REV01
REV00 Checked :
Approved :
Rev. Number Date ECO Number Owner Santosh.C
2. Origin Notification
ENG
19. Languages
Printing Specification
1. Specification 1.1 Folding / Cover
Models
SIZE
COVER
INNER
3. History
Description
NOTE Especially, Part should be followed and controlled the following specification.
12/06/2021
296 mm
1
2
3
Barcode
Front
Back
420 mm
105 mm
148 mm
Folding Step
Folded
Aditya.K
Nitin Hase
1
5
2
32LQ63*
1 2 3
Head
washer
AAA
Head
washer
Head
washer
x 2
(M4 x L16)
3
4
AA
1O cm
* M F L 7 1 8 3 3 9 2 0 2 1 1 2 R E V 0 0 *
www.lg.com
Images shown in manual may vary depending on model
Unpacking
Check your product box for the following items. If there are
any missing accessories, contact the local dealer where you
purchased your product. The illustrations in this manual may
differ from the actual product and item.
Quick Start Guide
: Depending on model
: Depending on country
Kg
90°
A
B
C
D
E
F
G
A B C x D(mm) E
WallMount 32LQ63* 200 x 200 M6
B
A
C
D
E
The Analog Gender adapter can be purchased separately at Customer Service.
5s
1
ABCD E F F G
32LQ630B6LB
32LQ630BPSA 736 464 180 437 82.9 4.7 4.65
32LQ635BPSA
32LQ6360PSA
32LQ636BPSA
736 464 180 437 82.9 5.1 5.05
Power requirement
An external audio device that
supports SIMPLINK and ARC
must be connected using
HDMI IN eARC/ARC port
When connected with a
high-speed HDMI cable, the
external audio device that
supports ARC outputs SPDIF
audio without additional audio
cable and supports the
SIMPLINK function
ARC (Audio Return Channel)
Do not look into the optical
output ports, looking at the
laser beam may damage
your vision
Audio with ACP (Audio Copy
Protection)function may
block digital audio output.
An external audio device that
supports SIMPLINK and ARC
must be connected using
HDMI IN eARC/ARC port
When connected with a
high-speed HDMI cable, the
external audio device that
supports ARC outputs SPDIF
audio without additional audio
cable and supports the
SIMPLINK function
ARC (Audio Return Channel)
Some USB Hubs may not
work, if a USB device con-
nected using a USB Hub is
not detected, connect it to
the USB port on the TV
directly
Connect the external power
source if your USB is needed.
Image shown may vary depending on
model .
All connection cables & devices shown
in the picture are not included along
with the product.
