OWNER'S MANUAL
Color Video Camera
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
LCZ2850-DN/LCZ2850-DP
LCZ2850 series
2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s
enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modications to this
equipment may cause harmful interference unless the
modications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modication is
made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment
is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to
radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
• A suitable conduit entries, knock-outs or glands shall
be provided in the cable entries of this product in the
end user.
3
• Caution: Danger of explosion if battery is incorrectly
replaced. Replaced only with the same or equivalent
type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s
instructions.
• Holes in metal, through which insulated wires pass,
shall have smooth well rounded surfaces or shall be
provided with brushings.
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à la
norme NMB-003 du Canada.
Warning
• Do not install this equipment in a conned space such
as a bookcase or similar unit.
• Wiring methods shall be in accordance with the
National Electric Code, ANSI/NFPA 70.
• This is a class A product. In a domestic environment
this product may cause radio interference in which
case the user may be required to take adequate
measures.
• To reduce a risk of re or electric shock, do not expose
this product to rain or moisture.
Caution
• This installation should be made by a qualied service
person and should conform to all local codes.
• To avoid electrical shock, do not open the cabinet.
Refer servicing to qualied personnel only.
• The apparatus shall not be exposed to water (dripping
or splashing) and no objects lled with liquids, such as
vases, shall be placed on the apparatus.
To disconnect power from mains, pull out the mains cord
plug. When installing the product, ensure that the plug is
easily accessible.
4
Disposal of your old appliance
1. When this crossed-out wheeled bin
symbol is attached to a product it means
the product is covered by the European
Directive 2002/96/EC.
2.
All electrical and electronic products
should be disposed of separately from the
municipal waste stream via designated
collection facilities appointed by the
government or the local authorities.
3. The correct disposal of your old
appliance will help prevent potential
negative consequences for the
environment and human health.
4. For more detailed information about
disposal of your old appliance, please
contact your city oce, waste disposal
service or the shop where you purchased
the product.
LG Electronics hereby declares that this/
these product(s) is/are in compliance with
the essential requirements and other relevant
provisions of Directive 2004/108/EC, 2006/95/
EC, and 2009/125/EC.
European Standards Centre:
Krijgsman 1, 1186 DM Amstelveen The
Netherlands
5
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not t into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
Important Safety Instructions
6
Power Supply
This camera must always be operated a DC 12 V Certied/
Listed, class 2 power supply only.
Handling of the unit
Be careful not to spill water or other liquids on the unit. Be
cautions not to get combustible or metallic material inside
the body. If used with foreign matter inside, the camera is
liable to fail or to get cause of re or electric shock.
• Remove dust or dirt on the surface of the lens with a
blower.
• Use a dry soft cloth to clean the body. If it is very dirty,
use a cloth dampened with a small quantity of neutral
detergent then wipe dry.
• Avoid the use of volatile solvents such as thinners,
alcohol, benzene and insecticides.
• They may damage the surface nish and/or impair the
operation of the camera.
Operating and storage location
Avoid viewing a very bright object (such as light ttings)
during an extended period. Avoid operating or storing the
unit in the following locations.
• Extremely hot or cold places (operating temperature
• -10 °C to 50 °C, however, we recommend that the unit
be used within a temperature range of 0 °C to 45 °C)
• Damp or dust place
• Places exposed to rain
• Places subject to strong vibration
• Close to generators of powerful electromagnetic
• radiation such as radio or TV transmitters.
Cautions for Safe Operation
7
Features................................................................. 8
Part Names and Functions................................... 9
Connections ........................................................11
Power connection.........................................................11
Connecting Monitor ....................................................11
Menu Opertaion .................................................16
General Operation........................................................18
Focus settings ................................................................19
Exposure Settings.........................................................21
White Balance setting .................................................23
Day/Night setting .........................................................25
Motion Detection setting ..........................................26
Privacy Mask setting ....................................................27
3D-DNR setting..............................................................28
Special menu settings.................................................29
Reset settings.................................................................32
Reference ............................................................33
On Screen Display.........................................................33
RS-485 Protocol (Optional)........................................35
Specications .................................................................37
Contents
8
Features
This color video camera is designed for use in monitoring
system.
• High resolution and high sensitivity with a 4.5 mm
(1/4 Type) Super HAD CCD II.
• High magnitude of zoom lens with optical x28,
Digital x12 (MAX x336)
• Auto Focus
• Auto White Balance
• Auto exposure with DC Iris control
• Day & Night function
9
CONTROL
S - VIDEO
POWER
VIDEO
OUT
+ 12V DC -
a b
aCamera installation bracket
The bracket can be xed at the top or bottom of the
camera.
bLens mount cap
The cap is installed to protect the lens mount section.
Remove the lens mount cap before install the camera.
(sold separately)
CONTROL
S - VIDEO
POWER
VIDEO
OUT
+ 12V DC -
cde
fgh
cPower indicator
Comes on when the power to the camera is on.
dControl buttons
• T(TELE) button: When push, picture is telephoto.
• N(NEAR) button: In a manual situation, focus get
Part Names and Functions
a b
10
Part Names and Functions
near.
• M(MENU) button: If you want to set up a diverse
function, you can push this button.
• W(WIDE) button: When push, picture is wide
angle.
• F(FAR) button: In a manual situation, focus get far.
• H(HOT) button: When you set the DAY/NIGHT
mode to EXT, you can change the Day/Night mode
using this button.
eVideo output (S-Video type)
Connect to the S-Video in connector of a monitor.
fCONTROL connector
Interface of camera control jack (10 Pin Din Jack Type)
gPower input terminal
Connect to an external power supply of DC 12V.
hVideo output connector (BNC type)
Connect this connector to a device such as a VCR or
monitor with a VIDEO IN connector.
Otros manuales para LCZ2850-DN
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Cámara de seguridad de LG
LG
LG LNP2810 Manual de usuario
LG
LG LV300N-C Manual de usuario
LG
LG L9322 Series Manual de usuario
LG
LG LW332 Series Manual de usuario
LG
LG L6223 Series Manual de usuario
LG
LG L2304-DN Manual de usuario
LG
LG LW6454 series Manual de usuario
LG
LG LCV5300R-BP Manual de usuario
LG
LG LND3210R series Manual de usuario
LG
LG LCV5300R-BN Manual de usuario
LG
LG LVC-S60HM Manual de usuario
LG
LG LNB7210 Manual de usuario
LG
LG RNOE-B501A Manual de usuario
LG
LG LVC-DV110HM Manual de usuario
LG
LG LPT-DW113P Manual de usuario
LG
LG LW9226 Series Manual de usuario
LG
LG LVC-S60HM Manual de usuario
LG
LG LW130W Manual de usuario
LG
LG LT913 Series Manual de usuario
LG
LG LW9424 Manual de usuario
