LG 27MP36HQ Manual de usuario

Please read this manual carefully before operating

your set and retain it for future reference.

www.lg.com

*Disclaimer: LG LED Monitor applies LCD screen with LED backlights.

This product is a computer monitor and not for television purpose.

Owner's Manual

IPS LED COMPUTER

MONITOR

LED LCD COMPUTER

MONITOR

(LED COMPUTER

MONITOR*)

IPS LED Computer Monitor (LED Computer Monitor) Model List

19M37A

19M37D

19M37H

20M37A

20M37D

20M37H

20MP37A

22M37A

22M37D

22M37H

22M37HQ

22MC37D

24M37A

24M37D

24M37H

24M37HQ

24MC37D

27M37D

27MP37HQ

27MP37VQ

27MC37HQ

27MP36HQ

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

6 Partsandbuttons

7 MovingandLiftingtheMonitor

8 SettinguptheMonitorset

8 - AttachingtheStandBase

9 - DetachingtheStandBase

10 - Mountingonatable

10 - Usingthecableholder

12 - Mountingonawall

13 USINGTHEMONITORSET

13 ConnectingtoaPC

13 - D-SUBconnection

13 - DVI-Dconnection

14 - HDMIconnection

15 ConnectingtoExternalDevices

15 - Peripheraldeviceconnection

16 CUSTOMIZINGSETTINGS

17 CustomizingSettings

17 - MenuSettings

19 -Picture

20 -Color

21 -Display

21 -Audio

22 -Others

23 READERSetting

24 FUNC.Setting

24 -SMARTENERGYSAVING

25 -PictureMode

26 -Colorwizard

27 -DUALDISPLAY

27 -DUALWEB

28 TROUBLESHOOTING

30 SPECIFICATIONS

40 PresetModes(Resolution)

41 Indicator

42 PROPERPOSTURE

42 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

27MP37VQ

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisnoadjust-

menttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

19M37H

27MC37HQ

20M37H 22M37H 22M37HQ 24M37H 24M37HQ 27MP37HQ 27MP37VQ

27MP36HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

D-SUBCable

(Thiscableisnotincludedinall

countries.)

HDMICable

StandBody StandBase

StandBase

DVI-DCable

(Thiscableisnotincludedinall

countries.)

(Thiscableisnotincludedinall

countries.)

StandBody

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

HDMI IN

22M37HQ

19M37A 20M37A

20MP37A

22M37A

24M37A

19M37H 20M37H 22M37H 24M37H

24M37HQ

19M37D 20M37D 22M37D 22MC37D

24M37D 24MC37D 27M37D

27MP37HQ 27MC37HQ

27MP37VQ

27MP36HQ

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.13~15)

Button(Seep.16)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotheright.

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

2

StandBase

StandBody

StandBase

19M37A 20M37A 22M37A 24M37A

19M37D 20M37D 22M37D 24M37D

19M37H 20M37H 22M37H 24M37H

20MP37A 22M37HQ 24M37HQ

22MC37D 24MC37D

27M37D 27MP37HQ 27MP37VQ 27MC37HQ

27MP36HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBase

StandBody

PullouttheStandBodyandStandBase

fromthemonitorset.

Turnthescrewtotheleft.

PullouttheStandBase.

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

Turnthescrewtotheleft.

PullouttheStandBasefromtheStandBody.

RemovetwoscrewsandpullouttheStand

Bodyfromthemonitorset.

StandBody

StandBase

219M37A 20M37A 22M37A 24M37A

19M37D 20M37D 22M37D 24M37D

19M37H 20M37H 22M37H 24M37H

20MP37A 22M37HQ 24M37HQ

22MC37D 24MC37D

27M37D 27MP37HQ 27MP37VQ 27MC37HQ

27MP36HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder
