LG 25UM57 Manual de usuario

www.lg.com

25UM57

29UM57

Please read the safety information carefully before using the

product.

IPS LED Monitor (LED Monitor) Model List

Owner's Manual

IPS LED MONITOR

(LED MONITOR*)

*LG LED Monitors are LCD Monitors with LED Backlighting.

ENG

ENGLISH

Contents

CONTENTS

21 ActivatingtheMainMenu

22 Customizingsettings

22 - MenuSettings

22 - -QuickSettings

23 - -Picture

25 - -General

26 - -Reset

27 - -Gamemode

29 TROUBLESHOOTING

31 SPECIFICATIONS

31 25UM57

32 29UM57

33 Factorysupportmode

33 HDMITiming(Video)

33 PowerIndicator

34 PROPER POSTURE

34 ProperPostureforUsingtheMonitor

3 LICENSE

4 ASSEMBLING AND

PREPARING

4 ProductComponents

5 ComponentandButtonDescription

6 MovingandLiftingtheMonitor

7 InstallingtheMonitor

7 - Assemblingthestandbase

8 - Usingthecableholder

9 - Detachingthestandbase

11 - Installingontoatable

12 - Adjustingtheangle

13 - UsingtheKensingtonlock

13 - Installingthewallmountplate

14 - Installingtoawall

15 USING THE MONITOR

15 ConnectingtoaPC

15 - HDMIconnection

15 ConnectingtoAVDevices

15 - HDMIconnection

16 ConnectingtoExternalDevices

16 - Headphoneportconnection

17 INSTALLING THE LG

MONITOR SOFTWARE

17 InstallingTheScreenSplit

19 InstallingTheDualController

21 CUSTOMIZING SETTINGS

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedstomeet

theErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisno 

adjustmenttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Product Components

Pleasecheckwhetherallthecomponentsareincludedintheboxbeforeusingtheproduct.Ifthereare

missingcomponents,contacttheretailstorewhereyoupurchasedtheproduct.Notethattheproductand

componentsmaylookdifferentfromthoseshownhere.

 Alwaysusegenuinecomponentstoensuresafetyandproductperformance.

 Theproductwarrantywillnotcoverdamageorinjurycausedbytheuseofcounterfeitcomponents.

 Notethatthecomponentsmaylookdifferentfromthoseshownhere.

 Withoutpriornotice,allinformationandspecificationsinthismanualaresubjecttochangetoim-

provetheperformanceoftheproduct.

 Topurchaseoptionalaccessories,visitanelectronicsstoreoronlineshoppingsiteorcontactthe

retailstorewhereyoupurchasedtheproduct.

 TheDisplayPortcablemaynotbeavailableinsomeareas.

CAUTION

NOTE

User Manual/Card

Stand Base Stand Body Screw Cover Screws

HDMI Cable

Stand Base Stand Body Screw Cover Screws

(Dependingonthecountry) (Dependingon

thecountry)

Power Cord AC-DC Adapter AC-DC Adapter

ENG

ENGLISH

ASSEMBLING AND PREPARING

Component and Button Description

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Moving and Lifting the Monitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

 Ifyouusethemonitorpanelwithoutthe

standbase,itsjoystickbuttonmaycause

themonitortobecomeunstableandfall,

resultingindamagetothemonitororhuman

injury.Inaddition,thismaycausethejoystick

buttontomalfunction.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Installing the Monitor

Assembling the stand base

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

2 Checkthedirectionofthestandbody

(front,back)andthenmountthestandbody

ontothestandhinge.

Tightentwoscrewsintothebackofthestand

body.

1 Placethescreenfacedown.

3

4 Attachthescrewcover.

Stand Body

Stand Base

Stand Hinge

AttachtheStand BasetoStand Body.

Tightenthescrewtotheright.

Screws

Screw Cover

25UM57

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

2 Checkthedirectionofthestandbody

(front,back)andthenmountthestandbody

ontothestandhinge.

Tightentwoscrewsintothebackofthestand

body.

1 Placethescreenfacedown.

Applyingexcessiveforcewhentightening

thescrewsmaycausedamagetothemoni-

tor.Damagecausedinthiswaywillnotbe

coveredbytheproductwarranty.

CAUTION

3

4 Attachthescrewcover.

Itmayhurtyourfootoffthestand,sobe

careful.

CAUTION

Stand Body

Stand Base

Stand Hinge

AttachtheStand BasetoStand Body.

Tightenthescrewtotheright.

Screws

Screw Cover

29UM57

Using the cable holder

ENG

ENGLISH

ASSEMBLING AND PREPARING

Detaching the stand base

2 Removethescrewcover.

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

1 Placethescreenfacedown.

25UM57

3 Removethetwoscrewsonthebackofstand

body.

Asshownintheillustration,disconnectthe

stand body from the stand hinge.

Screw cover

Stand Body

Stand Base

Turnthescrewtotheleft.

PullouttheStand Base.

41

Screws

Stand Body

ENG

ENGLISH

ASSEMBLING AND PREPARING

2 Removethescrewcover.

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

 Illustrationsinthisdocumentrepresenttypi-

calprocedures,sotheymaylookdifferent

fromtheactualproduct.

 Donotcarrythemonitorupsidedownbyjust

holdingthestandbase.Thismaycausethe

monitortofalloffthestandandcouldresult

inpersonalinjury.

 Whenliftingormovingthemonitor,donot

touchthemonitorscreen.Applyingforceor

pressuremaydamagethemonitorscreen.

Instead,holdthestandbodyortheplastic

frameoftheproduct.

CAUTION

1 Placethescreenfacedown.

29UM57

3 Removethetwoscrewsonthebackofstand

Asshownintheillustration,disconnectthe

stand body from the stand hinge.

Stand Hinge

Screw cover

Stand Body

Stand Base

Turnthescrewtotheleft.

PullouttheStand Base.

41

 Thecomponentsintheillustrationsmaydif-

ferfromtheactualproduct.

 Donotcarrythemonitorupsidedown,asthis

maycauseittofalloffitsstandandresultin

damageorinjury.

 Toavoiddamagingthescreenwhenlifting

ormovingthemonitor,onlyholdthestandor

theplasticcover.Thisavoidsputtingunnec-

essarypressureonthescreen.

CAUTION
