ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBase

CD(Owner'sManual)/

Card

D-SUBCable

(Thiscableisnotincludedinall

countries.)

(Dependingonthecountry) (Dependingonthecountry)

PowerCord

DVI-DCable

(Thiscableisnotincludedinall

countries.)

OneScrew CableHolder

USBCable

AudioCable

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

(PowerButton)

PowerIndicator

 LEDOn:Powerison

 LEDOff:Powerisoff

FrontSideButtons

Motionsensorlens

InputConnectors(Seep.12to14)Seep.12to14)to14)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Motionsensorlens

Cautioninuse

Pleaseavoidusingthefresnellensinthefollowingconditionsbecauseitmaycausefailureor

malfunction.

(a)Insuchafluidaswater,alcoholetc.corrosivegas(SO2,Cl2,NOXetc.)orseabreeze.

(b)Inhighhumidity.

(c)Inaplaceexposeddirectlytosunlightorheadlightofautomobile.

(d)Inaplaceexposeddirectlytoblowfromair-conditionerorheater.

(e)Insuchaplacewhereinfraredrayisshaded.

(f)Inanyotherplacesimilartotheabove(a)through(e).

TheperformanceofMotionEnergySaverismaximizedtoaspecificuserdistance(1m)andangle(20

degrees).

Thesensormaynotdetectyouifyouaremotionless.

Ifyouthinkthatthemodeentrymessageappearstoofrequently,increasethetimesettingoftheMotion

EnergySaverorturnthemodeoff.

Avoidusingradioequipmentsuchasawalkie-talkieneartheproductasthismaycauseaproduct

malfunction.

Thesensormaynotdetectyou,whenthemonitorisusedinportraitmodedependingonaspecific

userangle.

Noticeinhandlingandstorage

1)Opticalfilterofsensorshouldnotbescratchedorsoiled.

2)Strongshockshouldbeavoided.

3)Hightemperature,highhumidity,fluidaswateroralcoholetc.,corrosivegas(SO2,Cl2,NOXetc.)and

seabreezeshouldbeavoided.

ENG

ENGLISH

ASSEMBLING AND PREPARING

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreensidedown

onaflatandcushionedsurface.

StandBase

StandBody

StandBase

StandBody

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

3 Usingacoin,turnthescrewclockwisetosecure

thestandbase.

2 Checktheposition(atthefrontandrear)of

thestandbody,thenmountthestandbaseon

thestandbodyasshowninthefigure.

CAUTION

StandBase

 Thecomponentsappearingintheillustra-

tionsmaylookdifferentfromtheactualprod-

uct.

 Donotcarrythemonitorupside-downasthis

maycauseittofalloffitsstand,resultingin

damageorinjury.

 Toavoiddamagingthescreenwhenlifting

ormovingthemonitor,onlyholdthestandor

theplasticcover.Thisavoidsputtingunnec-

essarypressureonthescreen.

 Onlyremovethetapeandthelockingpin

whenthemonitorismountedonthestand

baseandisinanuprightposition.Otherwise,

thestandbodymayprotrude,whichmay

leadtoinjury.

Detachingthestandbase

1 Placethemonitor'sscreenfacedown.

Toprotectthescreenfromscratches,coverthe

surfacewithasoftcloth.

2 Usingacoin,turnthescrewinthestandbase

counterclockwise.Detachthestandbasefrom

thestandbody.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 Liftthemonitorandplaceitonthetableinan

uprightposition.

Installatleast10cmawayfromthewallto

ensuresufficientventilation.

10 cm

Detachingthestandbody

1 Placethemonitor'sscreenfacedown.To

protectthescreenfromscratches,coverthe

surfacewithasoftcloth.

2 Usingascrewdriver,removethefourscrews

anddetachthestandfromthemonitor.

Usingthecableholder

FixtheKnob(Cableholder)tothe

Hole(Hingebody).

UseonescrewtofixtheCableHolderand

monitorset.

ClosetheCableholder.

3 Pressthe (Power)buttononthefrontofthe

monitortoturnonthemonitor.

 Unplugthepowercordpriortomovingor

installingthemonitor.Thereisriskofelectric

shock.

CAUTION

ConnectthePowercordtothemonitor,then

plugthepowercordintothewalloutlet.

(Beforeconnectpleasecheckthe“ON/OFF”

knobin“O”state).

Pressthe“ON/OFF”knobin“”state

(Openthepower).



ENG

ENGLISH

ASSEMBLING AND PREPARING

Adjustingtheangle

1 Placethemonitormountedonthestandbase

inanuprightposition.

2 Adjusttheangleofthescreen.Theangleofthe

screencanbeadjustedupto5°forwardsand

20°backwardsforacomfortableviewingexpe-

rience.

 Toavoidinjurytothefingerswhenadjusting

thescreen,donotholdthelowerpartofthe

monitor'sframeasillustratedbelow.

 Becarefulnottotouchorpressthescreen

areawhenadjustingtheangleofthemonitor.

WARNING

FrontSideRearSide

22MB67PY

2 Adjusttheangleofthescreen.Theangleofthe

screencanbeadjustedupto5°forwardsand

35°backwardsforacomfortableviewingexpe-

rience.

FrontSideRearSide

24MB67PY 27MB67PY

Adjustingthestandheight

1 Placethemonitormountedonthestandbase

inanuprightposition.

2 Removethetapeattachedatthebottomrearof

thestandbody,thenpulloutthelockingpin.

Tape

LockingPin

StandBody



ENG

ENGLISH

ASSEMBLING AND PREPARING

Using the Kensington locking

device

TheconnectorfortheKensingtonlockislocated

ontherearofthemonitor.

Formoreinformationoninstallationandusage,

refertotheKensingtonlockusermanualorvisit

thewebsiteathttp://www.kensington.com.

ConnectthemonitortothetablewiththeKensing-

tonlockcable.

 UsingtheKensingtonlockisoptional.The

accessoriescanbepurchasedatyourlocal

electronicsstore.

NOTE

 Oncethepinisremoved,itisnotnecessary

tore-insertittoadjusttheheight.

3 Theheightcanbeadjustedupto120mm.

 Donotputyourfingerbe-

tweenthescreenandthe

base(chassis)whenadjust-

ingthescreen'sheight.

CAUTION

WARNING

120.0mm

22MB67PY

3 Theheightcanbeadjustedupto130mm.

130.0mm

24MB67PY 27MB67PY

ENG

ENGLISH

ASSEMBLING AND PREPARING

Swivelstand

 ImageshownmaydifferfromyourMonitor

set.

1 Swivel355degreesandadjusttheangleofthe

Monitorsettosuityourview.

1 Liftthemonitortoitshighestheighttoutilizethe

Pivotfunction.

UsingthePivotfunction

Thepivotfunctionallowsyoutorotatethescreen

90degreesclockwise.

2 Landscape&Portrait:Youcanrotatethepanel

90°clockwise.Pleasebecautiousandavoid

contactbetweenthemonitorheadandthe

StandBasewhenrotatingthescreentoaccess

thePivotfunction.Ifthemonitorheadtouches

theStandBase,thentheStandBasecould

crack.

Head

section

Stand

section

3 Becarefulwiththecableswhenrotatingthe

screen.
