LG 86UL3J-N Manual de usuario

OWNER’S MANUAL

LG Digital Signage

(MONITOR SIGNAGE)

www.lg.com

Please read this manual carefully before operating your set and retain it for future

reference.

43UL3J-B

50UL3J-B

55UL3J-B

65UL3J-B

75UL3J-B

86UL3J-B

43UL3J-N

50UL3J-N

55UL3J-N

86UL3J-N

ENGLISH

TABLE OF CONTENTS

SAFETY PRECAUTIONS ................3

- Precautions for the AC Adapter and Power ......4

- Precautions for Moving the Product......................6

- Precautions for Installing the Product ..................7

- Precautions for Cleaning the Product...................9

- Precautions for Using the Product.......................10

- Precautions for Using the Remote control......12

- Precautions for Experiencing Image Retention...

- Product Disposal............................................................13

ASSEMBLY AND PREPARATION 14

- Parts and Buttons.........................................................15

- Portrait Layout................................................................16

- Using Kensington Lock...............................................16

- Installing on a Wall........................................................17

REMOTE CONTROL .................... 19

MAKING CONNECTIONS........... 21

- Connecting to a PC.......................................................21

- External Device Connection.....................................21

- Using the Input List ......................................................22

- Connecting Multiple Monitors................................23

TROUBLESHOOTING.................. 24

PRODUCT SPECIFICATIONS...... 28

LICENSES.................................... 35

ENGLISH

WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may

cause radio interference.

SAFETY PRECAUTIONS

The safety precautions are intended to prevent unexpected danger or harm by helping the user to use the product

safely and for its intended purpose.

WARNING

If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.

CAUTION

If you ignore the caution message, you may be slightly injured or the product may be damaged.

WARNING

Indoor Use Only.

ENGLISH

Precautions for the AC Adapter and Power

WARNING

•Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord,

make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the

manufacturer or the nearest authorized service center for a replacement.

•Operate the display only from a power source(i.e. voltage) indicated in the product specification.

- Otherwise the product can be damaged, fire can occur or you may be electrocuted. If you are not sure what type of

power supply you have, consult a certified installation company.

•Make sure the power cord connect to a properly grounded outlet.

- If you do not you may be electrocuted or injured or the product can be damaged.

•Insert the power plug or AC adapter firmly so it cannot come loose.

- Poor connection may cause a fire or electric shock.

•In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very

dangerous.

- It can cause electric shock.

•Be careful not to step or place heavy objects (electronic appliances, clothing, etc.) on the power cord or AC adapter.

Additionally, do not bend or pull out the power cord or AC adapter with excessive force.

- Damaged power cords may cause a fire or electric shock.

•Do not connect power cord or AC adapter damaged with sharp objects to power outlet.

- You may be electrocuted.

•Do not insert a conductor (like a metal chopstick) into one end of the power cord while the other end is connected to

the input terminal on the wall. Additionally, do not touch the power cord right after it is unplugged.

- You may be electrocuted.

•Do not use with a multi-outlet connected by many electrical product and heating devices. Use an exclusive multi-

outlet with a grounding terminal.

- A fire can break out due to overheating.

ENGLISH

•If water or any foreign substance goes inside the product, disconnect the power cord immediately and contact the

service center.

- Otherwise, this may cause a fire or electric shock due to damage to the product.

•Keep the power cord or AC adapter away from any heating devices.

- The cord coating may melt and cause fire or electric shock.

•Never disassemble, repair or modify the power cord or AC adapter.

- This may cause a fire or electric shock.

•The main cutoff device is the power cord. Please make sure the product is installed near the wall outlet and that it is

easily accessible.

•As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the

unit is turned off.

•Power consumption will be ‘0’ only when the power plug is unplugged.

•Use the appliance coupler as the disconnect device.

CAUTION

•If the outlet pins of the power plug or AC adapter is covered with dust, be sure to wipe them and keep them clean.

- Overheating due to layers of dust may cause a fire or electric shock.

•If the outlet pins of the power plug or AC adapter is covered with water be sure to wipe them and keep them clean.

Additionally, Do not touch the power plug or AC adapter with wet hands.

- This may cause an electric shock.

•Do not turn the product on or off by plugging in or unplugging the power plug from the power outlet. Do not use the

power socket as a switch.

- This may cause an electric shock or product malfunction.

•Do not unplug the power cord while the product is in use.

- Electrical shock can damage the product.

ENGLISH

Precautions for Moving the Product

WARNING

•Contact the service center before moving the product.

- It may cause electric shock and damage the product.

•Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved.

- You may be electrocuted or the product can be damaged.

•When moving the product, do not shock or cause an impact on the front panel.

- You may be electrocuted or the product can be damaged.

•Use the correct number of people according to the weight of the product. (Under 25 kg per person use lifting

equipment when exceeding 100 kg)

- If use the damaged product again, contact the service center because it can cause electric shock or fire.

•Do not hold it upside down while holding only the stand. (It is for stand supported models only.)

- This may cause stand warping, panel damage and other types of product damage.

CAUTION

•Do not dispose of the product-packing box. Use it when moving by putting the product in the box to carry it.

ENGLISH

Precautions for Installing the Product

WARNING

•Contact the service center before installing the product.

- It can cause electric shock and damage the product.

•Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects

near the product to prevent throwing things on the product screen.

- It can cause injury to human, problem to product and damage the display.

•Do not put heavy objects on, or hang from, the product.

- If the product collapses or is dropped, you may be injured.

•Do not touch the surface of the product if it overheats.

- It can cause injury to human.

•Install the product firmly fixed on a floor, wall, etc. to prepare against external impact such as wind and earthquake.

- You must refer to the manual provided.

•Prevent Children from climbing or hanging on the product.

- If the product collapses or is dropped, you may be injured.

•Do not install it where there are heating devices such as electrical heaters or lighting equipment.

- Fire, electrical shock, malfunction may occur.

•Do not install this product by yourself as you may injure yourself or cause damage to the product. Please contact

service engineer authorized by service center.

•Do not install this product on a wall if it could be exposed to oil or oil mist.

- This may damage the product and cause it to fall.

•Do not leave the power or signal cable, etc. on the pathway.

- This could cause a trip or fall, which could cause an electrical shock, fire, product breakdown, or injury.

•Do not let the product drop when connecting it to an external device connected with a short cable.

- This may cause injury and damage to the product.

•If you drop the product or the case is broken, turn off the product and unplug the power cord and contact the service

center.

- If you continue to use without taking proper measures, electrical shock or fire can occur.

•Install the product in a dry place where it is not near dust and water. Avoid high temperatures and humidity.

- This may cause electrical shock, fire or product damage.

•Safely install the product in a place that can hold the weight of the product.

- A lack of strength may cause the product to fall.

•Take a comfortable and natural position to relax the muscles when working with a product.

ENGLISH

CAUTION

•Install the product where no Electromagnetic Interference occurs.

•If you install the product in a place that does not meet the recommended conditions, this may cause serious damage

to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing. Please

do not install the product in places such as where there is an abundance of fine dust or oil mist, chemical substances

are used, exposed to direct sunlight, the temperature is very high or low, the humidity is very high.

•Make sure the product is well ventilated by Installing at a distance (100mm or more) from the wall.

- If you install the product too close to the wall, it may be deformed or fire can break out due to internal heat buildup.

•Do not cover the product with a tablecloth or a curtain or other materials (e.g. plastic) while plugged in. Do not block

the ventilation hole of the product.

- The product can be deformed or fire can break out due to overheating inside the product.

•Do not install the product in an area with poor ventilation (e.g. on a bookshelf, in a closet) or outside and avoid placing

on cushions or carpets.

- The product could catch fire due to overheating inside the product.

•Install the product on a flat and stable place that is large enough to support the product.

- If the product is dropped, you may be injured or the product may be broken.

•When installing the product on a shelf or cabinet, make sure that the bottom end of the product is not protruding

forward.

- The product may fall due to unbalanced center of gravity, which may cause personal injury or damage to the

product. Be sure to use cabinets or shelves that fit your product.

ENGLISH

Precautions for Cleaning the Product

WARNING

•Keep the product clean at all times.

- If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage.

•When you need to clean the inside of the product, you must contact the service center.

- Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product.

•When cleaning the product, unplug the power cord and wipe gently with a soft cloth to prevent scratching.

- An electric shock may occur or damage to the screen if its scratched.

•When you want to clean the front frame, spray water onto a soft cloth 2 to 4 times and wipe in one direction only.

- Too much moisture may cause staining.

CAUTION

•When cleaning the product or the screen, unplug the power cord and wipe it gently with a soft cloth. Do not spray

water or other liquids directly on the product. Especially, do not clean your product with chemicals including glass

cleaner, any type of air freshener, insecticide, lubricants, wax (car, industrial), abrasive, thinner, benzene, alcohol, etc.,

which can damage the product or its panel.

- This may result in fire, electric shock or product damage (deformation, corrosion or breakage).

ENGLISH

Precautions for Using the Product

WARNING

•Do not use the product in any environment with excessively high temperatures or humidity.

- It may cause electrical shock or damage the product.

•If you use the product for a long period of time, take a rest from time to time to protect your vision.

- Extended viewing could result in impaired vision.

•Listening at high volume or using for a long time can cause damage to your hearing.

•In the event that liquid or a foreign object falls into the product, please switch it off and unplug it from the wall outlet

and contact the service center.

- Otherwise, the product may cause fire or electric shock.

•In the event that no image appears on the screen or no sound is heard, stop using the product. Switch it off

immediately, unplug it from the power outlet and contact the service center.

- Otherwise, the product may cause fire or electric shock.

•Do not drop an object or impact on the product or screen.

- It can cause injury to human, problem to product and damage the screen.

•If you can smell smoke or other odors or hear a strange sound, unplug the power cord and contact the service center.

- If you continue to use the product without taking proper measures, it may cause electrical shock or fire.

•Do not attempt to disassemble, repair or modify the product yourself. Please contact service center if you need to

repair it.

- Fire or electric shock can occur.

•Do not place objects filled with liquids such as vases, cups etc. on or over the product to prevent liquid from entering

the product.

- Failure to do so may result in fire, electric shock, malfunction or deformation.

•Do not push hard on or scratch the product’s surface with your hands or sharp objects, such as nails, pencils or pens.

Do not shock or scratch the front and sides of the screen with metallic objects.

- This may damage the products and cause it to malfunction.

•Do not touch the product if it has been exposed to sunlight or an intense light because it could be hot.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Señalización digital de otras marcas

SMART-AVI

SMART-AVI SIGNAGEPRO Manual de usuario

KeyWest Technology

KeyWest Technology BREEZE Manual de usuario

XtendLan

XtendLan XL-DSP-183C Manual de usuario

Dynascan

Dynascan DS861LR4 Manual de usuario

Classic Exhibits

Classic Exhibits SEGUE DESIGNS MOD-1363 Manual de usuario

protech

protech KT-7290 Manual de usuario

WebDT

WebDT 515A Instrucciones de montaje

Samsung

Samsung IWJ Series Manual de usuario

EVERI

EVERI Enrollment Kiosk Manual de usuario

NCR

NCR SelfServ 90 Manual

ViewSonic

ViewSonic EP4602 Manual de usuario

ViewSonic

ViewSonic EP3202r Manual de usuario

Samsung

Samsung OM46N Manual de usuario

Viessmann

Viessmann 6336 Manual de usuario

Osram

Osram Traxon Manual de instrucciones de instalación

Philips

Philips Signage Solutions Series BDL4990VL Manual de usuario

ViewSonic

ViewSonic EP5012-L Manual de usuario

Philips

Philips CRD01/00 Manual de usuario
