LG UX 830 Manual de usuario
UX830
QUICK START GUIDE
www.LGUSA.com
Touch
Screen
Transferring
Music
Playing
Music
Bluetooth®
Pairing
Taking a Picture/
Recording a Video
Hold Key
(Unlocks
Touch Screen)
Power/
End Key
Talk Key
Clear &
Back Key
Getting to Know Your Phone
BACK SIDE
FRONT SIDE
LEFT
SIDE
RIGHT
SIDE
Volume Up/Down
(Scrolls Contact List)
USB/
Charging
Port
Headset Jack
Camera Key
Camera
microSDTM
Port
Quick Menu*
Mirror
Flash
Touch Screen
(Adaptive Menu
Interface)
Quick Touch Keys
Menu Dial Messaging Contacts
*Customizable.
Getting to Know Your Phone Touch Screen
Touch Protection
The touch screen is automatically locked when the phone is
closed or after the phone is inactive for 14 seconds (default).
Unlocking the Touch Screen (3 Ways)
• Press the Key on the left side of the phone twice.
• Touch .
• Open the slider.
Using the Touch Screen
• Use the tip of your nger to touch the center
of a touch key.
• It’s not necessary to press hard. A light touch will do.
• Press and drag your nger up or down to scroll.
• You can also scroll using the scroll bar on the right side of the screen. Drag your nger
directly on the bar or touch a section of the bar to quickly jump to off-screen items.
• Touch End at any time to return to the idle screen.
Touch Screen Settings
• Touch Menu > Settings > Sound & Touch. Then scroll down and select
Touch Key Feedback (8) to adjust the touch screen’s sound and vibration.
• If the touch screen is not responding as you expect, calibrate the screen for touch
accuracy. Touch Menu > Settings > Sound & Touch > Touch Calibration (9).
Transferring Music
The fun never has to stop when you’ve got the UX830. Take your
tunes with you! With an optional 4GB microSD card, you can store
up to approximately 960 songs.
1. Insert your microSD card* (gold contacts facing
down) into the memory port underneath the
battery cover.
2. Press the Key twice on the left side of the
phone to unlock the touch screen.
3. The rst time you transfer music, you must format the card.
Touch Menu > Settings > Phone Information >
Memory (5).
4. Touch Card Memory (3) > Format > Yes (1). Then touch
End to exit.
5. Connect the included USB cable from the phone to your PC.
6. The PC will recognize the phone as a Removable Disk and a
screen will appear. Drag and drop music les on your PC into the
My_Music folder.
7. When done, disconnect the phone.
*microSDcardsoldseparately.
Enjoy your favorite songs on the go with the UX830. This sophisticated phone
features an integrated music player with a customizable equalizer. Turn up the volume
and rock out!*
1. Insert a microSD card containing music.
2. Press the Key twice on the left side of the phone to unlock the touch screen.
3. Touch Quick Menu , then Music.†
4. Select a song from one of the categories, then touch Play.
*microSDcardrequired.Soldseparately.
†BasedondefaultQuickMenu.
Note: You can play
music in the back-
ground while doing
other tasks. Once you
have exited the music
player with background
music enabled, touch
the song shown at the
top of the idle screen to
return to the player.
Playing Music
Minimize
(Activates background
music mode and returns
to the idle screen.)
Previous/Rewind
Play/Pause
Volume Up/Down
Back
Library
Next/Fast Forward
Exit
Options
1 Repeat
2 Shufe
3 Background Music
4 Information
Sound Effects
Repeat
Shufe
Bluetooth® Pairing
Forget looking around for that lost cable. With the UX830, you can
connect wirelessly to headsets, speakers, phones and more.
1. Set your Bluetooth accessory into pairing mode.*
2. Press the Key twice on the left side of the phone to unlock
the touch screen.
3. Touch Menu > Settings > Bluetooth > Add New (2).
4. When prompted to turn on Bluetooth, touch Yes (1).
5. Touch Search (1) to begin a new search.
6. Once the Bluetooth device has been found, highlight it
and touch Pair.
7. Enter the PIN code* (typically “0000” – 4 zeroes) and
touch Pair.
8. Touch Yes (1) to connect with the device.
*RefertoyourBluetoothaccessory’susermanualfor
informationaboutinitiatingpairingmodeandthePINcode.
Taking a Picture/Recording a Video
Record the action right as it happens! With the UX830’s 2.0 megapixel
camera/camcorder, you can capture moments in a ash.
Taking a Picture
1. Press the Key twice on the left side of the phone to unlock the touch screen.
2. Rotate the phone horizontally and press and hold the side Key.
3. Refer to the callouts below for options.
4. Press to take the picture. Touch Send to send it to someone.
Recording a Video
1. Press twice on the left side of the phone to unlock the touch screen.
2. Rotate the phone horizontally and press and hold .
3. Touch Record Video , then press the side Key to start or stop recording.
Camerasettingof
1600x1200pixels
doesnotsupport
zoomfunction.
Flash
View Mode
Photo Settings
Settings
Back
Zoom In
Zoom Scroll Bar
Zoom Out
My Image
Record Video
Optional Accessories
Maximize your phone with these cutting-edge accessories at www.LGUSA.com.
Bluetooth Stereo Speakers
Bluetooth Headset (HBM-770)
©2008 LG Electronics, Inc. All rights reserved. All other trademarks are property of their respective owners. All phone images are simulated.
The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license.
Bluetooth Headset (HBM-750)
Bluetooth Stereo Headset
(HBS-200)
Bluetooth Headset (HBM-755)
Vehicle Power Charger
