INSTALLATION MANUAL
Expansion Battery Module
Please read this manual carefully before operating your set and retain it for future
reference.
This guide explains installing the expansion battery module to the ESS battery
unit. Please check which models this expansion battery module can be installed.
https://www.lg.com/global/business/ess/business-resources/download
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
*3103-08503-00*
Rev. 01 14/07/2023
Model
BPEL04KAB-E
Getting Started
2
Safety Information
IMPORTANT : THIS PRODUCT SHOULD NOT BE USED FOR ANY PURPOSE OTHER THAN THE
PURPOSE DESCRIBED IN THIS INSTALLATION MANUAL.
WARNING Indicators for a potentially dangerous situation.
yThere is a high possibility of electric shock or serious burns due to the high voltages in the ESS.
yHigh voltages on DC cables. Do not short circuit positive and negative conductors.
yA potentially hazardous circumstance such as excessive heat or electrolyte mist may occur due to
improper operating conditions, damage, misuse and/or abuse.
yThis product poses potential danger such as death or serious injury by re, high voltages, or
explosion if appropriate precautions are not read, fully understood, and followed.
yDo not place or install ammable or potentially explosive objects near the product or in explosive
atmospheres.
yDo not place objects of any kind on top of the product during operation.
yAll work on the battery installations must be carried out by LG-certied service providers only.
yElectrical installations must be done in accordance with the local and national electrical safety
standards.
yWear rubber gloves and protective clothing (including protective glasses and boots) when installing
the battery module.
yThere is a risk of electric shock. Do not disassemble the battery module. There is no user serviceable
parts inside. Refer servicing to qualied and accredited service technician.
yDo not damage the unit in such ways as drop, deform, impact, cut or spearing with a sharp object. It
may cause electrolyte leakage or re.
yBreakdown of the unit may cause electrolyte leakage or ammable gas generation.
yWhen electrolyte leak out, avoid contact with eyes, skin or clothes. In event of accident, ush with
water and get medical help immediately.
yDo not sit or step on the product or the product package. It may cause serious injury or product
damage.
yDo not smoke or bring open flames near the product.
Getting Started
Getting Started
3
CAUTION Indicates a situation where damage or injury may occur.
yThis product is intended for battery module expansion. Do not use it for any purpose other than
expanding the HBC battery unit.
ySerious injury may occur due to the heavy weight of the product. Therefore, special care must be
taken in handling. Make sure to have at least two persons deliver and move the package.
yThe product should not be exposed to water (dripping or splashing) and no objects lled with
liquids, such as vases, should be placed on the product.
yThe product must be disposed of according to local regulations.
yDo not place heavy objects on this product. It may cause deformation or fracture.
yMake sure the DC switch of the ESS battery unit is switched off before connecting.
yNever use any solvents, abrasives or corrosive materials to clean this product.
yKeep out of reach of children or animals.
yThere should be no foreign object that could damage the bottom of the product.
NOTE Indicates a risk of possible damage to the product.
yDo not store or place any objects on top of or against the product. It may cause serious malfunction
or other problems.
yThis expansion battery module is designed and installable for LG ESS battery unit (BUEL011HBC1)
only. Do not connect this expansion battery module to a device which makes AC voltage such as an
AC power source or a generator. Connecting the product to external devices could result in serious
damage to your equipment.
yHandling of batteries should be performed or supervised by an LG service person or a qualieds
installer.
yThe battery does not discharged when the load is under the certain level.
yFor the latest ESS documents and full Limited Warranty , visit: https://www.lg.com/global/business/
ess/business-resources/download
Getting Started
4
First Aid Measures
The Product includes internal fault mechanisms designed to prevent failures and subsequent risk
hazards. However, LG Electronics cannot the guarantee safety performance of the Product if it is ever
exposed to abuse, damage, or negligence.
If a person is exposed to the internal materials of the battery cell due to damage on the outer casing,
the following actions are recommended.
-In case of inhalation: Leave the contaminated area immediately and seek medical attention.
-In case of contact with eyes: Rinse eyes with running water for 15 minutes and seek medical
attention.
-In case of contact with skin: Wash the contacted area with soap thoroughly and seek medical
attention.
-In case of ingestion: Induce vomiting and seek medical attention.
Fire Fighting Measures
Suitable extinguishing media
Use metal re extinction powder or dry sand if only few cells are involved.
In case of large re, use large amount of water to extinguish or an Lithium re extinguisher to
extinguish.
Special hazards arising from the chemical
May form hydrouoric acid if electrolyte comes into contact with water.
In case of re, the formation of the following ue gases cannot be excluded: Hydrogen uoride (HF),
Carbon monoxide and carbon dioxide.
Protective equipment and precautions for reghters
If batteries are on charge, shut off power.
Wear self-contained breathing apparatus and protective suit.
The battery cell may catch re when heated above 130 °C (266 °F). When the battery module
is burning, it will leak poisonous gases. Do not approach it.
WARNING
Effective way to deal with accidents
-On land: Place the damaged battery into a separate place and call your local re department or
service engineer.
-In water: Stay out of the water and do not touch the product if any part of the battery, inverter, or
wiring is submerged.
-Do not use the submerged battery again. Contact your service engineer for assistance.
5
Table of Contents
Getting Started
Safety Information ..................................................................2
First Aid Measures .....................................................................4
Product Features....................................................................6
Unpacking ..........................................................................7
Unpacking the expansion battery module ...............................................7
Contents of this product ...............................................................8
Name of each part...................................................................9
Installation
Preparation........................................................................10
Check your battery unit ...............................................................10
How to check the charging and discharging cycles......................................10
Energy Storage System settings .......................................................11
Installing an expansion battery module to the battery unit..............................14
Appendix
Maintenance.......................................................................20
Inspecting Regularly...................................................................20
Contact...............................................................................20
Disposing the product .................................................................21
Entsorgung Ihrer Altgeräte ............................................................22
Specifications......................................................................23
Getting Started
6
Product Features
This product is an expansion Lithium-Ion battery module that can be installed in addition to the
existing ESS battery unit. Before installing this expansion battery module to your ESS battery unit,
ensure your ESS battery unit can be expanded.
Contact an authorized dealer or the seller you purchased the system from about whether the
expansion battery module can be installed.
Product Specifications
All specications and descriptions contained in this document are veried to be accurate at the time
of printing. However, since continuous improvement is a goal at LG Electronics, we reserve the right to
make product modications at any time.
The images provided in this document are for demonstration purposes only. Depending on product
version and market region, details may appear slightly different.
©2023 LG Electronics Inc. All rights reserved.
All information in this document is subject to copyright and other intellectual property rights of LG
Electronics Inc. and its licensors. This material may not be modied, reproduced or copied, in whole
or in part, without the prior written permission of LG Electronics Inc. and its licensors. Additional
information is available upon request. The following are trademarks or registered trademarks of LG
Electronics Inc. in the Europe and other countries:
Getting Started
7
Unpacking
Unpacking the expansion battery module
Unpack the expansion battery module from its packaging.
A
Remove the packing tape and open the box.
B
Take out all the accessories and components.
yWhen working on the battery installation, at least 2 people are needed for safe installation
and moving.
yThis product is heavy. Wear appropriate personal protective equipment (such as gloves and
protective footwear) when handling the unit. Only a sufcient number of trained movers
should lift the product.
WARNING
Getting Started
8
Contents of this product
Expansion battery module Installation Manual Nuts (6EA)
Q label
Required Tools
Insulated gloves Safety glasses Protective footwear
200 mm magnet bit holder and
T-Handle torque wrench with
magnet hex socket (M5, M6,
M8)
Screw driver
Phillips (5 mm)
Flat head (6, 5, 4, 2 mm)
Voltmeter
Getting Started
9
Name of each part
A
B
C
ACommunication cable connector
BPower cable connector
C Nuts xing hole
Installation
10
Preparation
Check your battery unit
To secure battery performance and safety, installing an expansion battery module is possible when all
the conditions below are met.
yThe current battery unit is within 200 cycles of charging and discharging.
yThe installation date of the current battery unit is within 18 months.
yIt is recommended to adjust the SOC level of the battery in use to about 30% for fast
expansion.
yThe matching time depends on the voltage difference between the battery in use and the
battery to be expanded. If the voltage difference is large, it may take up to 3 hours.
NOTE
How to check the charging and discharging cycles
To check your battery unit's charging and discharging cycles, your Energy Storage System must be
registered to the EnerVu system. Check the number of cycles through the EnerVu+ app on your
mobile device as described below.
A
Launch the EnerVu+ app on your mobile device.
B
Tap [System Information] and scroll the display to the battery section. You can check the charging
and discharging cycles of the battery unit at [Cycle Count] item.
Installation
