LG TS-C2425DA1 Manual de usuario

Room Air Conditioner

SVC MANUAL(Exploded View)

MODEL : TS-C2425DA1 TS-C2425ML1

CAUTION

Before Servicing the unit, read the safety precautions in General SVC manual.

Only for authorized service personnel.

http://biz.lgservice.com

2Room Air Conditioner

1. Specification

Note:

: Applied, - : No relation

For circuit breaker rating, please conform to local standards wherever necessary.

Some of functions are slightly different depending upon models.

The specification may be subject to change without prior notice for purpose of

improvement.

Product Model TS-C2425DA1

Sales Model SJ242CD

Capacity

Cooling Capacity

Btu/h 24000

Heating Capacity

Btu/h -

Electrical Parts

Voltage. Frequency/Phase

Φ/ V / Hz 1,220V,60Hz

Power Input Cooling W 2560

Heating W -

Running Current Cooling A 12.0

Heating A -

Performance

EER Cooling

Btu/h 9.38

COP Heating

W/W -

Air Circulation

Indoor,Max ㎥/min(cfm) 14.5

Outdoor,Max ㎥/min(cfm) 42

Moisture Removal l/h 2.9

Sound Level

Indoor,H/M/L dB(A)+3 44

Outdoor,Max dB(A)+3 57

Feature

Neo Plasma Air Purifying System N

Anti Corrasion N

Temperature Control Y

CHAOS Wind(Auto Wind) N

Airflow Direction Control(up&down) Auto

Airflow Direction Control(left&right) Manual

Remocon Type Wireless Simple

Setting Temperature Range Cooling 18-30

Heating -

Auto Chage Over N

Auto Clean N

Seps,Fan/Cool 3/4

Temperature Increment

Timer 7Hr,Off

Sleep Operation Y

Restart Delay(Minute) 3

Hot start -

Jet Cool Y

Compressor Type Rotary,TS35N(Mitsubishi)

Installation & Stuffing

Net Dimensions WxHxD mm

1090*314*190/801*555*262

Net Weight Indoor/Outdoor kg 14/51

Service Manual 3

1. Specification

Note:

: Applied, - : No relation

For circuit breaker rating, please conform to local standards wherever necessary.

The specification may be subject to change without prior notice for purpose of

improvement.

Some of functions are slightly different depending upon models.

Product Model TS-C2425ML1

Sales Model SP242CM

Capacity

Cooling Capacity

Btu/h 24000

Heating Capacity

Btu/h -

Electrical Parts

Voltage. Frequency/Phase

Φ/ V / Hz 1,220V,60Hz

Power Input Cooling W 2560

Heating W -

Running Current Cooling A 12.0

Heating A -

Performance

EER Cooling

Btu/h 9.38

COP Heating

W/W -

Air Circulation

Indoor,Max ㎥/min(cfm) 14.5

Outdoor,Max ㎥/min(cfm) 42

Moisture Removal l/h 2.9

Sound Level

Indoor,H/M/L dB(A)+3 44

Outdoor,Max dB(A)+3 57

Feature

Neo Plasma Air Purifying System Y

Anti Corrasion N

Temperature Control Y

CHAOS Wind(Auto Wind) New Chaos

Airflow Direction Control(up&down) Auto

Airflow Direction Control(left&right) Manual

Remocon Type Wireless LCD

Setting Temperature Range Cooling 18-30

Heating -

Auto Chage Over N

Auto Clean N

Seps,Fan/Cool 3/4

Temperature Increment

Timer 7Hr,Off

Sleep Operation Y

Restart Delay(Minute) 3

Hot start -

Jet Cool Y

Compressor Type Rotary,TS35N(Mitsubishi)

Installation & Stuffing

Net Dimensions WxHxD mm

1090*314*190/801*555*262

Net Weight Indoor/Outdoor kg 14/51

4 Room Air Conditioner

2. Piping Diagrams

Indoor Unit Outdoor Unit

Heat

Exchanger

(Evaporator)

Heat

Exchanger

(Condenser)

Capillary Tube

Compressor

Accumulator

Gas Side

3-Way Valve

2-Way Valve

Liquid Side

Cooling

High Pressure S/W

Th1

Th2

rotcennoCBCPnoitpircseD.COL

Th1 Thermistor for indoor air temperature CN-TH1

Th2 Thermistor for evaporating temperature

TINUROODTUOTINUROODNI

HEAT

EXCHANGE

(EVAPORATOR)

HEAT

EXCHANGE

(CONDENSER)

COMPRESSOR

ACCUMU

LATOR

GAS SIDE

3-WAY VALVE

LIQUID SIDE

3-WAY VALVE

CAPILLARY TUBE

CHECK VALVE

(Heating Model only)

COOLING

HEATING

REVERSING

VALVE

(Heating Model Only)

(2) Cooling & Heating Models

Service Manual 5

3. Wiring Diagrams

TS-C2425ML1

Outdoor Unit

TS-C2425DA1

YELLOW

RED

CAPACITOR

HCF

BLUE

RED

BLUE

YELLOW

OVERLOAD

PROTECT

2(N)

BLUE

/GREEN

BLUE

BROWN BROWN

1(L)

THE UNIT INDOOR

OUTDOOR DIAGRAM WIRING

TERMINAL BLOCK

EBY36312302

FAN

Exploded View

6 Room Air Conditioner

1. Indoor Unit

135313

342800

359011

131410 733010

135316

135311

147581

268711C

146811

346810

W0CZZ

135516

35211B

354210

249951267110

352116

352115

152302

135301

135511

147582-1

147582-2

435301

352150

268711A

354212

W6640

264110

263230

149303

Outdoor Unit

6Room Air Conditioner

Exploded View

554031

435512

437212

435511

554160

550140

552203-1

552203-2

430410

447910

649950

552111

552112

437210

435301

559010

546810

549610

W0CZZ

430400

W6640

148000

P/NO : MFL58884505 SEP, 2008
