Air Conditioner

INSTALLATION MANUAL

website http://www.lgservice.com

e-mail http://www.lgeservice.com/techsup.html

IMPORTANT

• Please read this installation manual completely before

installing the product.

• When the power cord is damaged, replacement work shall

be performed by authorized personnel only.

• Installation work must be performed in accordance with

the national wiring standards by authorized personnel

only.

2Room Air Conditioner

Multi Air Conditioner Installation Manual

TABLE OF CONTENTS

The following should be

always observed for

safety................................4~6

Installation of Indoor,

Outdoor Unit....................7~9

Flaring work and piping

connection...................10~14

Connecting the Cable

between Indoor Unit and

Outdoor Unit................15~16

CheckingtheDrainageand

Forming the Pipings ...17~18

Vacuum ........................19~20

Test running.......................21

Installation

Requirements Required Parts Required Tools

❏Installation guide map

❏Four Type “A” screws & plastic

anchors

❏Connecting cable

❏Level gauge

❏Screw driver

❏Electric drill

❏Hole core drill (ø50mm)

❏Horizontal meter

❏Pipes: Gas side..........1/2", 3/8"

Liquid side................1/4"

(Refer to page 7)

❏Insulation materials

❏Additional drain pipe

(Inner Diameter..............20mm)

❏Flaring Tools set

❏Specifiedtotorquewrenches

1.8kg.m, 4.2kg.m, 5.5kg.m,

6.6kg.m (different depending on

model No.)

❏Spanner....................Half union

❏A glass of water

❏Screw driver

❏Hexagonal Wrench (4mm)

❏Gas-leak Detector

❏Vacuum pump

❏Gauge manifold

❏Two type "B" screws ❏Owner's manual

❏Thermometer

❏Holder Remote Control

Installation Parts Provided

Installation Manual 3

ENGLISH

Installation Parts Provided

Type "A" screws and plastic anchors

Type "B" screws Holder Remote Control

Installation plate

Standard Type

(Side)

(Rear)

Air intake

vents

Air outlet vents

Piping

Drain hose

Control cover

Connecting wire

(Side)

(Rear)

Air intake

vents

Air outlet vents

Piping

Drain hose

Control cover

Connecting wire

48K Btu/h

60K Btu/h

4Room Air Conditioner

Safety Precautions

To prevent injury to the user or other people and property damage, the following instructions

must be followed.

■

Incorrect operation due to ignoring instruction will cause harm or damage.The

seriousness is classified by the following indications.

■Meanings of symbols used in this manual are as shown below.

WARNING

CAUTION

This symbol indicates the possibility of death or serious injury.

This symbol indicates the possibility of injury or damage.

WARNING

Be sure not to do.

Be sure to follow the instruction.

■Installation

Install the panel and the cover of

control box securely.

•There is risk of fire or

electric shock.

Always install a dedicated

circuit and breaker.

•Improper wiring or

installation may cause fire or

electric shock

Use the correctly rated breaker

or fuse.

•There is risk of fire or

electric shock.

Do not use a defective or

underrated circuit breaker. Use

this appliance on a dedicated

circuit.

•There is risk of fire or

electric shock.

For electrical work, contact the

dealer, seller, a qualified

electrician, or an Authorized

Service Center.

•

Do not disassemble or repair

the product.There is risk of

fire or electric shock.

Always ground the product.

•There is risk of fire or

electric shock.

ENGLISH

Installation Manual 5

Safety Precautions

Do not modify or extend the power cable.

•There is risk of fire or electric shock.

Be cautious when unpacking and installing the

product.

•

Sharp edges could cause injury. Be especially

careful of the case edges and the fins on the

condenser and evaporator.

For installation, always contact the dealer or an

Authorized Service Center.

•There is risk of fire, electric shock, explosion,

or injury.

Do not install the product on a defective

installation stand.

•It may cause injury, accident, or damage to

the product.

Be sure the installation area does not

deteriorate with age.

•

If the base collapses, the air conditioner could fall with

it, causing property damage, product failure, and

personal injury.

Do not let the air conditioner run for a long time when

thehumidityisveryhighandadoororawindowis

left open.

•Moisture may condense and wet or damage

furniture.

Do not store or use flammable gas or combustibles

near the product.

•There is risk of fire or failure of product.

■Operation

Gasolin

6Room Air Conditioner

Safety Precautions

Always check for gas (refrigerant) leakage after

installation or repair of product.

•Low refrigerant levels may cause failure of

product.

Install the drain hose to ensure that water is

drained away properly.

•A bad connection may cause water leakage.

Keep level even when installing the product.

•To avoid vibration or water leakage.

Do not install the product where the noise or hot air

from the outdoor unit could damage the

neighborhoods.

•It may cause a problem for your neighbors.

Use two or more people to lift and transport the

product.

•Avoid personal injury.

Do not install the product where it will be

exposed to sea wind (salt spray) directly.

•It may cause corrosion on the product.

Corrosion, particularly on the condenser and

evaporator fins, could cause product

malfunction or inefficient operation.

CAUTION

90°

■Installation

Installation Manual 7

ENGLISH

Installation of Indoor, Outdoor Unit

Read completely, then follow step by step.

Indoor unit

1. Do not have any heat or steam near the unit.

2.Selectaplacewheretherearenoobstacles

infrontoftheunit.

3. Make sure that condensation drainage can be

conveniently routed away.

4. Do not install near a doorway.

5. Ensure the spaces indicated by arrows from

the wall, ceiling, fence or other obstacles.

6. Use a stud finder to locate studs to prevent

unnecessary damage to the wall.

Outdoor unit

1. If an awning is built over the unit to prevent

direct sunlight or rain exposure, make sure

that heat radiation from the condenser is not

restricted.

2. Ensure that the spaces indicated by arrows

around front, back and side of the unit.

3. Do not place animals and plants in the path

of the warm air.

4.Take the air conditioner weight into account

and select a place where noise and vibration

are minimum.

5. Select a place so that the warm air and noise

from the air conditioner do not disturb

neighbors.

Rooftop Installations:

If the outdoor unit is installed on a roof

structure, be sure to level the unit. Ensure the

roof structure and anchoring method are

adequate for the unit location. Consult local

codes regarding rooftop mounting.

Select the best location

More than 5cm

More than

5cm

More than 2.3m More than

5cm

More than 120cm

More than

90cm

More than 90cm

More than

90cm

Fence or

obstacles

Fence or

obstacles

Fence or

obstacles

CAUTION: Install the indoor unit

on the wall where the height from

thefloorsmorethan2.3meters.

8Room Air Conditioner

Installation of Indoor, Outdoor Unit

Multi Piping Type (m)

Piping length and elevation

48k 15+15=30 30 10 10

60k 15+15=30 30 10 10

Outdoor Capacity

(Btu/h) Total Length

(m) Max Length(A/B)

(m) Max Elevation (h1)

(m)

In - In Elevation (h2)

(m)

12k 1/2" 1/4" 7.5 30

24k 5/8" 3/8" 7.5 30

Indoor Capacity

(Btu/h)

Pipe Size

Gas Liquid

Standard Length Additional Refrigerant

(m) (g/m)

CAUTION: Capacity is based on standard length and maximum allowance

length is on the basis of reliability. Oil trap should be installed every 5~7

meters.

Installation Manual 9

ENGLISH

Installation of Indoor, Outdoor Unit

The wall you select should be strong and solid

enough to prevent vibration

1. Mount the installation plate on the wall with

type "A" screws. If mounting the unit on a

concrete wall, use anchor bolts.

•Mount the installation plate horizontally by

aligning the centerline using a level.

2. Measure the wall and mark the centerline. It

is also important to use caution concerning

the location of the installation plate-routing

of the wiring to power outlets is through the

walls typically. Drilling the hole through the

wall for piping connections must be done

safely.

How to fix installation plate

Installation Plate

Type "A" screw

Installation plate

Ø70mm

Left rear piping Right rear piping

AØ70mm

(SR, ST)

SR(9k~12k) 0 40 20 40

ST(18k~24k) 105 0 210 0

CHASSIS (Grade) Distance (mm)

ABCD

10 Room Air Conditioner

Flaring Work Piping Connection

Flaring work

Main cause for gas leakage is due to defect in flaring work. Carry out correct flaring work in the

following procedure.

Cut the pipes and the cable.

1. Use the piping kit accessory or the pipes

purchased locally.

2. Measure the distance between the indoor and

the outdoor unit.

3. Cut the pipes a little longer than measured

distance.

Cut the cable 1.5m longer than the pipe length.

Burrs removal

1. Completely remove all burrs from the cut cross

section of pipe/tube.

2. Put the end of the copper tube/pipe in a

downward direction as you remove burrs in

order to avoid dropping burrs into the tubing.

Putting nut on

•Remove flare nuts attached to indoor and

outdoor unit, then put them on pipe/tube having

completed burr removal.

(not possible to put them on after flaring work)

Flaring work

•Carry out flaring work using flaring tool as shown

below.

•Firmly hold copper pipe in a die in the dimension

showninthetableabove.

Copper

pipe

90°Slanted Uneven Rough

Pipe Reamer

Point down

Flare nut

Copper tube

mm inch mm

Ø6.35 1/4 0~0.5

Ø9.52 3/8 0~0.5

Ø12.7 1/2 0~0.5

Ø15.88 5/8 0~1.0

Outside diameter A

Bar

Copper pipe

Clamp handle Red arrow mark

Cone

Yoke

Handle

Bar

"A"

Tabla de contenidos

Otros manuales de Acondicionador de aire de LG

LG LS090HYV Manual de usuario

LG URNU18GVJA2 Manual de usuario

LG ARUN040GSS0 Manual de usuario

LG A2UQ18GFD0 Guía de inicio rápido

LG Multi V ARNU073B3G2 Manual de usuario

LG LS090HSV4 Manual de usuario

LG LS091HSV3 Manual de usuario

LG TPNC306SLA1 Manual de usuario

LG ARNU243BHA2 Manual de usuario

LG V-NET PDRYCB400 Manual de usuario

LG ATNQ48GMLE2 Manual de usuario

LG HSNC126B4A5 Manual de usuario

LG Art Cool Mirror Inverter Manual de instalación y operación

LG LW5012J Manual de usuario

LG 457645 Manual de usuario

LG BECON PACP4B001 Instrucciones de funcionamiento

LG T05NL Manual de usuario

LG UT30R Manual de usuario

LG URNU76GB8A2 Manual de usuario

LG Multi V ARNU07GTJ 2 Series Manual de usuario

LG LTUH186ELE1 Manual de usuario

LG L8010ER Manual de usuario

LG UHXM120BA1 Manual de usuario

LG VR122C7 NJP8 Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
