iPECS is an Ericsson-LG Brand
Please read this manual carefully before
operating your set. Retain it for future reference.
ES-2024G / ES-2024GP
Installation Manual
I
NSTALLATION
M
ANUAL
ES-2024G/2024GP
ES-2024G ADVANCED SMART 24-PORT GE SWITCH
Layer 2 Advanced Smart Switch
with 24 10/100/1000BASE-T (RJ-45) Ports,
and 4 shared Gigabit Combination Ports (SFP)
ES-2024GP ADVANCED SMART 24-PORT GE POE SWITCH
Layer 2 Advanced Smart Switch
with 24 10/100/1000BASE-T (RJ-45) PoE Ports,
and 4 shared Gigabit Combination Ports (SFP)
ES-2024G / ES-2024GP
E012013-AP-R01
150200000590A
– 3 –
ES-2024G/2024GP
COMPLIANCES AND SAFETY STATEMENTS
FCC CLASS A
This device complies with Part 15 rules. Operation is subject to the
following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
You are cautioned that changes or modifications not expressly approved by
the party responsible for compliance could void your authority to operate
the equipment.
You may use unshielded twisted-pair (UTP) for RJ-45 connections -
Category 3 or better for 10 Mbps connections, Category 5 or better for 100
Mbps connections, Category 5, 5e, or 6 for 1000 Mbps connections. For
fiber optic connections, you may use 50/125 or 62.5/125 micron
multimode fiber or 9/125 micron single-mode fiber.
INDUSTRY CANADA - CLASS A
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus as set out in the interference-causing
equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques
applicables aux appareils numériques de Classe A prescrites dans la norme
sur le matériel brouilleur: “Appareils Numériques,” NMB-003 édictée par le
ministère des Communications.
C
OMPLIANCES
– 4 –
ES-2024G/2024GP
CE MARK DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC)
This information technology equipment complies with the requirements of
the Council Directive 2004/108/EC on the Approximation of the laws of the
Member States relating to Electromagnetic Compatibility and 2006/95/EC
for electrical equipment used within certain voltage limits and the
Amendment Directive 93/68/EEC. For the evaluation of the compliance
with these Directives, the following standards were applied:
The following declaration is for two models:
RFI Emission: ◆Limit class A according to EN 55022:2006+A1:2007
◆Limit class A for harmonic current emission
according to EN 61000-3-2/2006
◆Limitation of voltage fluctuation and flicker in low-
voltage supply system according to EN 61000-3-3/
1995+A2:2005
Immunity: ◆Product family standard according to EN
55024:1998+A2:2003
◆Electrostatic Discharge according to IEC 61000-4-
2:1995+A: 1998+A2:2000 (Contact Discharge: ±4
kV, Air Discharge: ±8 kV)
◆Radio-frequency electromagnetic field according to
IEC 61000-4-3:2006 (80 - 1000 MHz with 1 kHz AM
80% Modulation: 3 V/m)
◆Electrical fast transient/burst according to IEC
61000-4-4:2004
(AC/DC power supply: ±1 kV, Data/Signal lines:
±0.5 kV)
◆Surge immunity test according to IEC 61000-4-
5:2005
(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2
kV)
◆Immunity to conducted disturbances, Induced by
radio-frequency fields: IEC 61000-4-6:2006 (0.15 -
80 MHz with 1 kHz AM 80% Modulation: 3 V/m)
◆Voltage dips, short interruptions and voltage
variations immunity test according to IEC 61000-4-
11:2004 (>95% Reduction @10 ms, 30% Reduction
@500 ms, >95% Reduction @5000 ms)
LVD: ◆EN 60950-1:2006+A11:2009
C
OMPLIANCES
– 5 –
ES-2024G/2024GP
SAFETY COMPLIANCE
SAFETY INSTRUCTION
This product complies with and conforms to the following international
Product Safety standards as applicable:
◆Safety of Information Technology Equipment, IEC(EN) 60950-1,
including all relevant national deviations as listed in Compliance with
IEC for Electrical Equipment (IECEE)
◆Safety of Information Technology Equipment, CAN/CSA-C22.2 No.
60950-1/UL 60950-1
POWER CORD SAFETY
Please read the following safety information carefully before installing the
switch:
WARNING: Installation and removal of the unit must be carried out by
qualified personnel only.
◆The unit must be connected to an earthed (grounded) outlet to comply
with international safety standards.
◆Do not connect the unit to an A.C. outlet (power supply) without an
earth (ground) connection.
◆The appliance coupler (the connector to the unit and not the wall plug)
must have a configuration for mating with an EN 60320/IEC 320
appliance inlet.
◆The socket outlet must be near to the unit and easily accessible. You
can only remove power from the unit by disconnecting the power cord
from the outlet.
◆This unit operates under SELV (Safety Extra Low Voltage) conditions
according to IEC 60950. The conditions are only maintained if the
equipment to which it is connected also operates under SELV
conditions.
France and Peru only
This unit cannot be powered from IT† supplies. If your supplies are of IT
type, this unit must be powered by 230 V (2P+T) via an isolation
transformer ratio 1:1, with the secondary connection point labelled
Neutral, connected directly to earth (ground).
† Impédance à la terre
Important! Before making connections, make sure you have the correct
cord set. Check it (read the label on the cable) against the following:
C
OMPLIANCES
– 6 –
ES-2024G/2024GP
Veuillez lire à fond l'information de la sécurité suivante avant d'installer le
Switch:
AVERTISSEMENT: L’installation et la dépose de ce groupe doivent être
confiés à un personnel qualifié.
◆Ne branchez pas votre appareil sur une prise secteur (alimentation
électrique) lorsqu'il n'y a pas de connexion de mise à la terre (mise à la
masse).
◆Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la
masse) afin de respecter les normes internationales de sécurité.
◆Le coupleur d’appareil (le connecteur du groupe et non pas la prise
murale) doit respecter une configuration qui permet un branchement
sur une entrée d’appareil EN 60320/IEC 320.
◆La prise secteur doit se trouver à proximité de l’appareil et son accès
doit être facile. Vous ne pouvez mettre l’appareil hors circuit qu’en
débranchant son cordon électrique au niveau de cette prise.
◆L’appareil fonctionne à une tension extrêmement basse de sécurité qui
est conforme à la norme IEC 60950. Ces conditions ne sont maintenues
Power Cord Set
U.S.A. and
Canada The cord set must be UL-approved and CSA certified.
The minimum specifications for the flexible cord are:
- No. 18 AWG - not longer than 2 meters, or 16 AWG.
- Type SV or SJ
- 3-conductor
The cord set must have a rated current capacity of at
least 10 A
The attachment plug must be an earth-grounding type
with NEMA 5-15P (15 A, 125 V) configuration.
Denmark The supply plug must comply with Section 107-2-D1,
Standard DK2-1a or DK2-5a.
Switzerland The supply plug must comply with SEV/ASE 1011.
U.K. The supply plug must comply with BS1363 (3-pin 13 A)
and be fitted with a 5 A fuse which complies with
BS1362.
The mains cord must comply with IEC 60227
(designation
60227 IEC 52).
Europe The supply plug must comply with CEE7/7 (“SCHUKO”).
The mains cord must comply with IEC 60227
(designation
60227 IEC 52).
IEC-320 receptacle.
C
OMPLIANCES
– 7 –
ES-2024G/2024GP
que si l’équipement auquel il est raccordé fonctionne dans les mêmes
conditions.
France et Pérou uniquement:
Ce groupe ne peut pas être alimenté par un dispositif à impédance à la
terre. Si vos alimentations sont du type impédance à la terre, ce groupe
doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un
transformateur d’isolement à rapport 1:1, avec un point secondaire de
connexion portant l’appellation Neutre et avec raccordement direct à la
terre (masse).
Bitte unbedingt vor dem Einbauen des Switches die folgenden
Sicherheitsanweisungen durchlesen:
WARNUNG: Die Installation und der Ausbau des Geräts darf nur durch
Fachpersonal erfolgen.
◆Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose
angeschlossen werden.
◆Das Gerät muß an eine geerdete Steckdose angeschlossen werden,
welche die internationalen Sicherheitsnormen erfüllt.
◆Der Gerätestecker (der Anschluß an das Gerät, nicht der
Wandsteckdosenstecker) muß einen gemäß EN 60320/IEC 320
konfigurierten Geräteeingang haben.
Cordon électrique - Il doit être agréé dans le pays d’utilisation
Etats-Unis et
Canada: Le cordon doit avoir reçu l’homologation des UL et un
certificat de la CSA.
Les spécifications minimales pour un cable flexible
sont AWG No. 18, ouAWG No. 16 pour un cable de
longueur inférieure à 2 mètres.
- type SV ou SJ
- 3 conducteurs
Le cordon doit être en mesure d’acheminer un
courant nominal d’au moins 10 A.
La prise femelle de branchement doit être du type à
mise à la terre (mise à la masse) et respecter la
configuration NEMA 5-15P (15 A, 125 V).
Danemark: La prise mâle d’alimentation doit respecter la section
107-2 D1 de la norme DK2 1a ou DK2 5a.
Suisse: La prise mâle d’alimentation doit respecter la norme
SEV/ASE 1011.
Europe La prise secteur doit être conforme aux normes CEE
7/7 (“SCHUKO”)
Le cordon d'alimentation doit être conforme à la
norme IEC 60227 (IEC 60227 désignation 52)
C
OMPLIANCES
– 8 –
ES-2024G/2024GP
◆Die Netzsteckdose muß in der Nähe des Geräts und leicht zugänglich
sein. Die Stromversorgung des Geräts kann nur durch Herausziehen
des Gerätenetzkabels aus der Netzsteckdose unterbrochen werden.
◆Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen
(Sicherheitskleinstspannung) gemäß IEC 60950. Diese Bedingungen
sind nur gegeben, wenn auch die an das Gerät angeschlossenen Geräte
unter SELV-Bedingungen betrieben werden.
WARNINGS AND CAUTIONARY MESSAGES
W
ARNING
:
This product does not contain any serviceable user parts.
W
ARNING
:
Installation and removal of the unit must be carried out by
qualified personnel only.
W
ARNING
:
When connecting this device to a power outlet, connect the field
ground lead on the tri-pole power plug to a valid earth ground line to
prevent electrical hazards.
W
ARNING
:
This switch uses lasers to transmit signals over fiber optic cable.
The lasers are compliant with the requirements of a Class 1 Laser Product
and are inherently eye safe in normal operation. However, you should
never look directly at a transmit port when it is powered on.
C
AUTION
:
Wear an anti-static wrist strap or take other suitable measures to
prevent electrostatic discharge when handling this equipment.
C
AUTION
:
Do not plug a phone jack connector in the RJ-45 port. This may
damage this device.
C
AUTION
:
Use only twisted-pair cables with RJ-45 connectors that conform
to FCC standards.
ENVIRONMENTAL STATEMENTS
The manufacturer of this product endeavours to sustain an
environmentally-friendly policy throughout the entire production process.
This is achieved though the following means:
◆Adherence to national legislation and regulations on environmental
production standards.
◆Conservation of operational resources.
Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden:
Schweiz Dieser Stromstecker muß die SEV/ASE
1011Bestimmungen einhalten.
Europe Das Netzkabel muss mit IEC 60227 (IEC 60227
entsprechen Bezeichnung 52)
Der Netzstecker muß die Norm CEE 7/7 erfüllen
(”SCHUKO”).
C
OMPLIANCES
– 9 –
ES-2024G/2024GP
◆Waste reduction and safe disposal of all harmful un-recyclable by-
products.
◆Recycling of all reusable waste content.
◆Design of products to maximize recyclables at the end of the product’s
life span.
◆Continual monitoring of safety standards.
END OF PRODUCT LIFE SPAN
This product is manufactured in such a way as to allow for the recovery and
disposal of all included electrical components once the product has reached
the end of its life.
MANUFACTURING MATERIALS
There are no hazardous nor ozone-depleting materials in this product.
DOCUMENTATION
All printed documentation for this product uses biodegradable paper that
originates from sustained and managed forests. The inks used in the
printing process are non-toxic.
– 10 –
ES-2024G/2024GP
ABOUT THIS GUIDE
PURPOSE This guide details the hardware features of the switches, including the
physical and performance-related characteristics, and how to install the
switches.
AUDIENCE The guide is intended for use by network administrators who are
responsible for installing and setting up network equipment; consequently,
it assumes a basic working knowledge of LANs (Local Area Networks).
CONVENTIONS The following conventions are used throughout this guide to show
information:
N
OTE
:
Emphasizes important information or calls your attention to related
features or instructions.
C
AUTION
:
Alerts you to a potential hazard that could cause loss of data, or
damage the system or equipment.
W
ARNING
:
Alerts you to a potential hazard that could cause personal injury.
RELATED PUBLICATIONS The following publication gives specific information on how to operate and
use the management functions of the switch:
The User Manual
Also, as part of the switch’s software, there is an online web-based help
that describes all management related features.
REVISION HISTORY This section summarizes the changes in each revision of this guide.
JANUARY 2013 REVISION
This is the first revision of this guide.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Cambiar de LG-Ericsson
LG-Ericsson
LG-Ericsson ES-2010GP Manual de usuario
LG-Ericsson
LG-Ericsson ipecs ES-5048XG Manual de usuario
LG-Ericsson
LG-Ericsson iPECS ES-4550G Manual de usuario
LG-Ericsson
LG-Ericsson iPECS ES-4550G Manual de usuario
LG-Ericsson
LG-Ericsson iPECS ES-2026P Manual de usuario
LG-Ericsson
LG-Ericsson EZ Switch SMC-EZ1016DT Manual de usuario
