1. NAVIGATION OPERATION

1. Remote Touch

1. NAVIGATION OPERATION

QUICK GUIDE

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

No. Name Function Page

“MENU” button Press to display the “Menu” screen. 22

“ · ” button Press to change the scale of the map and to scroll

the list screen. 33, 36, 48

“MAP/VOICE”

button

Press to repeat a voice guidance, cancel the

screen scroll, start guidance, and display the cur-

rent position.

Remote Touch

knob

Move in the desired direction to select a function,

letter and map screen button.

Press to enter the selected function, letter or map

screen button.

1. NAVIGATION OPERATION

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

2. MAP SCREEN

No. Name Function Page

North-up or

heading-up

symbol

This symbol indicates whether the map orienta-

tion is set to north-up or heading-up. Selecting this

symbol changes the map orientation. Both north-

up and heading-up symbols display the vehicles

direction as a letter (e.g. N for north).

Scale indicator This figure indicates the map scale. 48

Zoom out button Select to reduce the map scale. 48

“WW Off”

Select to obtain a broader view. Some of the but-

tons on the screen will not be displayed. They are

displayed again by selecting “On XX”.

130

“Mark” Select to register the current position or the cur-

sor position as an address book entry. 41

1. NAVIGATION OPERATION

QUICK GUIDE

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

*: Press and hold the “PWR·VOL” knob for 3 seconds or more to turn off the screen and restart the

navigation system. Do this when the vehicle-mounted device response is extremely slow.

“Route” Select to change the route. 97, 99

“Show on Map”

Select to browse information about guidance

route, to set the POI (Point of Interest) icons to be

displayed on the screen, to record the route, etc.

104, 342,

367

Zoom in button Select to magnify the map scale. 48

Foot print map

button

Select to display the foot print map and the build-

ing information. 48

“Map Mode” Select to display the “Map Mode” screen. 45

Distance and

time to destina-

tion

Select to display the distance, estimated travel

and arrival time to the destination. 96

XM indicator This mark is displayed when XM information is re-

ceived. 340, 342

“GPS” mark

(Global Position-

ing System)

Whenever the vehicle is receiving signals from the

GPS, this mark is displayed. 139

INFORMATION

●Remove dirt from the display and its surrounding area by lightly wiping with a soft, dry cloth,

such as a cloth used for cleaning glasses with plastic lenses. Scrubbing too hard or using a

hard cloth could scratch the display. Also, the display is treated with a coating, and could be

damaged by coming into contact with benzine or alkaline solution.

●When the screen is viewed through polarized sunglasses, a rainbow pattern may appear on

the screen due to optical characteristics of the screen. If this is disturbing, please operate

the screen without polarized sunglasses.

No. Name Function Page

1. NAVIGATION OPERATION

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

3. REGISTERING HOME

Press the “MENU” button on the

Remote Touch.

Select “Destination” and press the

Remote Touch knob.

Select “Go Home” and press the

Remote Touch knob.

If a home address has not been regis-

tered, it can be registered by selecting

“Go Home”.

Select “Yes” and press the Remote

To u c h k n o b .

There are 4 different methods to

searchyour home. (See “DESTINA-

TION SEARCH” on page 68.)

Select “Enter” and press the

Remote Touch knob.

The “Edit Home” screen is displayed.

1. NAVIGATION OPERATION

QUICK GUIDE

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

Select “OK” and press the Remote

To u c h k n o b .

Registration of home is complete.

Home can also be registered by selecting

“Navigation” on the “Setup” screen. (See

“REGISTERING HOME” on page 109.)

The name, location, phone number and

icon can be changed. (See “EDITING

HOME” on page 110.)

The registered points can be used on the

“Destination” screen. (See “DESTINA-

TION SEARCH BY HOME” on page

69.)

1. NAVIGATION OPERATION

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

4. REGISTERING PRESET DESTINATIONS

Press the “MENU” button on the

Remote Touch.

Select “Destination” and press the

Remote Touch knob.

Select one of the preset destination

buttons and press the Remote

To u c h k n o b .

A preset destination can be set to any pre-

set destination button that has not yet

been set.

Select “Yes” and press the Remote

To u c h k n o b .

There are 4 different methods to

search preset destinations. (See

“DESTINATION SEARCH” on

page 68.)

Select “Enter” and press the

Remote Touch knob.

The “Edit Preset Destination” screen is

displayed.

1. NAVIGATION OPERATION

QUICK GUIDE

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

Select “OK” and press the Remote

To u c h k n o b .

Registration of preset destinations is com-

plete.

Preset destinations can also be registered

by selecting “Navigation” on the “Setup”

screen. (See “REGISTERING PRESET

DESTINATIONS” on page 112.)

The name, location, phone number and

icon can be changed. (See “EDITING

PRESET DESTINATIONS” on page 113.)

The registered points can be used on the

“Destination” screen. (See “DESTINA-

TION SEARCH BY PRESET DESTINA-

TIONS” on page 69.)

1. NAVIGATION OPERATION

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

5. OPERATION FLOW: GUIDING THE ROUTE

Press the “MENU” button on the

Remote Touch.

Select “Destination” and press the

Remote Touch knob.

There are 11 different methods to

search destinations. (See “DESTI-

NATION SEARCH” on page 68.)

XPage 1

XPage 2

Select “Go to ” and press the

Remote Touch knob.

The navigation system performs a search

for the route.

Select “OK” and press the Remote

Touch knob. Then start driving.

Routes other than the one recommended

can also be selected. (See “STARTING

ROUTE GUIDANCE” on page 87.)

Guidance to the destination is displayed

on the screen and can be heard via voice

guidance.

1. NAVIGATION OPERATION

QUICK GUIDE

ES350/300h_Navi_OM33A07U_(U)

12.05.11 08:14

6. SETTING HOME AS THE DESTINATION

Press the “MENU” button on the

Remote Touch.

Select “Destination” and press the

Remote Touch knob.

Select “Go Home” and press the

Remote Touch knob.

“Go Home” can be used if your home ad-

dress has been registered. (To register

home, see “REGISTERING HOME” on

page 109.)

Your home address is set as the destina-

tion. The navigation system performs a

search for the route.

Select “OK” and press the Remote

Touch knob. Then start driving.

Routes other than the one recommended

can also be selected. (See “STARTING

ROUTE GUIDANCE” on page 87.)

Guidance to the destination is displayed

on the screen and can be heard via voice

guidance.
