Lexmark MS810 Series Guía de referencia rápida

Media Guide

The printer supports the following paper and specialty media sizes. Select custom sizes up to the maximum measurements

specified for the Universal setting.

Paper sizes supported by the printer

Paper size1Dimensions Standard or

optional 250‑or

550‑sheet trays

Optional

2100‑sheet tray

Multipurpose

feeder

Duplex

A4 210 x 297 mm

(8.3 x 11.7 in.)

A5 148 x 210 mm

(5.8 x 8.3 in.)

A6 105 x 148 mm

(4.1 x 5.8 in.)

JIS B5 182 x 257 mm

(7.2 x 10.1 in.)

Letter 216 x 279 mm

(8.5 x 11 in.)

Legal 216 x 356 mm

(8.5 x 14 in.)

Executive 184 x 267 mm

(7.3 x 10.5 in.)

Oficio 216 x 340 mm

(8.5 x 13.4 in.)

Folio 216 x 330 mm

(8.5 x 13 in.)

Statement 140 x 216 mm

(5.5 x 8.5 in.)

Universal2105 x 148 mm to 216

x 356 mm (4.13 x

5.83 in. to 8.5 x 14 in.)

70 x 127 mm to

216 x 356 mm

(2.76 x 5 to 8.5 x 14 in.)

XX X

7 3/4 Envelope (Monarch) 98 x 191 mm

(3.9 x 7.5 in.)

X X

9 Envelope 98 x 225 mm

(3.9 x 8.9 in.)

X X

1If your preferred default paper size cannot be set in the printer control panel, then you may select common paper sizes that

correspond to the position of the length guide in the tray from the Paper Size/Type menu. If the paper size is not available, then select

Universal or turn off tray size sensing. For more information, contact customer support.

2To support two‑sided (duplex) printing, the Universal width must be between 105 mm (4.13 inches) and 216 mm (8.5 inches); the

Universal length must be between 148 mm (5.83 inches) and 356 mm (14 inches).

Media Guide

Page 1 of 4

Paper size1Dimensions Standard or

optional 250‑or

550‑sheet trays

Optional

2100‑sheet tray

Multipurpose

feeder

Duplex

10 Envelope 105 x 241 mm

(4.1 x 9.5 in.)

X X

DL Envelope 110 x 220 mm

(4.3 x 8.7 in.)

X X

C5 Envelope 162 x 229 mm

(6.38 x 9.01 in.)

X X

B5 Envelope 176 x 250 mm

(6.93 x 9.84 in.)

X X

Other Envelope 98 x 162 mm

(3.9 x 6.4 in.) to

176 x 250 mm

(6.9 x 9.8 in.)

X X

1If your preferred default paper size cannot be set in the printer control panel, then you may select common paper sizes that

correspond to the position of the length guide in the tray from the Paper Size/Type menu. If the paper size is not available, then select

Universal or turn off tray size sensing. For more information, contact customer support.

2To support two‑sided (duplex) printing, the Universal width must be between 105 mm (4.13 inches) and 216 mm (8.5 inches); the

Universal length must be between 148 mm (5.83 inches) and 356 mm (14 inches).

Storing paper

Use these paper storage guidelines to help avoid jams and uneven print quality:

•For best results, store paper where the temperature is 21°C (70°F) and the relative humidity is 40%. Most label manufacturers

recommend printing in a temperature range of 18 to 24°C (65 to 75°F) with relative humidity between 40 and 60%.

•Store paper in cartons when possible, on a pallet or shelf, rather than on the floor.

•Store individual packages on a flat surface.

•Do not store anything on top of individual paper packages.

Avoiding jams

Load paper properly

•Make sure paper lies flat in the tray.

Media Guide

Page 2 of 4

Correct loading of paper Incorrect loading of paper

•Do not remove a tray while the printer is printing.

•Do not load a tray while the printer is printing. Load it before printing, or wait for a prompt to load it.

•Do not load too much paper. Make sure the stack height is below the maximum paper fill indicator.

•Do not slide the paper into the tray. Load paper as shown in the illustration.

•Make sure the guides in the tray or the multipurpose feeder are properly positioned and are not pressing tightly against the

paper or envelopes.

•Push the tray firmly into the printer after loading paper.

Use recommended paper

•Use only recommended paper or specialty media.

•Do not load wrinkled, creased, damp, bent, or curled paper.

Media Guide

Page 3 of 4

•Flex and straighten paper before loading it.

•Do not use paper that has been cut or trimmed by hand.

•Do not mix paper sizes, weights, or types in the same tray.

•Make sure the paper size and type are set correctly on the computer or printer control panel.

•Store paper per manufacturer recommendations.

Media Guide

Page 4 of 4
