Lewitt DGT 450 Manual de usuario

ALL YOU NEED

NOTHING LESS THAN

IOS // OS X // WINDOWS

MULTI-PURPOSE USB MICROPHONE

// DGT 450

USER MANUAL

Made for iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus,

iPhone 5, iPhone 5s, iPhone 5c, iPad (4th generation),

iPad Air, iPad mini, iPod touch (5th generation)

// Index

Intro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Recording Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Operating the microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Tech Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Saftey Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

// Intro

Thank you for choosing a LEWITT DGT 450!

In brief: It’s one of the most capable USB microphone on the market. It’s compatible with Windows, Mac and

even iOS devices. It can be used to record vocals, instruments, ambient sound, samples, podcasts and more.

Be sure to check out our Breakout Box although it’s not included in the package - it’s a clever additional

accessory available online and at your local dealer. With this little box you will be able to plug in and record your

guitar, synthesizer, mixing desk or any other line output-equipped device. You can also plug in any MIDI input

device directly and record everything on seperate tracks in one run ...

You see, this is way more than a simple USB microphone: it’s your Digital Multi-Tool.

// Features

// Professional small diaphragm capsule for authentic

recordings of any acoustic event

// Switchable to cardioid polar pattern

// Illuminated user interface for quick and easy

handling even in dark environments

// Recording with iPhone, iPod touch or iPad

// Bus-powered on PC & Mac

// Zero-latency direct monitoring

// Mixable direct monitoring and tape return signal for

host device playback and zero-latency monitoring of

the microphone

// Asynchronus USB transfer: precise internal clock

handles the samplerate timing to avoid jitter and

ensure bit & pitch accurate audio reproduction

// Top applications

// Home studio and live recording

// Sample and demo recording

// Podcasts and YouTube productions

// Mobile / outdoor recording

// Streaming

// Recording Modes

We’ve built two different recording modes into your DGT 450 to make it more versatile, we’d like to briey

introduce them to you here:

Cardioid Mode // Best used for vocal recording or other applications where you need good rear rejection.

Singer/Songwriter Mode // Only availbale with the Breakout Box (not inlcuded). Channel 1 is the cardioid

mic and channel 2 is the line input. Use this mode for simultaneous recording of acoustic and line sources. For

example: plug in your guitar to the line input and sing into the microphone to put the two signals on separate

tracks. If you plug a stereo source into the line input, it will be summed mono (this could possibly cause phase

issues on some synthesizers).

// Setup

Connect the hi-speed 18-pin data connector with the microphone, then connect the USB plug to the computer

or the lightning connector to your iOS device. If you need to extend the USB cable, be sure to use a HI-SPEED-

compatible USB extension cord. We do not recommend the use of USB hubs, but if you need to, only use a

powered hub or use the USB port to power the DGT 450.

OS X (10.6 and up) // Connect the DGT 450 to the USB port.

Open “system preferences” in the menu at the top of the screen.

Click on the “Sound” icon.

Click the “Output” tab and select “DGT 450”.

Click the “Input” tab and also select the “DGT 450”.

Download the Control Center at www.lewitt-audio.com/DGT-Series/DGT-450/Downloads in order to

change the settings of your DGT 450 from your computer

Windows // Connect the DGT 450 to the USB port.

Download and install the drivers – please follow the onscreen instructions.

To use the DGT 450 with your preferred sequencer / digital audio workstation, refer to the software manual.

Download the Control Center at www.lewitt-audio.com/DGT-Series/DGT-450/Downloads in order to

change the settings of your DGT 450 from your computer.

iOS // Just plug and play. Make sure that a power supply is connected to the USB port.

// User Interface

Input indicator // Displays active recording mode

a // Cardioid Mode

b // Singer/Songwriter Mode

Monitoring modes // Mix the output signal of your device

with the input signal of your microphone – simply put: hear the

playback and your voice at the same time ...

Return // Monitor the output of your PC, Mac or iOS device

Direct // Monitor the input of the DGT 450 without any latency

High-pass ﬁ lter // Use these  lters to get rid of unwanted

low frequencies like wind, footsteps, structure-borne noise, ...

The high-pass  lter at 80Hz affects the microphone and line

input at 12dB per octave.

Pre-Attenuation // For loud signals to prevent clipping.

-10 dB of pre-attenuation affect the microphone only.

a b

LED Graph // Displays a value for some settings

like headphone gain, input gain, and others.

I/O Gain // Input and output gain settings

Jog Dial // Push and turn to change settings.

Status Indicator // Displays the current state of

the microphone:

Illuminated white // Standard mode

Not illuminated // Settings mode

Illuminated red // Overload has occurred.

Decrease the gain or change the pre-attenuation

setting.

USB // use the dedicated USB port as power

supply for the DGT 450. As long as it‘s connected

to a PC‘s USB port, it will be powerd via the data

connection.

Breakout Box (not inlcuded) // Adds the

functionality of an interface to your DGT 450.

Data Connector // Connects your DGT 450 to

your device.

Headphone Jack // Plug in your headphones

here.

MIDI In // Plug in your MIDI device here.

Line In // Plug in your instrument here.

// Operating the microphone

The following will walk you through all the settings of your DGT 450.

Standard Mode // This is the default state of the device when you power it on ( is illuminated white).

Settings Mode // This is where you can change all the settings on your DGT 450 including recording modes,

monitoring options, high-pass lters, pre-attenuation and gain. The illuminated LEWITT logo will turn off as

soon as the microphone switches to Settings Mode. Press the jog dial to enter the settings mode, to switch

from setting to setting and rotate it to change the selected setting.

Headphone/Output Gain // The headphone symbol is lit. Rotate the jog dial to change the output volume.

ATTENTION: Your DGT 450 has a professional, built-in headphone amp. Be sure to check your gain settings

befor using headphones, the signal can be very loud. Honestly, we mean it - this can seriously harm your ears.

Input Gain // Press the jog dial until the input gain symbol is lit. We use a very ne gain control – there are

intermediate steps that do not show up on the LEDs. The settings will change depending on the selected

recording mode. You can set input gain levels for all recording modes individually.

Cardioid Mode selected // Gain L R will be lit. Rotate the jog dial to change the gain.

Singer/Songwriter Mode selected (only available with the optional Breakout Box) // Gain L will be lit

rst. This lets you set the gain for the left channel – in this mode, it’s the cardioid microphone. Press the
