IES-0610 V2

User Manual

6-Port Gigabit PoE Industrial Switch, 802.3at/af PoE, 4 PoE Outputs, 1 x SFP, 1 x SFP/RJ45 Combo,

-40°C to 75°C, DIN-Rail, 126W

FCC MARKING

This Equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with th e

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his

own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received; including interference that may

cause undesired operation.

CE MARKING

This equipment complies with the requirements relating to electromagnetic

compatibility, EN 55032/24 class A for ITE, the essential protection requirement of

Council Directive 2014/30/EU on the approximation of the laws of the Member States

relating to electromagnetic compatibility.

Company has an on-going policy of upgrading its products and it may be possible

that information in this document is not up-to-date. Please check with your local

distributors for the latest information. No part of this document can be copied or

reproduced in any form without written consent from the company.

Introduction

This hardened UL60950-1 certified high power POE+ is designed especially for IP

surveillance, traffic monitoring and for a broad range of applications. It accepts 3 power input

sources: PW1, PW2, and Power DIN (via external power adapter) for 48-56VDC power input.

The four PoE+ ports can be used to provide power and data for a variety of PoE devices. It

can be used as a stand-alone device for buses, trucks, and other vehicles for surveillance

purposes. It can also be cascaded/daisy-chained to other devices to cover wider areas via the

uplink ports.

Installation package

This unit can be din-rail mounted or wall-mounted. Din-rail brackets and wall-mounted

brackets are included.

Dip switch function

This unit is equipped with two dip switches,

located on the front panel. Adjusting the dip

switches will change the default function of

this unit. The default manufacturer setting is

SFP for port 5, and 1000M speeds for both

port 5 and port 6 SFP ports. More details are

shown in the chart:

Power connection

This unit provides a 6 pin terminal block. PoE functions can be operated from 48-56VDC

power input. Always make sure your input voltage is within this supported voltage range

for each model.

WARNING – Any exceeded input voltage will not make this unit function and may

damage this unit.

This unit comes with 3 power input sources. P1, P2, and P3.

To connect power: Follow the printed polarity for P1+, P1-, P2+, P2-, and ground. Connect

positive wires to P1+ and/or P2+, connect negative wires to P1- and/or P2-, and connect the

neutral wire to the ground screw as shown.

Power DIN: This unit contains an extra P3 port for power DIN. This power DIN can power

the unit via external power adapter.

Relay: This unit includes an additional 24V@1A relay circuit for special purpose. When 2

powers are connected, the relay is in OPEN mode. If only one of the power sources is

connected, the relay changes to SHORT mode. This relay will only work with P1 and P2. It is

independent from P3.

Power connecting procedure:

STEP 1 – Pull out 6 pin terminal block

STEP 2 – Connect wire to P1+, P1-, P2+, P2-, and the neutral wire to the ground screw.

STEP 3 – Plug connected 6 pin terminal block back into place. Or, Connect the P3 power DIN

from external power adapter.

WARNING – Always SHUT OFF power source to connect power wire.

WARNING – Always ground the power source to maintain a clean power input. Cheaply

made power supplies create too much noise and will cause the power input to fluctuate

when connected to this unit. To avoid this, always ground the power source to maintain a

clean power input.

LED indicator

LNK (Green)

ON—TX link is detected

OFF – TX port is not detected

Flashing – TX port is active

POE (Amber)

ON – POE functioning.

OFF – POE off

PW1 (Green)

ON - V1+, V1- is connected

PW2 (Green)

ON - V2+, V2- is connected

PW3 (Amber)

ON - Power DIN is connected

OFF - Power DIN is

disconnected

F5 (Green)

ON – port 5 SFP fiber is detected

OFF –port 5 SFP fiber is not detected.

Flashing – port 5 SFP fiber is active

F6 (Green)

ON – port 6 SFP fiber is detected

OFF – port 6 SFP fiber is not detected.

Flashing – port 6 SFP fiber is active

RLY (Amber)

ON – Alarm Relay is connected

OFF –Alarm Relay is disconnected

Specification

IEEE Standard

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3ab 1000Base-T Gigabit Ethernet

IEEE 802.3z 1000Base-X Gigabit Ethernet

IEEE 802.3x Flow Control and Back Pressure,

IEEE 802.3af for POE

IEEE 802.3at for POE+

Switch Architecture

Back-plane (Switching Fabric): 12Gbps

Data Processing

Store and Forward

Flow Control:

IEEE 802.3x Flow Control and Back Pressure

Jumbo Frame

9KB

MAC address Table Size

Packet Buffer Size

Network Connector

5 x RJ-45 10/100/1000BaseT(X) auto negotiation,

4 x Gigabit 30W POE+ 802.3at/af PSE port

2 x SFP 100/1000M BaseX

Auto MDI/MDI-X function, Full/Half duplex

Network Cable

UTP/STP Cat.5e or above Cable

EIA/TIA-568 10-ohm (100m)

Fiber Cable (Multi-mode):50/125um,62.5/125um

Fiber Cable (Single-mode): 9/125um

Protocol

CSMA/CD

DIP Switch

DIP 1: F5: F5 ON (default)

T5/OFF: F5 OFF

DIP 2: 1000M: SFP 1000M (default)

100M: SFP 100M

LED

PW1 (Green): ON－Power is detected

PW2 (Green): ON－Power is detected

PW3 (Amber): ON－Power is detected

RLY (Amber):

ON－Only PW1 or PW2 is connected

OFF－Both PW1 and PW2 are connected

TX/RJ-45 port

LNK (Green):

ON－TX port is detected

Flashing－TX data is transmitting/receiving

PoE (Amber):

ON－PSE is activated and PD is detected

OFF－PSE is detecting PD

SFP port (Green):

ON－SFP port is detected

Flashing－SFP data is transmitting/receiving

Reserve polarity protection

Present

Overload current protection

Present

Power Supply

Redundant Dual DC 48V-56V Power Input

POE input 48-56VDC

Power Consumption

5.76W@48 VDC full load, Without POE

Alarm Relay Contact

Relay outputs with current carrying capacity of 1

A @24VDC, Relay in “open” circuit mode when

PW1 and PW2 are connected. in “short” circuit

mode when only one power supply is connected

POE power

POE power per port 30watts. Maximum 36Watts

Maximum total power 126Watts, Supports

IEEE802.3af/at

Removable Terminal Block

Provide 2 Redundant power, Alarm relay contact,

6 Pin

Wire range: 0.34mm^2 to 2.5mm^2

Solid wire (AWG):12-24/14-22

Stranded wire(AWG): 12-24/14-22

Torque:5lb-In/0.5Nm/0.56Nm

Wire Strip length: 7-8mm

Operating Temperature

-40°C to 75°C

Operating Humidity

5% to 95% (Non-condensing)

Storage Temperature

-40°C to 85°C

MTBF (mean time between failure)

>500,000 hrs (MIL-HDBK-217F) at 25°C

Housing

Rugged Metal, IP30 Protection

Case Dimension

142 x 42.8 x 105 mm (L x W x D)

Installation

DIN Rail Mount or Wall Mount

Certifications

Safety

UL 60950-1

Safety

IEC EN62368-1

EMC/EMS

CE, FCC, VCCI

EMI

FCC Part 15 Subpart B Class A

EN 60068-2-6

Vibration

EN 60068-2-27

Shock

EN 60068-2-32

Free Fall

Housing Dimension (mm)

NOTE:

Housing dimension is for purpose of showing product Length, Width, Height, din-rail, and

terminal block’s position and dimension. Please reference the LED Indicator Page for correct

port order.
