User Manual

GSW-0509 / GSW-0809

5/8-Port Gigabit Switch w/ Internal Power

V1.0

FCC Certifications

This Equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to

correct the interference at his own expense.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any

interference received; including interference that may cause

undesired operation.

CE Marking Warning

This equipment complies with the requirements relating to

electromagnetic compatibility, EN 55022 class A for ITE, the

essential protection requirement of Council Directive 89/336/EEC on

the approximation of the laws of the Member States relating to

electromagnetic compatibility.

Company has an on-going policy of upgrading its products and it

may be possible that information in this document is not up-to-date.

Please check with your local distributors for the latest information.

No part of this document can be copied or reproduced in any form

without written consent from the company.

Trademarks:

All trade names and trademarks are the properties of their

respective companies.

Introduction

The device is a powerful, high-performance Gigabit Ethernet switch,

with all ports capable of 10, 100 or 1000Mbps auto-negotiation

operation (NWay), which means the switch could automatically

negotiate with the connected partners on the network speed and

duplex mode. It is ideal for micro-segmenting large networks into

smaller, connected subnets for improved performance, enabling the

bandwidth demanding multimedia and imaging applications.

Moreover, the 10/100/1000Mbps auto-sensing ability provides an

easy way to migrate 10/100Mbps to 1000Mbps network with no pain.

Compared to the shared 10Mbps or 100Mbps networks, the switch

delivers a dedicated 10/100/1000Mbps connection to every attached

client with no bandwidth congestion issue. This switch also supports

auto MDI / MDI-X function. Each port could be used to connect to

another switch or hub with no crossover RJ-45 cable.

Store-and-forward switching mode promises the low latency plus

eliminates all the network errors, including runt and CRC error

packets. To work under full-duplex mode, transmission and

reception of the frames can occur simultaneously without causing

collisions as well as double the network bandwidth.

The switch provides 9K bytes jumbo frames, which means the

frames size is larger than normal 1.5K. With the Jumbo frame

function, you can get better network performance, because the

switch can send more data at the same time.

The switch is plug-n-play without any software to configure and also

fully compliant with all kinds of network protocols.

Before you start to install the switch, check the following contents in

this package：

zGSW-0509/GSW-0809 Switch

zOne power cord

zUser’s manual

LED Definition

GSW-0509 Front Panel

GSW-0809 Front Panel

LED Status Operation

Power Steady Green Power is on

Off Power is off

Link/ACT Steady Green Port connected

Blinking Green The port is transmitting/receiving data

Rear Panel

The rear panel of the GSW-0509/GSW-0809 switch consists

of a DC power connector and 5/8 10/100/1000Mbps RJ45

Ports. The following figure shows the rear panel of the Switch.

yGSW-0509

yGSW-0809

Stations Connection

Connect each station to the switch by twisted-pair cable. Plug

one RJ-45 connector into a RJ-45 port of the switch, and plug

the other RJ-45 connector into the station’s network adapter.

Power on the switch and then system is ready.

For cable selection, refer to the following table.

Switches Connection

In making a switch interconnection, you could use any port to

connect another switch with straight or crossover cable. As all

the ports support auto MDI / MDI-X function, using a straight

cable to make a switch-to-switch connection is allowed.

For cable selection, refer to the following table：

Network Speed Cable Type Max. Length

10Mbps Cat. 3, 4, 5 UTP/STP 100 meters

100Mbps Cat. 5 UTP/STP 100 meters

1000Mbps Cat. 5e/6 UTP/STP 100 meters

Specification

Standard yIEEE 802.3 10BASE-T

yIEEE 802.3u 100BASE-TX

yIEEE 802.3ab 1000BASE-T

yIEEE 802.3x Full Duplex Operation & Flow

Control

Interface y5/8 * 10/100/1000Mbps RJ-45 Gigabit Ethernet

Ports (GSW-0509/GSW-0809)

NWay Protocol

Support

y10Mbps: Full/Half duplex

y100Mbps: Full/Half duplex

y1000Mbps: Full duplex only

MAC Address

Table

y1K MAC Address entries (GSW-0509)

y4K MAC Address entries (GSW-0809)

Buffer Memory y104KBytes (GSW-0509)

y128KBytes (GSW-0809)

Jumbo Frame y9K Byte (GSW-0509/GSW-0809)

Power Supply yInternal Power Supply 100-240 VAC 5V/2A

Temperature yOperating Temperature: 0 40~℃℃

yStorage Temperature : -10Ԩ~70Ԩ

Humidity yOperating Humidity: 10%~90% (non-condensing)

yStorage Temperature: 5%~95%

EMI yCE and FCC class A

Technical Support

Thank you for selecting LevelOne products. LeveOne’s

website contains the latest user documentation and soft-ware

updates for LevelOne products.

Please contact LevelOne Technical Support through our

website.

World Wide Web

http://global.level1.com/
