LevelOne FVT-5001 Manual de usuario
FVT-5001 / FVT-5301 / GVT-5000
Copper to Fiber
Media Converter Module
User Manual
Part No. Model
No. Description
532502 FVT-5001 10/100Base-TX to 100Base-FX
SC, Multi-mode 2km (TS-1000)
532530 FVT-5301 10/100Base-TX to 100Base-FX
SC, Single-mode 30km (TS-1000)
532500 GVT-5000
1000BaseT to SFP mini-GBIC
Converter Module
Ver. 1.02 - 0701
FCC Warning
This Equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a class A product. In a domestic environment this product
may cause radio interference in which case the user may be
required to take adequate measures.
Table of Contents
1. INTRODUCTION................................................1
1.1. FAST ETHERNET EXPENSION MODULE.............1
1.2. GIGABIT EXPENSION MODULE .........................1
1.3. PACKAGE CONTENTS......................................2
2. HARDWARE DESCRIPTION............................2
2.1. FRONT PANEL.................................................2
2.2. FAST ETHERNET LED INDICATORS ..................3
2.3. GIGABIT LED INDICATORS...............................4
3. INSTALLATION.................................................5
3.1. CHASSIS ........................................................5
3.2. FIBER.............................................................6
4. SPECIFICATION................................................7
4.1. OPTICAL FIBER...............................................7
4.2. OPTIONAL SFP MODULES...............................7
4.3. TECHNICAL SPECIFICATION .............................8
1
1. Introduction
These converter modules are for FVT-5000 16 slot Converter
Chassis with TS-1000 supported. By this converter module, user
can get higher bandwidth from your network infrastructure and
extend network available link distance by fiber cable
1.1. Fast Ethernet Expansion Module
Comply with IEEE 802.3, 802.3u standards
Convert between UTP cabling and Fiber-optic cabling
One RJ-45 connector, Auto-MDI/MDIX for UTP port
Support 10/100 Mbps Auto-negotiation for UTP port
Support TS-1000, Loop Back Test
Built in Link Lose Forwarding Technology
Remote Monitor/Control for Terminal side
Hot swappable
1.2. Gigabit Expansion Module
Comply with IEEE 802.3, 802.3u, 802.3ab, 802.3z standards
Convert between UTP cabling and Fiber-optic cabling
One SFP slot for mini-GBIC module
One RJ-45 connector, Auto-MDI/MDIX for UTP port
Support 10/100/1000 Mbps Auto-negotiation for UTP port
Built in Link Lose Forwarding Technology
Remote Monitor/Control for Terminal side
Hot swappable
Note:
Gigabit Module does not support TS-1000
2
1.3. Package Contents
- Media Converter Module
- User manual
If any item is damaged or missing, please contact your local dealer
for service.
2. Hardware Description
2.1. Front Panel
FVT-5001
FVT-5301
GVT-5000
3
2.2. Fast Ethernet LED Indicators
LED Status Meaning
PWR Green Power on
Green Link on 100Mbps Speed
SPD
(UTP) OFF Link on 10Mbps Speed
Green The unit is linking with it’s link partner.
Blinks The unit is transmitting or receiving packets
LK/ACT
(UTP)
Off No device attached
Green The unit is linking with it’s link partner.
Blinks The unit is transmitting or receiving packets
LK/ACT
(Fiber) Off No device attached
Orange The UTP port is operating in full-duplex mode.
Blinks Collision of Packets occurs in the port.
FDX/COL
(UTP)
Off Half-duplex mode or no device attached
Orange The fiber port is operating in full-duplex mode.
Blinks Collision of Packets occurs in the port.
FDX/COL
(Fiber) Off Half-duplex mode or no device attached
Link Lost Forwarding:
When LLF is enable, allow UTP link failures to be reported to the
fiber side and also allow Fiber link failure to be reported to the UTP
side. Therefore, A link loss forward feature is provided in both UTP
and Fiber side.
4
2.3. Gigabit LED Indicators
LED Status Meaning
PWR Green Power on
Green Link on 1000Mbps Speed
Orange Link on 100Mbps Speed
SPD
(UTP)
OFF Link on 10Mbps Speed
Green The unit is linking with it’s link partner.
Blinks The unit is transmitting or receiving packets
LK/ACT
(UTP) Off No device attached
Green The unit is linking with it’s link partner.
Blinks The unit is transmitting or receiving packets
LK/ACT
(Fiber)
Off No device attached
Orange The UTP port is operating in full-duplex mode.
Blinks Collision of Packets occurs in the port.
FDX/COL
(UTP) Off Half-duplex mode or no device attached
Orange The fiber port is operating in full-duplex mode.
Blinks Collision of Packets occurs in the port.
FDX/COL
(Fiber)
Off Half-duplex mode or no device attached
5
3. Installation
3.1. Chassis
This installation is only for mounting in converter chassis converter
module. You can follow the steps below to install modular
converters.
Remove the module slot cover from the converter chassis.
Install the modular converter by inserting it into the guides and
sliding it in, and then, press it firmly until the power plug in the
chassis plugs into the modular converter receptacle property.
Push the thumbscrews in and turn clockwise to tighten.
Do not over tighten the thumbscrews.
Front Panel with all modules installed
6
3.2. Fiber
For the Fast Ethernet Fiber Port: We provide SC connectors
(multi/single mode). Please follow the below figure to connect it.
Wrong connection will cause the port cannot work properly.
This is a Class 1 Laser/LED product
Do not stare into the Laser/LED beam
ATTENTION
7
4. Specification
4.1. Optical Fiber
Model No. Wavelength
(nm) Avg. Launch
Power (dB) Avg.
Sensitivity (dB)
FVT-5001
SC, Multi-mode 1310 (nm) -18 (dB) -30 (dB)
FVT-5301
SC, Single-mode 1310 (nm) -6 (dB) -34 (dB)
Model No. Avg. Power
Loss Budget
(dBm)
Max. FDX Fiber
Distance (Km) Fiber Size (um)
FVT-5001
SC, Multi-mode 12 (dBm) 2 (Km) 62.5/125
50/125
FVT-5301
SC, Single-mode 28 (dBm) 30(Km) 10/125
8/125
4.2. Optional SFP Modules
GVT-5000 supports 3.3V mini-GBIC module
Part No. Model No. Description
570622 GVT-0300 Mini-GBIC SFP transceiver
Multi-Mode, 550m
551071 GVT-0301 Mini-GBIC SFP transceiver
Single-Mode, 10km
551072 GVT-0302 Mini-GBIC SFP transceiver
Single-Mode, 70km
