LevelOne FVT-2001 Manual de usuario
Copper to Fiber
Stand-Alone Media Converter
User Manual
Model No.
Description
FVT-2001
10/100BASE-TX to 100BASE-FX MMF SC Converter, 2km
FVT-2002
10/100BASE-TX to 100BASE-FX MMF ST Converter, 2km
FVT-2201
10/100BASE-TX to 100BASE-FX SMF SC Converter, 20km
FVT-2202
10/100BASE-TX to 100BASE-FX SMF SC Converter, 20km
FVT-2401
10/100BASE-TX to 100BASE-FX SMF SC Converter, 40km
GVT-2000
10/100/1000BASE-T to 1000BASE-X SFP Converter
GVT-2001
10/100/1000BASE-T to 1000BASE-SX MMF SC Converter,
550m
GVT-2002
10/100/1000BASE-T to 1000Base-SX/LX SMF SC Converter,
20km
GVT-2003
10/100/1000BASE-T to 1000Base-SX/LX SMF ST Converter,
20km
Ver. 1.03
Table of Contents
1. INTRODUCTION ................................................... 1
1.1. FEATURES .................................................. 1
2.1. FRONT PANEL ............................................ 3
2.2. REAR PANEL ............................................... 4
2.3. LED INDICATORS ....................................... 5
2.4. DIP-SWITCH ................................................ 7
3. CABLING ................................................................. 8
4. SPECIFICATION .................................................. 10
5. OPTIONAL SFP MODULES ............................... 12
1
1. Introduction
LevelOne media converters are Fast Ethernet 10/100Base-TX to
100Base-FX and 10/100/1000Base-T to 1000Base-SX/LX
converters to provide the flexibility required in network integration.
The TX port auto-sense connection speed, auto-negotiates half/full
duplex modes and auto-selects MDIX media type. The fiber
connectors come with multimode or singlemode, SC, ST or SFP
connector to provide necessary connection interface and distance
capabilities.
LevelOne have designed 19” racks to organize media converters the
smart way by providing a single power supply. With the
Plug-and-play technology, the converter is easy to set-up and run.
For simple, cost-effective network design, LevelOne converter
series is the perfect solution to bridge the complex network
infrastructure.
1.1. Features
Fast Ethernet Module
§ Comply with IEEE 802.3, 802.3u and 802.3x standards.
§ Convert between UTP cabling and Fiber-optic cabling.
§ One RJ-45 connector, Auto-MDI/MDIX for UTP port.
§ Support 10/100 Mbps Auto-negotiation for UTP port.
§ Fiber cabling connectivity up to 40Km.
§ Store-and-forward switching to separate two collision domains.
2
§ One fiber connector (SC/ ST) for 100Base-FX.
§ 2 DIP-switches to set the operation mode
§ Link- Lost-Forwarding function.
Gigabit Ethernet Module
§
Comply with IEEE 802.3, 802.3u and 802.3x, IEEE 802.3ab
1000BaseT, 802.3z 1000Base SX/LX standards.
§
Convert between UTP cabling and Fiber-optic cabling.
§
One RJ-45 connector, Auto-MDI/MDIX for UTP port.
§
Support 10/100/1000 Mbps Auto-negotiation for UTP port
§
Fiber cabling connectivity up to 80Km.
§
Store-and-forward switching to separate two collision domains.
§
One fiber connector (SC / SFP) for 1000Base-SX/LX
§
DIP-switches to set the operation mode function.
§
Link- Lost-Forwarding function.
3
2. Hardware Description
2.1. Front Panel
l FVT-2001 / FVT-2002 / FVT-2201 / FVT-2401 / FVT-2202
l GVT-2000
l GVT-2001 / GVT-2002 / GVT-2003
(1) RJ-45 Port (3) Fiber/SFP Connector
(2) LED Indicators (4) DIP-Switch
3
2
1
4
4
2.2. Rear Panel
Model No.
Power Adapter
FVT-2001
DC 5V, 1A
FVT-2002
DC 5V, 1A
FVT-2201
DC 5V, 1A
FVT-2202
DC 5V, 1A
FVT-2401
DC 5V, 1A
GVT-2000
DC 5V, 2A
GVT-2001
DC 5V, 2A
GVT-2002
DC 5V, 2A
GVT-2003
DC 5V, 2A
4
5
2.3. LED Indicators
Fast Ethernet Module
LED
Status
Meaning
PWR
On
Power on
FX
On
100Mbps Fiber Speed
TX
On
100Mbps UTP Speed
OFF
10 Mbps UTP Speed
FDX
On
Converter works in the full duplex mode
OFF
Converter works in the half duplex mode
L/A
UTP(right)
On
Connection status display for fiber link.
“ON” indicates that Fiber link is in correct
connection.
Blinks
Active status display of fiber link
“Blink” indicates packet goes through FX end.
L/A
Fiber(left)
On
Connection status display for electric link.
“ON” indicates that electric link is in correct
connection.
Blinks
Active status display of fiber link
“Blink” indicates packet goes through TX end
6
Gigabit Ethernet Module
LED
Status
Meaning
PWR
On
Power on
1000
On
1000Mbps UTP Speed
100
On
100Mbps UTP Speed
FDX
On
Converter works in the full duplex mode
Off
Converter works in the half duplex mode
L/A
UTP(right)
Blinks
Active status display of electrical interface link
Blink” indicates packet goes through TP
L/A
Fiber(left)
Blinks
Active status display of fiber interface link
“Blink” indicates packet goes through FX
Note: The UTP port speed is 10Mbps when both 100 and 1000 LED indicators
"OFF"
7
2.4. DIP-switch
The DIP-switch is used to configure operation mode for LLF (Link
Lost Forwarding) and Flow-Control function for UTP/Fiber port. The
default value of DIP switch is OFF.
Fast Ethernet Module/Gigabit Ethernet Module
No
Status
Description
1
ON
LFP is Enable
OFF
LFP is Disable
2
ON
Flow-Control function ENABLED
OFF
Flow-Control function DISABLED
Link Lost Forwarding:
When LLF is enable, allow UTP link failures to be reported to the
fiber side and also allow Fiber link failure to be reported to the UTP
side. Therefore, A link loss forward feature is provided in both UTP
and Fiber side.
Flow Control Function :
Flow control stops and resumes the transmission of network traffic
between two connected peer nodes on a full-duplex Ethernet
physical link. Controlling the flow by pausing and restarting it
prevents buffers on the nodes from overflowing and dropping
frames.
Note:
Please don’t change the DIP-switch setting when UTP or fiber port is
transmitting or receiving data. It may cause some data error.
8
3. Cabling
Fast Ethernet Module
§ Twisted-pair segment can be use unshielded twisted pair (UTP)
or shielded twisted pair (STP) cabling. The cable must comply
with the IEEE 802.3u 100Base TX standard for Category 5. The
cable between the converter and the link partner (switch, hub,
workstation, etc.) must be less than 100 meters (328 ft.) long.
§ Fiber segment using multi-mode connector type must use 50 or
62.5/125 um multi-mode fiber cable. You can connect two
devices up to a 2-kilometer (6,562 ft.) distance.
§ Fiber segment using single-mode connector type must use
8/125 or 9/125 um single-mode fiber cable. You can connect two
devices in the distance of 40 Kilometers in full duplex operation.
For half-duplex operation, the recommended maximum distance
is 412 meters (1,352 ft.)
Gigabit Ethernet Module
§ Using four twisted-pair, Category 5 cabling for RJ-45 port
connection. The cable between the converter and the link
partner (switch, hub, workstation, etc.) must be less than 100
meters (328 ft.) long.
§ Fiber segment using multi-mode connector type must use 50 or
62.5/125 um multi-mode fiber cable. You can connect two
devices up to 550m distances.
§ Fiber segment using single-mode connector type must use
8/125 or 9/125 um single-mode fiber cable. You can connect two
devices in the distance of 80 Kilometers in full duplex operation.
For half-duplex operation, the recommended maximum distance
is 412 meters (1,352 ft.)
