Lenovo TAB A7-40/

Lenovo TAB A7-50

Quick Start Guide v1.0

Read this guide carefully before using your tablet.

All information labeled with * in this guide refers only to

the WLAN + 3G model (Lenovo A3500-H/HV).

Height: 198 mm Width: 121.2 mm Depth: 9.9 mm

Weight: 320 g

Size: 7 inches (diagonal) Screen: Multi-touch display

Resolution: 1280 × 800 LCD type: IPS

①Actual product may differ.

② Launch with Android 4.2 which only supports BT 4.0 PXP proﬁle.

Lenovo A3500-FL does not have a rear camera.

Technical speciﬁcations

5.0 MP FF (rear) + 2.0 MP FF (front) 2.0 MP FF (front)

*Version: WLAN + 3G

②Bluetooth 4.0 WLAN 802.11 b/g/n GPS

*WCDMA, GSM

3450 mAh

Wireless

communication

Display

Battery

CPU

① Size and weight

Camera

Lenovo TAB A7-50

Model & version

Model: Lenovo A3500-FL

Version: WLAN

MTK MT8121 Quad Core 1.3 GHz

*MTK MT8382 Quad Core 1.3 GHz

(Data only)

*Model: Lenovo A3500-H

Model: Lenovo A3500-F

Version: WLAN

③

*Model: Lenovo A3500-HV

(Voice)

*Version: WLAN + 3G

Lenovo TAB A7-40

Volume Key

*SIM card Slot

*Receiver

On/Off button

Micro USB

Speaker Rear camera

Earphone jack 2

Microphone

Front camera

microSD card slot

For Lenovo A3500-H, the receiver is only available to VoIP (Voice over

Internet Protocol)

Lenovo A3500-F/FL does not have a SIM card slot.

First glance

1 2

Step 1. Open the SIM card & microSD card slot cover.

Step 2. Insert the SIM card into the SIM card slot and insert the

microSD card into the microSD card slot.

Step 3. Replace the SIM card & microSD card slot cover .

You can use cellular services with the WLAN + 3G model (Lenovo

A3500-H/HV) by inserting the SIM card provided by your carrier

services. Install the SIM card & microSD card as shown.

Do not insert or remove the SIM card while your tablet is turned on.

Doing so may permanently damage your SIM card or tablet.

*Installing the SIM card & microSD card

SIM

microSD

SIM

1 2 3

microSD

SIM

reset

Method 1. Connect your tablet to a power outlet using the included

cable and USB power adapter.

Method 2. Charge the battery using a computer.

Low battery Fully charged Charging

For more information about battery safety, see the Important Product

Information Guide.

Before using your tablet, you might need to charge the battery.

Charge the battery as shown.

Charging the battery

70110781

Printed in China

Learn more

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the

United States, other countries, or both.

Other company, product, or service names may be trademarks

or service marks of others.

First Edition (March 2014) © Copyright Lenovo 2014.

For other useful manuals, please access “User Guide” from the

Browser favorites in your tablet.

For “Regulatory Notices” , please go to

http://support.lenovo.com/.

Getting support

For support on network service and billing, please contact your

wireless network operator. For instructions on how to use your

tablet, go to

http://support.lenovo.com/.

Radio and Telecommunications Terminal Equipment Directive

This product is in compliance with the essential requirements

and other relevant provisions of the Radio and Telecommuni-

cations Terminal Equipment Directive, 1999/5/EC.

European Union conformity
