Lenovo IdeaTab A3000 Manual de usuario

Quick Start Guide v1.0

IdeaTab

A3000

Please read this guide carefully before using your IdeaTab. The guide will

help you learn tips on setting and using IdeaTab.

The information in this guide is based on default settings. Illustrations and

screenshots used here may differ from the actual product appearance and

screen displays.

Front

Front camera

Volume

button

Welcome

Screen lock/unlock

In standby mode, press the Power button to lock your IdeaTab.

To unlock the screen, press the Power button, and then drag the on-screen

slider to enter the interface displayed before it locks.

Turning IdeaTab off

While in standby mode, press and hold the Power button and then follow the

on-screen instructions to conﬁrm shutdown.

Power button

Back

camera

Earphone jack Micro USB

Microphone

Speaker

Getting started

Model:IdeaTab A3000-H Version: 3G Voice

L × W × H: 194mm x 120mm x 11mm *

3500 mAh

Weight: Appr. 345g

Color: Black

Android 4.2

Bluetooth 4.0

7", 16:9, 1,024 x 600 dpi

Micro USB

5.0 M (back) 0.3 M (front)

64 GB (max.)

Wi-Fi

MTK MT8389

Dimensions/Weight/Color

Integrated camera

Screen

Battery

CPU

GPS

3.5 mm

earphone jack micro SD card slot

Operating system

Hardware

Operating system

Interface

Communication

*SIM Card

3G WWAN

(WCDMA)

* Based on actual measurement.

Technical speciﬁcations

You can charge your IdeaTab whether it is on or off.

When the battery level falls below the threshold, IdeaTab will alert you with

a tone and the battery status icon will change into . We recommend you

plug the AC power adapter into your IdeaTab in the direction of the orange

arrow as shown above ﬁgure.

If your IdeaTab is being charged while it is on, the battery status icon

(located on the status bar of the screen) will appear as . After the battery

has ﬁnished charging, the status bar will show the fully charged icon .

For more information on battery safety, see the Important Product

Information Guide.

Charging IdeaTab

Inserting micro SD card and SIM card

Keep the metal surface down for SIM card and micro SD

card.

IdeaTab supports micro SD card and SIM card extension. To insert an micro

Step . Open the IdeaTab back cover as shown.

Step . Insert the micro SD card and SIM card as shown.

Close the back cover.

SD card and SIM card , do the following:

SIM2

SIM1

You can connect IdeaTab to the PC's USB port with the cable provided for

battery charging or data transferring with the PC.

Installing apps and games

Transfer the APK setup ﬁle from the PC to IdeaTab, and then open it in the

ﬁle manager on IdeaTab. The installer will run automatically.

There are three connection methods available: USB storage, Media device

(MTP) and Camera (PTP).

IdeaTab supports micro SD card and SIM card extension. To insert an micro

Connecting IdeaTab to PC

This function requires support from your wireless carrier.

Touch > Call. Now you can input your number or choose a number

from the call history or Contacts.

operators13800000000

Phone

Options

Hide dial pad

Show dial pad

Mute on/off

Microphone on/off Suspend call

Add call

*Multiparty service is required to use the teleconference function.

Teleconference*

Making a call

This function requires support from your wireless carrier.

New message

Send message

Options

Add contact

Touch > Messaging. Now you can use the messaging function to

keep contact with your family or friends.

Add attachment

Search Phone

10:51

10:54

13800000000

Type message

sent

Received

HI~How's everything?

Me too,what are you busy now?

I am going to China for a travel with my family next month.

It sounds good.Have a good trip then.

Thanks~~~

I’m ﬁne.and you?very pleased to see you.

Messaging

Adding apps/widgets to the desktop

Tap and hold the icon of your desired application or widget, until the

desktop background pattern appears on the screen, and then place the

icon wherever you wish.

Touch >WIDGETS. You can drag your favorite applications and

widgets onto the desktop.

Tap and hold any icon on the desktop and then drag it to your preferred

location or delete it from the desktop.

Editing the desktop

Customizing the desktop
