Lenovo IdeaCentre A300 Manual de usuario

1. Unpack

2. Computer instructions 3. Computer stand 4. Carry the computer

84 73 5 6 9

2 3 4 5 6 8 89 10 117

Do not put any fluid container on the

base stand.

The buttons at the bottom of the screen

are touch buttons. When you touch

these, the indicator lights turn on.

Connect the power cords properly to

grounded electrical outlets.

Connect the

keyboard cable to

the appropriate

keyboard connector

(USB connector).

Connect the mouse

cable to the

appropriate mouse

connector (USB

connector).

Adjust the angle for the best viewing

experience. It can be rotated from

horizontal or vertical.

The stand provides stability to the

computer; it is not a removable part.

Hold the computer tightly when you carry it.

318

Adjust the panel angle

for the best viewing

from the vertical.

Do not only use one

hand to adjust the panel

angle to avoid the

computer falling over.

Adjust the panel angle

for the best viewing

from the horizontal.

Version: 1.0

Connecting the wired keyboard and

mouse to your computer

(Selected models only)

Press the power button on the top of the

base stand to turn on the computer.

Camera

Built-in microphone

Hard Disk Drive Indicator

Bluetooth status indicator

WIFI status indicator

HDMI-IN mode indicator

LCD light adjust button

Novo Vision button

LCD on/off and PC/HDMI-IN switch combo

Power button

TV tuner connector

(Selected models only)

Power connector

Ethernet connector

HDMI-IN connector

(Selected models only)

HDMI-OUT connector

(Selected models only)

IEEE 1394 connector

(Selected models only)

USB ports (4)

Memory card reader

(Selected models only)

Microphone connector

Headphone connector

Bluetooth connect button

Mode switch button

(Selected models only)

The computer stand must

remain installed at all

times to ensure maximum

system stability.

31041772

5. Wireless keyboard and mouse instructions (Only some models are equipped with wireless keyboard and mouse)

Method 2Method 1

Make sure the power switch on the back of the mouse is in

the ON position (the keyboard does not have a power switch).

When the keyboard and mouse wireless indicator lights

blink green, turn the computer on immediately.

Once the wireless connection is successfully established,

the indicator lights on the keyboard and mouse will turn

off and they will work properly.

CONNECT

LASER

OFFON

CONNECT

OFF ON

CONNECT

Make sure the power

switch on the back of

the mouse is in the ON

position (the keyboard

does not have a power

switch).

CONNECT

LASER

OFFON

Install the batteries into the

keyboard and mouse

battery compartments.

Install the batteries

into the keyboard

and mouse battery

compartments.

Press the wireless connect buttons on the right side of the

keyboard and the back of the mouse for over 5 seconds.

When the keyboard and mouse wireless indicator lights

blink green, turn the computer on immediately.

Once the wireless connection is successfully established,

the indicator lights on the keyboard and mouse will turn

off and they will work properly.

CONNECT

LASER

OFFON

CONNECT

OFFON

CONNECT

Press the wireless connect buttons on the right side of

the keyboard and the back of the mouse for over 5

seconds.

If the wireless indicator lights stop blinking,

press the connect buttons on the keyboard

and mouse again.

The process of searching for wireless devices

could take several minutes.

After entering the system, press the Bluetooth connect button

on the base stand for over 5 seconds to search for wireless

devices.

When the wireless mouse device is found, the driver will be

installed automatically.

When the wireless keyboard device is found, enter the PIN

code and press the Enter key to finish the pairing process.

Once the wireless connection has been successfully

established, the wireless keyboard and mouse will work

properly.

If the wireless keyboard and mouse do not work, do

the following:

Bluetooth

connect button

Mode switch

button
