Lenovo IdeaCentre 5i Manual de usuario

IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6)

User Guide

Read this first

Before using this documentation and the product it supports, ensure that you read and understand the

fo owing:

• Safety and Warranty Guide

• Generic Safety and Compliance Notices

• Setup Guide

First Edition (July 2021)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is de ivered pursuant to a Genera Services

Administration “GSA” contract, use, reproduction, or disc osure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

bout this documentation . . . . . . . . iii

Chapter 1. Meet your computer. . . . . 1

Front . . . . . . . . . . . . . . . . . . . . 1

Rear . . . . . . . . . . . . . . . . . . . . 3

Features and specifications . . . . . . . . . . . 4

USB specifications . . . . . . . . . . . . . . 4

Operating environment . . . . . . . . . . . . . 6

Chapter 2. Get started with your

computer . . . . . . . . . . . . . . . . . 7

Work with Windows . . . . . . . . . . . . . . 7

Windows he p information . . . . . . . . . . 7

Connect an externa disp ay . . . . . . . . . . . 8

Manage cab es with a smart cab e c ip . . . . . . . 8

Chapter 3. Explore your computer . . . 9

Lenovo Vantage. . . . . . . . . . . . . . . . 9

Set the power p an . . . . . . . . . . . . . . 9

Transfer data . . . . . . . . . . . . . . . . 10

Connect to a B uetooth-enab ed device (for

se ected mode s) . . . . . . . . . . . . 10

Use the optica drive (for se ected mode s) . . 10

Use a media card (for se ected mode s) . . . . 11

Purchase accessories . . . . . . . . . . . . 11

Chapter 4. CRU replacement . . . . . 13

CRU ist . . . . . . . . . . . . . . . . . . 13

Remove or rep ace a CRU . . . . . . . . . . . 14

Power cord. . . . . . . . . . . . . . . 14

Computer cover . . . . . . . . . . . . . 15

Front beze . . . . . . . . . . . . . . . 16

Storage drive . . . . . . . . . . . . . . 18

Storage drive bracket . . . . . . . . . . . 20

M.2 so id-state drive . . . . . . . . . . . 22

Power supp y assemb y . . . . . . . . . . 24

Coin-ce battery. . . . . . . . . . . . . 25

Optica drive . . . . . . . . . . . . . . 28

Heat sink assemb y . . . . . . . . . . . 29

PCI-Express card . . . . . . . . . . . . 30

Memory modu e . . . . . . . . . . . . . 31

Chapter 5. Help and support . . . . . 35

Frequent y asked questions . . . . . . . . . . 35

Se f-he p resources . . . . . . . . . . . . . 35

Ca Lenovo . . . . . . . . . . . . . . . . 37

Before you contact Lenovo . . . . . . . . 37

Lenovo Customer Support Center . . . . . . 37

Purchase additiona services. . . . . . . . . . 38

ppendix . Notices and

trademarks . . . . . . . . . . . . . . . 39

ii IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide

bout this documentation

• This guide app ies to the Lenovo product mode s isted be ow. I ustrations in this guide may ook s ight y

different from your product mode .

Model name Machine types (MT)

IdeaCentre 5 14IOB6 90RJ

IdeaCentre 5 14ACN6 90RX

• For further comp iance information, refer to the Generic Safety and Compliance Notices at https://

pcsupport. enovo.com/docs/generic_notices.

• Depending on the mode , some optiona accessories, features, and software programs might not be

avai ab e on your computer.

• Depending on the version of the operating systems and programs, some user interface instructions might

not be app icab e to your computer.

• Documentation content is subject to change without notice. Lenovo makes constant improvements to the

documentation of your computer, inc uding this User Guide. To get the atest documentation, go to https://

pcsupport. enovo.com.

• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.

As a resu t, some information in this documentation might become outdated. Refer to Microsoft resources

for the atest information.

iv IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide

Chapter 1. Meet your computer

Front

1. Optica drive* 2. Power button

3. Headset connector 4. USB-C® connector (USB 3.2 Gen 1)

5. USB 3.2 connectors Gen 1 6. USB 3.2 connectors Gen 2

7. 3 in 1 card reader s ot*

* for se ected mode s

** The icon varies with the configuration of the mode .

Power indicator

Show the system status of your computer.

• On: The computer is on.

• Off: The computer is off or in hibernation mode.

• Blinking: The computer is in s eep mode.

Headset connector (for IdeaCentre 5 14IOB6 only)

The headset connector is compatib e with:

• Headphones or earphones with a 3.5mm (0.14 inch), TRS (3-po e) p ug

• Headsets with a 3.5mm (0.14 inch), CTIA-comp iant TRRS (4-po e) p ug

Note: This headset connector does not support standa one externa microphones with a TRS (3-po e) p ug

or headsets with an OMTP-comp iant TRRS (4-po e) p ug.

Related topics

• “USB specifications” on page 4.

Chapter 1.Meet your computer 3

Features and specifications

For detai ed specifications of your computer, go to https://psref. enovo.com.

Hardware To view the hardware information of your computer, type device manager in the

Windows search box and then press Enter.

Power supply 260-watt automatic vo tage-sensing power supp y

daptability for power supply

• Main and China: 220 V±22 V, 50 Hz±1 Hz

• Adaptive vo tage positioning: 90 V to 264 V, 50/60 Hz

• With vo tage se ection switch: 90 V to 264 V, 50 Hz±1 Hz

Microprocessor To view the microprocessor information of your computer, type system

information in the Windows search box and then press Enter.

Memory Doub e data rate 4 (DDR4) dua in- ine memory modu e (DIMM)

Storage device

To view the storage drive capacity of your computer, type disk management in the

Windows search box and then press Enter.

Note: The storage drive capacity indicated by the system is ess than the nomina

capacity.

Expansion

• 3 in 1 card reader*

• Memory s ots

• M.2 so id-state drive s ot

• Optica drive*

• PCI-Express card s ots

• Storage drive bay

Network features

• B uetooth

• Ethernet LAN

• Wire ess LAN

* for se ected mode s

USB specifications

Note: Depending on the mode , some USB connectors might not be avai ab e on your computer.

4IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide
