Lenovo 10142/F0A9 Manual de usuario

LenovoFlex20All-In-OnePC

HardwareMaintenanceManual

ideaideaideaCentreidea

MachineTypes:10142/F0A9

LenovoFlex20All-In-OnePC

HardwareMaintenanceManual

MachineTypes:10142/F0A9

FirstEdition(August2013)30th

©CopyrightLenovo2013,2013.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwarearedeliveredpursuantaGeneralServices

Administration“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.

GS-35F-05925

Contents

Chapter1.Aboutthismanual......1

ImportantSafetyInformation..........1

Chapter2.Safetyinformation......3

Generalsafety................3

Electricalsafety...............3

Safetyinspectionguide............5

Handlingelectrostaticdischarge-sensitive

devices..................5

Groundingrequirements............6

Safetynotices................6

Chapter3.Generalinformation.....9

Specications................9

Chapter4.GeneralCheckout.....11

Chapter5.UsingtheSetupUtility...13

StartingtheLenovoBIOSSetupUtilityprogram.13

Viewingandchangingsettings........13

Usingpasswords..............13

Enablingordisablingadevice........15

Selectingastartupdevice..........16

Changingbootingmode...........17

ExitingtheLenovoBIOSSetupUtilityprogram..17

Chapter6.Symptom-to-FRUIndex..19

Harddiskdrivebooterror..........19

PowerSupplyProblems...........19

POSTerrorcodes.............20

Undeterminedproblems...........20

Chapter7.Locatingconnectors,

controlsandcomponents......21

Chapter8.Replacinghardware....25

Generalinformation.............25

Replacingthekeyboardandmouse......26

Replacingthepoweradapter.........26

Removingtherearcover...........28

Replacingthebattery............30

Replacingtheharddiskdrive.........31

Replacingthesystemfan..........34

Replacingtheheat-sink...........35

Replacingamemorymodule.........36

ReplacingtheWi-Ficard...........36

ReplacingtheI/Oboard...........37

Replacingthespeakersystem........38

ReplacingtheWindowsfunctionboard.....39

Replacingthemotherboard..........40

Replacingtheconverterboard........41

Replacingthecamera............42

ReplacingtheLEDpanelmodule.......45

Chapter9.FRUlists-Flex20.....47

Chapter10.AdditionalService

Information..............55

©CopyrightLenovo2013,2013iii

ivLenovoFlex20All-In-OnePCHardwareMaintenanceManual

Chapter1.Aboutthismanual

ThismanualcontainsserviceandreferenceinformationforLenovoFlex20All-In-Onecomputerslistedon

thecover.ItisintendedonlyfortrainedservicerswhoarefamiliarwithLenovocomputerproducts.

BeforeservicingaLenovoproduct,besuretoreadtheSafetyInformation.

ThedescriptionoftheTV-tunercardinthismanualappliesonlytocomputerswithaTV-tunercardinstalled.

ItdoesnotapplytocomputerswithoutaTV-tunercard.

ImportantSafetyInformation

BesuretoreadallCAUTIONandDANGERsectionsinthismanualbeforefollowinganyoftheinstructions.

VeuillezliretouteslesconsignesdetypeDANGERetATTENTIONduprésentdocumentavantd’exécuter

lesinstructions.

LesenSieunbedingtalleHinweisevomTyp“ACHTUNG”oder“VORSICHT”indieserDokumentation,bevor

SieirgendwelcheVorgängedurchführen

LeggereleistruzioniintrodottedaATTENZIONEePERICOLOpresentinelmanualeprimadieseguireuna

qualsiasidelleistruzioni

Certique-sedelertodasasinstruçõesdecuidadoeperigonestemanualantesdeexecutarqualquer

umadasinstruções

Esimportantequeleatodaslasdeclaracionesdeprecauciónydepeligrodeestemanualantesdeseguir

lasinstrucciones.

©CopyrightLenovo2013,20131

2LenovoFlex20All-In-OnePCHardwareMaintenanceManual

Chapter2.Safetyinformation

Thischaptercontainsthesafetyinformationthatyouneedtobefamiliarwithbeforeservicingacomputer.

Generalsafety

Followtheserulestoensuregeneralsafety:

•Keeptheareasaroundthecomputerclearandcleanduringandaftermaintenance.

•Whenliftinganyheavyobject:

1.Ensureyoucanstandsafelywithoutslipping.

2.Distributetheweightoftheobjectequallyacrossbothfeet.

3.Liftslowly.Nevermovesuddenlyortwistwhenyouattempttolift.

4.Liftbystandingorbypushingupwithyourlegmuscles;thisactionremovesthestrainfromthe

musclesinyourback.

Donotattempttoliftanyobjectsthatweighmorethan16kg(35lbs.)orobjectsthatyouthink

aretooheavyforyou.

•Donotperformanyactionthatwouldcreateahazardforthecustomer,orwouldmakethecomputer

unsafe.

•Beforeyoustartthecomputer,ensurethatotherservicerepresentativesandcustomerpersonnelarenot

inapositionthatwouldcreateahazardforthem.

•Placeremovedcoversandotherpartsinasafeplace,awayfromallpersonnel,whileyouareservicingthe

computer.

•Keepyourtoolcaseawayfromareasthatpeoplemaywalkthroughtoensureno-onetripsoverit.

•Donotwearlooseclothingthatcanbetrappedinthemovingpartsofamachine.Ensurethatyoursleeves

arefastenedorrolledupaboveyourelbows.Ifyourhairislong,tieorfastenitback.

•Inserttheendsofyournecktieorscarfinsideclothingorfastenitwithanonconductiveclip,approximately

8centimeters(3inches)fromtheend.

•Donotwearjewelry,chains,metal-frameeyeglasses,ormetalfastenersforyourclothing.

Remember:Metalobjectsaregoodelectricalconductors.

•Wearsafetyglasseswhenyouare:hammering,drillingsoldering,cuttingwire,attachingsprings,using

solvents,orworkinginanyotherconditionsthatmightbehazardoustoyoureyes.

•Afterservice,reinstallallsafetyshields,guards,labels,andgroundwires.Replaceanysafetydevice

thatiswornordefective.

•Reattachallcoverscorrectlybeforereturningthecomputertothecustomer.

Electricalsafety

CAUTION:

Electricalcurrentfrompower,telephone,andcommunicationcablescanbehazardous.Toavoid

personalinjuryorequipmentdamage,disconnectanyattachedpowercords,telecommunication

cables,networkcables,andmodemcablesbeforeyouopenthecomputercovers,unlessinstructed

otherwiseintheinstallationandcongurationprocedures.

©CopyrightLenovo2013,20133

Observethefollowingruleswhenworkingonelectricalequipment.

Important:Useonlyapprovedtoolsandtestequipment.Somehandtoolshavehandlescoveredwithasoft

materialthatdoesnotinsulateyouwhenworkingwithliveelectricalcurrents.Manycustomershaverubber

oormatsneartheirequipmentthatcontainsmallconductiveberstodecreaseelectrostaticdischarge.

•Findtheroomemergencypower-off(EPO)switch,disconnectingswitch,orelectricaloutlet.Ifanelectrical

accidentoccurs,youcanthenoperatetheswitchorunplugthepowercordquickly.

•Donotworkaloneunderhazardousconditionsornearequipmentthathashazardousvoltages.

•Disconnectallpowerbefore:

–Performingamechanicalinspection

–Workingnearpowersupplies

–RemovingorinstallingFieldReplaceableUnits(FRUs)

•Beforeyoustarttoworkonthecomputer,unplugthepowercord.Ifyoucannotunplugit,askthe

customertopower-offtheelectricaloutletthatsuppliespowertothemachineandtolocktheelectrical

outletintheoffposition.

•Ifyouneedtoworkonacomputerthathasexposedelectricalcircuits,observethefollowingprecautions:

–Ensurethatanotherperson,familiarwiththepower-offcontrols,isnearyou.

Remember:Anotherpersonmustbetheretoswitchoffthepower,ifnecessary.

–Useonlyonehandwhenworkingwithpowered-onelectricalequipment;keeptheotherhandinyour

pocketorbehindyourback.

Remember:Theremustbeacompletecircuittocauseelectricalshock.Byobservingtheaboverule,

youmaypreventacurrentfrompassingthroughyourbody.

–Whenusingatester,setthecontrolscorrectlyandusetheapprovedprobeleadsandaccessoriesfor

thattester.

–Standonsuitablerubbermats(obtainedlocally,ifnecessary)toinsulateyoufromgroundssuchas

metaloorstripsandmachineframes.

Observethespecialsafetyprecautionswhenyouworkwithveryhighvoltages;theseinstructionsarein

thesafetysectionsofthemaintenanceinformation.Useextremecarewhenmeasuringhighvoltages.

•Regularlyinspectandmaintainyourelectricalhandtoolstoensuretheyaresafetouse.

•Donotusewornorbrokentoolsandtesters.

•Neverassumethatpowerhasbeendisconnectedfromacircuit.First,checkthatithasbeenpoweredoff.

•Alwayslookcarefullyforpossiblehazardsinyourworkarea.Examplesofthesehazardsarewetoors,

non-groundedpowerextensioncables,conditionsthatmaycauseorallowpowersurges,andmissing

safetygrounds.

•Donottouchliveelectricalcircuitswiththereectivesurfaceofaplasticdentalmirror.Thissurfaceis

conductive,andtouchingalivecircuitcancausepersonalinjuryanddamagetothecomputer.

•Donotservicethefollowingpartswiththepoweronwhentheyareremovedfromtheirnormaloperating

positionsinacomputer:

–Powersupplyunits

–Pumps

–Blowersandfans

–Motorgenerators

andsimilarunits.(Thispracticeensurescorrectgroundingoftheunits.)

•Ifanelectricalaccidentoccurs:

–Usecaution;donotbecomeavictimyourself.

4LenovoFlex20All-In-OnePCHardwareMaintenanceManual
