Getting Started with
ThinkSmart View
Lenovo Smart Office | June 2020
2019 Lenovo Internal. All rights reserved.
ThinkSmartViewQuickSetup
1. Unbox the device and plug in AC adapter
2. Select the system language from the menu
3. Connect to your wireless network from the WLAN page
➢TIP: Turn the device to portrait (vertical) mode when logging
into a network to see more settings on screen
4. Pair a Bluetooth headset or select Skip
➢The Microsoft Teams screen will open
5. Tap Sign in or select Sign in from another device
6. Follow the prompts on screen to finish the process
➢Note: ThinkSmart View will register with the Company Portal /
Intune. For the first setup, Intune can take up to 10 minutes to
register the device depending on your IT Admin’s policies.
7. After registration, the main Teams screen will be shown
8. Go to Settings →Device Settings →Time & Date to change
your time zone and show the correct time
AC adapter
2020 Lenovo. All rights reserved.
2019 Lenovo Internal. All rights reserved.
ProductOverview
ThinkSmart View is a new device for business,
tailored to meet the needs of employees in evolving
workspaces. It expands the desktop canvas,
supports a range of complementary uses, and
radically improves videoconferencing and
collaboration.
✓Tablet-sized touchscreen appliance with two-
position design for portrait and landscape
✓Standalone and complementary uses with your PC
✓Crystal clear audio and 5MP camera
✓Enterprise-ready, Easy to manage
Display
8” touch display; Anti
-glare and Anti-fingerprint coating
Microphone
Integrated microphone array built into the top of the device
Speakers
1.75” 10W Full
-size speaker, Two passive tweeters
Ports
USB Type
-C (Service and Support only)
Processor
Qualcomm® Snapdragon™ 624, Octa
-Core A53 1.8 GHz, 14 nm
Operating System
Android Open Source Project 8.1
Sensors
G, P, and L sensors
Software
Microsoft Teams for IP Phones
Buttons / Switches
Volume Rocker, Microphone Mute Switch, Camera Privacy Shutter
2019 Lenovo Internal. All rights reserved.
Signingintothedevice
Getting signed into your device:
1. Select the system language from the menu
2. Select your WLAN network from the list and login
➢TIP: Turn the device to portrait mode when logging into a
network to see more settings on screen
3. Pair to Bluetooth headset or select Skip
4. The Microsoft Teams screen will open. Tap Sign in
5. You can Enter your credentials or Sign in from another device
➢By selecting Sign in from another device a code will be
displayed on screen
➢Go to https://microsoft.com/devicelogin on another device and
enter the code
6. ThinkSmart View will register with the Company Portal / Intune
and then take you to the Microsoft Teams home screen.
Notes:
➢Intune policies can take up to 10 minutes to register on your
device. During this time, Company Portal may appear to be cycling.
➢Be sure to go to Device Settings and change your time zone.
2019 Lenovo Internal. All rights reserved.
Appearance and Mechanical
2019 Lenovo Internal. All rights reserved.
Appearance and Mechanical
8” HD Display
Light/Proximity Sensor
5MP CameraFull Range
Speaker
2019 Lenovo Internal. All rights reserved.
Appearance and Mechanical
Camera
Privacy Shutter
Mute Switch Volume Buttons
Far field
Microphone array
Power adapter
2019 Lenovo Internal. All rights reserved.
Appearance and Mechanical
USB type-C Port Rubber
Note: Remove the rubber to reveal the port. This port
is only used by Lenovo service and support.
2019 Lenovo Internal. All rights reserved.
HomeScreen–Calendar
Calls View Calendar View Voicemail Screen
Create a meeting
One-touch Join
or Edit the meeting
Profile Options
and Settings
Search active
directory contacts
Meeting schedule
Meeting details
2019 Lenovo Internal. All rights reserved.
HomeScreen–Calls
Calls View Calendar View Voicemail Screen
Search and make a call
Setup favorites in Teams
desktop client
Profile Options
and Settings
Search active
directory contacts
Toggle between Favorites
and Recent calls
Dial Pad
(PSTN calling required)
