LENCO XEMIO-200 Manual de usuario

USER’S MANUAL

XEMIO-200

MP3/WMA PLAYER

www.lenco.com

XEMIO-200

USER MANUAL

Special Features

•Elegant appearance and easy to use.

•Multi-Code Player - Supporting MP1, MP2, MP3, WMA, formats.

•Driver Free U Disk - You may manage your files directly through

“Portable Device” in “My Computer” on Windows 2000 Operating

System or above without driver.

Brief View of Player

A. About player’s battery

Player has an internal, non–user-replaceable rechargeable

lithium battery. For best results, the first time you use the player, let

it charging for about 1 - 2 hours or until the charging LED lights go

Off before you use it.

Charging the Battery

You can charge the Player’s battery in two ways:

1. Connect player to your computer. Or,

2. Use the USB power charger. (available separately)

B. Insert Micro SD Memory Card

This device is design without an internal memory; put a Micro SD

memory card insert into the memory card slot before use the player.

•Plug in the Micro SD memory card into player card slot at side,

now you can use the player.

•You can upload your desired media files to the player, or, you can

upload your desired media files to the Micro SD memory Card

direct with your computer before insert it to the player.

•When you want to insert / remove the Micro SD memory card

from memory card slot. Make sure the player is in Off status.

Otherwise, the player functional may dead halt or the internal

data / files will be lost / damaged.

Note: The status indicator light will be flashing fast and then will go

Off, when you want to turn On the player. However, the player will

XEMIO-200

USER MANUAL

turn Off automatically If no memory card has inserted to player’s

card slot.

C. Key function of buttons

Appearance

•Power ON – OFF switch: Main Power On and Off

•button: To Play / Pause or Standby On / Off.

•button: To previous song or fast-backward.

•button: To the next song or fast-forward.

•button: To increase volume level.

•Button: To decrease volume level.

•USB: For PC connection and charge function

D. Getting start player

1 Turn On / Off

1.1 Plug in earphone set into player’s jack

1.2 Slide the Power ON – OFF to “ON” position, the player will

turn On and play music directly. (make sure the Micro SD

memory card has plugged

XEMIO-200

USER MANUAL

1.3 Press and hold button, for about 2 - 3 second, the

player will turn Off and On in standby mode.

2 Play / Pause Music

2.1 Press button to pause the playing music, press it again

to play.

2.2 If player is in pause state for 3 minutes, it will be turned to

Off automatically.

3 Adjust Volume

3.1 Pressing / button to increase or decrease volume

level.

3.2 Press and hold / button to increase or decrease

volume level faster.

3.3 For hearing protection; a beep warning will be heard from

earphone every time you increase the volume level and

reach to the default setting level, which may exceed 85dB.

Press button to accept the warning and press /

button again to increase the level until to maximum level.

4 Play Next / Previous Music

4.1 In playing mode, press button to select next music.

4.2 Press button to select previous music.

5 Play Fast-Forward / Fast-Backward

5.1 In playing mode, press and hold button to enter

fast-forward mode.

5.2 Press and hold button to enter fast-backward mode.

E. USB mode

1 Connect player to computer

1.1 Connect player to computer with the USB cable, then a

“USB Mass Storage Device” is detected and related driver

is installed by you computer. (Windows 2000 / XP System

or about)

1.2 A removable disk drive will be shown in “My computer”

XEMIO-200

USER MANUAL

folder, now you can start Read / Write operation. And the

battery is charging in background.

1.3 In connection mode, the player can be play music if you

press or pressing the play button. However, the player

may stop or start playing if removing the PC connection.

2 Remove player from computer:

Please safety to removes the player in computer, otherwise, the

data stored in the Player might loss.

2.1 If you’re using a Windows PC, you can disconnect the

player in My Computer or by clicking the “Safely Remove

Hardware” icon in the Windows system tray.

2.2 If you’re using a Mac, you can also disconnect player by

dragging the player icon on the desktop to the Trash.

2.3 And now, is safe to disconnect the player with your

computer, unplug the USB connector from player and then

your computer.

2.4 If you’re accidentally disconnect player without disconnect

it, reconnect it to your computer.

2.5 At power ON mode, after remove the PC connection, the

player will auto-play the music directly.

F. Indicator light function

•Playing Mode: LED light flashing once per second.

•Pause Mode: LED light bright.

•PC Connecting Mode: LED light bright. (Charging in

background)

•Recharging Mode: LED light bright.

•Recharge complete: LED light will go OFF

XEMIO-200

USER MANUAL

G. Troubleshooting

Play cannot turn

•Check whether battery have enough

energy.

•Check whether the main power ON-OFF to

slide to ON position or not.

No sound is

heard

•Check whether Volume is set to “minimum”

and connect the headphone plugs firmly.

•Check whether the headphone plug is dirty.

•Corrupted WMA / MP3 may make a static

noise and the sound may cut off. Make sure

that the music files are not corrupted.

•Check whether music files format are

support.

Download of

music files fails.

•Check whether player’s USB connector is

connected with computer properly.

•Check whether driver is installed correctly.

•Check whether the player’s memory is in

full.

•Check whether the Micro SD memory card

is inserted.

H. Specification

Dimension 43 mm (H) x 29.8 mm (W) x 15 mm (D)

Weight 14.5 g

PC Connection USB 2.0 (High Speed)

Earphone

Impedance

32 Ohm

Internal Memory Nil

External Memory Micro SD Memory Card (up to 8GB)

Battery Built-in Rechargeable Lithium battery (3.7V

110mA)

XEMIO-200

USER MANUAL

Playing Time: about 4-5 Hours

Supports Music

Format

MP3 32kbps - 320kbps

WMA 32kbps – 384kbps

Audio

Earphone Output

Power

L: 275mV (32 Ohm)

R: 275mV (32 Ohm)

Frequency

Response

20Hz – 20,000Hz

SNR 80dB

Operation

Temperature

-0℃- 40℃

Operation

Systems

Windows 98/SE/ME2000/XP/Vista/Win7,

MAC9.2 or above

Note: Product design and specification are subject to change

without prior notice.

XEMIO-200

USER MANUAL

Safety instructions

IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY

BEFORE USE.

CAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

CAUTION: TO PREVENT AN ELECTRICAL SHOCK, DO NOT

REMOVE ANY COVER SCREWS. THERE ARE NO USER

SERVICEABLE PARTS INSIDE. REQUEST A QUALIFIED

SERVICE PERSON TO PERFORM SERVICING.

This symbol indicates that there are important operating

maintenance instructions in the user manual

accompanying this tablet.

This symbol indicates that dangerous voltage is present

within this tablet, constituting a risk of electric shock or

personal injury.

XEMIO-200

USER MANUAL

Keep these instructions in mind:

Do not use this device near water.

Clean only with a slightly damp cloth.

Do not cover or block any ventilation opening. When placing the

device on a shelf, leave 5 cm (2”) free space around the whole

device.

Install in accordance with the supplied user manual.

Don’t step on or pinch the power cord. Be very careful,

particularly near the plugs and the cable’s exit point. Do not

place heavy items on the power cord, which may damage it.

Keep the entire device out of children’s reach! When playing

with the power cable, they can seriously injure themselves.

Unplug this device during lightning storms or when unused for a

long period.

Keep the device away from heat sources such as radiators,

heaters, stoves, candles and other heat-generating products.

Avoid using the device near strong magnetic fields.

ESD can disturb normal usage of this device. If so, simply reset

and restart the device following the instruction manual. During

file transmission, please handle with care and operate in a

static-free environment.

Safety instructions - continued

WARNING! NEVER INSERT AN OBJECT INTO THE

PRODUCT THROUGH THE VENTS OR OPENINGS. HIGH

VOLTAGE FLOWS THRU THE PRODUCT AND INSERTING

AN OBJECT CAN CAUSE ELECTRIC SHOCK AND/OR

SHORT CIRCUIT INTERNAL PARTS. FOR THE SAME

REASON, DO NOT SPILL WATER OR LIQUID ON THE

PRODUCT.

XEMIO-200

USER MANUAL

Do NOT use in wet or moist areas such as bathrooms, steamy

kitchens or near swimming pools.

Do not use this device when condensation may occur.

This tablet is produced according to all current safety regulations.

The following safety tips should safeguard users against careless

use and dangers involved with such use.

Although this device is manufactured with the utmost care and

checked several times before leaving the factory, it is still

possible that problems may occur, as with all electrical

appliances. If you notice smoke, an excessive build-up of heat

or any other unexpected phenomena, you should disconnect the

plug from the main power socket immediately.

This device must be well ventilated at all time!

This device must operate on a power source as specified on the

specification label. If you are not sure of the type of power

supply used in your home, consult your dealer or local power

company.

The socket outlet must be installed near the equipment and

must be easily accessible.

Do not overload AC outlets or extension cords. Overloading can

cause fire or electric shock.

Keep away from rodents. Rodents enjoy biting on power cords.

Always hold the plug when pulling it out of the main supply

socket. Do not pull the power cord. This can cause a short

circuit.

Avoid placing the device on any surfaces that may be subject to

vibrations or shocks.

When the device is not in use for long periods, unplug the AC

power cable for safety reasons.

Otros manuales para XEMIO-200

Tabla de contenidos

Otros manuales de Reproductor de MP3 de LENCO

LENCO

LENCO XEMIO-732 R Manual de usuario

LENCO

LENCO XEMIO-253 Manual de usuario

LENCO

LENCO Xemio-560 Manual de usuario

LENCO

LENCO HELLO KITTY MP3 Manual de usuario

LENCO

LENCO Xemio-769GY Manual de usuario

LENCO

LENCO XEMIO-125 Manual de usuario

LENCO

LENCO XEMIO-200 Manual de usuario

LENCO

LENCO XEMIO-106 Manual de usuario

LENCO

LENCO XEMIO-SPORT-222 Manual de usuario

LENCO

LENCO XEMIO-106 Manual de usuario

LENCO

LENCO XEMIO-145 Manual de usuario

LENCO

LENCO XEMIO-360 W Manual de usuario

LENCO

LENCO Xemio-241 Manual de usuario

LENCO

LENCO Xemio-659MIX Manual de usuario

LENCO

LENCO SCD-38 USB Manual de usuario

LENCO

LENCO Xemio-280 Manual de usuario

LENCO

LENCO MP BLASTER SNOOPY Manual de usuario

LENCO

LENCO CD-200 Manual de usuario

LENCO

LENCO Xemio-560 Manual de usuario

LENCO

LENCO XEMIO-107 Manual de usuario

LENCO

LENCO SCD-39 USB Manual de usuario

LENCO

LENCO XEMIO-857 Manual de usuario

LENCO

LENCO Xemio-154 Manual de usuario

LENCO

LENCO Xemio-861 Manual de usuario

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

AGPtek

AGPtek C2 Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario
