Leica GS10 Manual de usuario
Leica GS10/GS15
Quick Guide
Version 1.0
English
2
GS10/GS15, Important Information about your Instrument
1 Important Information about your Instrument
Read and follow the User Manual on the accompanying DVD before using the
product.
)Keep for future reference!
Intended use • Computing with software.
• Carrying out measurement tasks using various GNSS measuring techniques.
• Recording GNSS and point related data.
• Data communication with external appliances.
• Measuring raw data and computing coordinates using carrier phase and code
signal from GNSS satellites.
The product must not be disposed with household waste.
GS10/GS15, Important Information about your Instrument 3
Conformity
to national
regulations
For products which do not fall under R&TTE directive:
Conformity
to national
regulations
Hereby, Leica Geosystems AG, declares that the product/s is/are in
compliance with the essential requirements and other relevant provi-
sions of the applicable European Directives. The declaration of
conformity can be consulted at http://www.leica-geosystems.com/ce.
• FCC Part 15, 22 and 24 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the product GS10 is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC. The declaration of conformity can be consulted at
http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC (R&TTE)
can be placed on the market and be put into service without restric-
tions in any EEA member state.
• The conformity for countries with other national regulations not covered by the
FCC part 15, 22 and 24 or European directive 1999/5/EC has to be approved prior
to use and operation.
4
GS10/GS15, Important Information about your Instrument
Conformity
to national
regulations
• FCC Part 15, 22 and 24 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the product GS15 is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC. The declaration of conformity can be consulted at
http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC (R&TTE)
can be placed on the market and be put into service without restric-
tions in any EEA member state.
• The conformity for countries with other national regulations not covered by the
FCC part 15, 22 and 24 or European directive 1999/5/EC has to be approved prior
to use and operation.
GS10/GS15, Instrument Components 5
2 Instrument Components
GS10 components a) Bluetooth antenna
b) Guide rail for clip-on-housing of a
device (available on both sides)
c) Function button
d) ON/OFF button
e) LEMO port P3
f) Power port
g) Antenna port
h) LED indicators
i) Battery compartment A including SD
card compartment
j) Battery compartment B
k) LEMO port P2
l) LEMO port P1 including USB port
GS_081 bahijklcd ef g
6
GS10/GS15, Instrument Components
GS15 components
a) RTK device compartment including
port P3
b) RTK device LEDs
c) Battery compartment 2
d) LEDs, ON/OFF button and Function
button
e) LEMO port P1 including USB port
f) QN-connector for external UHF or
digital cellular phone antenna
g) LEMO port P2
h) Battery compartment 1 with SD
card slot
i) Mechanical Reference Plane (MRP)
GS_079
a
c
b
d
e
f
g
h
i
GS10/GS15, Instrument Components 7
Keyboard GS10
Keyboard GS15
a) ON/OFF button
b) Function button
GS_082
ab
a) ON/OFF button
b) Function button
GS_080
ab
8
GS10/GS15, Technical Data
3 Technical Data
Environmental
specifications
Temperature
Protection against water, dust and sand
IP67 (IEC 60529)
Humidity
Up to 100 %.
The effects of condensation are to be effectively counteracted by periodically drying
out the instrument.
Operating temperature [°C] Storage temperature [°C]
-40 to +65 -40 to +80
GS10/GS15, Care and Transport 9
4 Care and Transport
Care and transport • Carry the product in its original container or carry the tripod with its legs splayed
across your shoulder, to protect the product against shock and vibration.
10
GS10/GS15, Operation
5 Operation
)The battery must be charged before using it for the first time.
Turning on and off
the instrument
1
23
4
ON
OFF
3
4
GS_131
2
3
1
4
ON
OFF
5
5
