Leica MICA Manual de usuario

Leica Microsystems CMS GmbH. User Manual, 11xxxxxx, revision 1.0, 2021-12-15

MICA

User Manual

From Eye to Insight

Copyrights

Revision 1.0, edited 2020-12-15 by:

Leica Microsystems CMS GmbH

Ernst-Leitz-Strasse 17–37

D-35578 Wetzlar (Germany)

http://www.leica-microsystems.com

Responsible for contents:

Marketing CMS

Copyrights

All rights to this documentation are held by Lei-

ca Microsystems CMS GmbH. Reproduction of

text or illustrations (in whole or in part) by print,

photocopy, microfilm or other method (including

electronic systems) is not allowed without ex-

press written permission from Leica Microsys-

tems CMS GmbH.

The instructions contained in the following doc-

umentation reflect state-of-the-art technology.

We have compiled the texts and illustrations

as accurately as possible. Still, we are always

grateful for comments and suggestions regarding

potential errors within this documentation.

The information included in this manual may be

changed without prior notice.

Contents

1. Important Notes about this Manual.............4

2. Function............................................................6

3. Safety Notes.....................................................9

3.1 Important Information for Operators and

Users .................................................................9

3.2 General Safety Notes .....................................9

3.3 Electrical Safety ............................................10

3.4 Specifications of the Lasers

Installed in the Supply Unit..........................13

3.5 Laser Safety ...................................................13

3.5.1 Safety notes for handling the laser ............13

4. Transport and Storage..................................15

4.1 Transport ........................................................15

4.2 Ambient Conditions.......................................15

4.3 Installation Location .....................................16

4.4 Disposal ..........................................................17

5. Overview of the Instrument.........................18

5.1 Mica 18

5.1.1 Status LED ......................................................18

5.2 Supply Unit .....................................................20

5.3 Incubator ........................................................21

5.4 Auto Immersion ............................................21

5.5 CORR objectives ...........................................21

5.6 Antivibration Table........................................22

6. Instrument Setup...........................................23

6.1 Switching on ..................................................23

6.2 Notes on Handling the Instrument Hood...23

7. Operation........................................................24

7.1 Starting the software....................................24

7.2 Software help.................................................24

7.3 Online Help .....................................................24

7.4 The User Interface ........................................25

7.5 First Experiment.............................................33

8. Care ...............................................................34

9. EU-Declaration of Conformity.....................35

1. Important Notes about this Manual

(1.2)

→p. 20

Numbers in parentheses refer to illustrations; for

example, (1.2) refers to Fig. 1, item 2.

Numbers with a pointer arrow (for example

→page 20), point to a certain page of this man-

ual.

WARNING indicates a hazard with a medium

degree of risk that, if not avoided, can result

in death or serious injury.

CAUTION indicates a potentially hazardous

situation with a low degree of risk that, if not

avoided, may result in minor or moderate in-

jury.

Caution!

In this manual, additional safety notes are in-

dicated with the triangle symbol shown here,

and have a gray background.

Caution! The instrument and its accessories can

be damaged when operated incorrectly.

Text Symbols and Their Meanings:

Caution!

This User Manual is an essential component

of the product; it must be read carefully be-

fore the product is assembled, put into op-

eration or used, and must be kept for future

reference.

1. Important Notes about this Manual

This User Manual includes important instruc-

tions and information related to the operating

safety and maintenance of the instrument. .

WARNING

CAUTION

1. Important Notes about this Manual

Warning of hazardous electrical voltage! Danger

of electric shock!

Warning of optical radiation! Never look directly

into the light beam! Wear safety goggles!

Warning of electromagnetic field

Warning of UV radiation! Wear safety goggles!

Warning of hazardous laser radiation – take ap-

propriate safety precautions!

Warning of hand injuries

Instructions for disposing of the instrument,

its accessories and consumables.

Ground terminal

Explanatory note

Item not contained in all equipment configura-

tions

Manufacturing date, e.g. 11 / 2011 for November

2011

China RoHS 50 years EFUP

(Environmentally friendly use period)

MM/YYYY

2. Function

The entire system of which this User Manual is

part is intended for research applications. The

Leica microscope Mica is an inverted light mi-

croscope and intended for use as a general lab

microscope for routine examinations of biologi-

cal specimens.

Directives of the European Community (EU Di-

rectives)

The microscope described here fulfills the re-

quirements of EU Directives 2014/35/EU concern-

ing the safety of electrical equipment, 2014/30/EU

concerning electromagnetic compatibility and

the Machinery Directive 2006/42/EC.

According to the VO1194/2012 regulation regard-

ing the implementation of the Ecodesign Direc-

tive 2009/125/EC, microscopes are considered

special products. The light sources in this instru-

ment are special lamps which are only suitable

for microscopes. They are not suitable for gener-

al lighting purposes or room lighting.

Reasonably Foreseeable Misuse

The following are prohibited:

• To use the system for any purpose

not in accordance with the Declara-

tion of Conformity (e.g. the use of IVD or

medical products in accordance with

EU regulation 2017/746 or 2017/45

)

• Operating the system in an inclined position

• Cleaning the system in a way other than speci-

fied in the manual

• Modifying the built-in safety circuits in the in-

strument

• Allowing unauthorized personnel to open the

instrument

• Using cables that Leica Microsystems CMS

GmbH has not provided or permitted

• Using combinations with non-Leica compo-

nents that go beyond the scope of the manual

2. Function

Caution!

The manufacturer assumes no liability for

damage caused by, or any risks arising from,

using the microscope for other purposes than

those for which they are intended or not us-

ing them within the speciﬁcations of Leica

Microsystems CMS GmbH.

In such cases, the Declaration of Conformity

shall be invalid.

WARNING

Notes on Handling Laser Devices

In the standard design without additional la-

ser safety precautions, the microscopes are

not suitable for coupling laser radiation (such

as to the camera ports), since this radiation

poses a hazard for the user (eye injury in par-

ticular).

For use of the microscope with lasers, Leica

Microsystems CMS GmbH offers special mi-

croscope variants with additional safety fea-

tures. Laser couplings require corresponding

safety devices that have to be inspected and

installed by trained personnel.

For further information, please contact your

authorized Leica Microsystems CMS GmbH

representative.

WARNING

Due to the special sources of danger of the

laser system, only those persons may use the

system who have received special training in

working with the system, observing the spe-

ciﬁc hazards of a laser system.

CAUTION

Light sources pose a potential irradiation risk

(glare, UV radiation, IR radiation). Therefore,

lamps may only be operated in closed hous-

ing and in an installed condition.

Never look directly into the beam path

(blinding hazard).

2. Function

CAUTION

If the hood to the specimen area is open

and the UV LED (365nm) is switched on with

maximum conﬁgured intensity, a distance

between the eye and light outlet interface on

the objective of <10cm may result in a hazard

to the eye.

No hazard for the eye exists in the normal use

case (distance between eye and objective

>10cm).

When changing specimens with the UV LED

(365nm) switched on at maximum intensity,

be sure not to exceed a maximum exposure

time of the skin (hands) of 60 minutes a day.

(actinic UV hazard)

We recommend dimming/deactivating all

LEDs before opening.

3. Safety Notes

3.1 Important Information for Operators and

Users

• The owner/operator and user of this product

are responsible for proper and safe operation

and safe maintenance of the system and for

following all applicable safety regulations.

• The owner/operator and user are fully liable

for all consequences resulting from the use of

the system for any purposes other than those

listed in the User Manual or the online help.

• The owner/operator and user are obligated to

perform and monitor suitable safety measures

(according to national regulations).

• The owner/operator and user are responsible

for observing the laser safety regulations ac-

cording to applicable country-specific regula-

tions.

• The owner/operator and user must ensure that

this laser product is started up and operated

only by persons who have been trained in the

use of the system and the potential dangers of

laser radiation.

• The owner/operator and user are fully liable

for all consequences resulting from the use of

the system if it is opened, improperly serviced

or repaired by persons other than authorized

Leica service representatives.

3.2 General Safety Notes

This protection class 1 instrument was built and

tested in accordance with

EN 61010-1/IEC 61010-1, Safety requirements for

electrical equipment for measurement, control

and laboratory use.

It also meets the requirements of EN / IEC 61326-

1, Electrical equipment for measurement, control

and laboratory use – EMC requirements.

The product has also been tested in accordance

with EN 60825-1 / IEC 60825-1 Safety of laser

products

Part 1: Equipment classifications and require-

ments checked.

The products were also tested in accordance

with IEC 62471 "Photobiological safety of lamps

and lamp systems" and are a risk of risk group

2 (medium risk). Observe the warning message

regarding optical radiation on the previous page.

Caution!

In order to maintain this condition and to en-

sure safe operation, the user must follow the

instructions and warnings contained in this

User Manual.

Also note the provided User Manuals of other

components (e.g. incubator, Mot.Corr, etc.).

3. Safety Notes

The instruments and accessories described

in this manual have been safety-tested and

checked for possible hazards.

The responsible Leica Microsystems CMS

GmbH afﬁliate or the main plant in Wetzlar

must be consulted whenever the instrument

is altered, modiﬁed or used in conjunction

with non-Leica components that go beyond

the scope of this manual.

Unauthorized alterations to the device or

noncompliant use shall void all rights to any

warranty claims and product liability!

In addition to this manual, the safety notes

of the other manuals provided must be ob-

served!

The system may be set up, installed and put

into operation only by authorized Leica per-

sonnel!

Caution!

The microscope may be operated by autho-

rized personnel only.

3.3 Electrical Safety

General Speciﬁcations

In addition, observe the information about the

specifications in the other User Manuals provid-

ed!

Supply Unit

For indoor use only.

Supply voltage: 100 to 240 VAC

Frequency: 50 / 60 Hz

Power consumption: max. 220 VA

Fuses: 4 A, slow-blowing,

Breaking capacity H, 250 VAC,

Size: 5x20 mm

Ambient temperature: 15 – 35 °C

Relative humidity: 90 % up to 30 °C,

non-condensing

Protection class: I

Overvoltage category: II

Pollution degree: 2

Tabla de contenidos

Otros manuales de Equipo de laboratorio de Leica

Leica

Leica CM3600 XP Manual de usuario

Leica

Leica CryoJane Manual de usuario

Leica

Leica TP1020 Manual de usuario

Leica

Leica VT1000S Manual de usuario

Leica

Leica RM2235 Manual de usuario

Leica

Leica ST4020 Manual de usuario

Leica

Leica HistoCore Arcadia C Manual de usuario

Leica

Leica RM2145 Manual de usuario

Leica

Leica ASP300 S Manual de usuario

Leica

Leica VT1200 Manual de usuario

Leica

Leica CV5030 Manual de usuario

Leica

Leica TCS SP8 Manual de usuario

Leica

Leica Ivesta 3 Series Manual de usuario

Leica

Leica RM2235 Manual de usuario

Leica

Leica CM1510 Manual de usuario

Leica

Leica EG F Manual de usuario

Leica

Leica LED1 Manual de usuario

Leica

Leica VT1200 Manual de usuario

Leica

Leica Viva GNSS Manual de usuario

Leica

Leica CM1950 Manual de usuario

Leica

Leica Aperio ImageScope DX Manual de usuario

Leica

Leica AutoStainerXL Manual de usuario

Leica

Leica RM CoolClamp Manual de usuario

Leica

Leica CM1520 Manual de usuario

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario
