LEGRAND PREMIUS 7.5kVA Manual de usuario

PREMIUS

7.5 kVA - 20 kVA UPS

User Manual

2PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

FOREWORD

Summary

Thank you for choosing Numeric UPS.

This document gives a description of the PREMIUS UPS,

including the features, performance, appearance, structure,

working principles, installation, operation, and maintenance,

etc.

Please save the manual after reading, for future references.

NOTE

The ﬁgures in this manual are just for reference, for details

please see the actual product.

PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

Symbol Conventions

The manual quotes the safety symbols, used to prompt users to comply with safety matters during installation,

operation, and maintenance. Safety symbol meaning as follows,.

Symbol Description

DANGER Alerts you to a high-risk hazard that could, if not avoided, result in serious

injury or death.

WARNING Alerts you to a medium or low risk hazard that could, if not avoided, result in

moderate or minor injury.

CAUTION

Alerts you to a potentially hazardous situation that could, if not avoided, result

in equipment damage, data loss, performance deterioration, or unanticipated

results.

Anti-static prompting.

Be careful of electric shock prompting.

TIP Provides a tip that may help you solve a problem or save time.

NOTE Provides additional information to emphasize or supplement important points

in the main text.

4PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

1 Safety Description 6

1.1 Safety Announcements 6

1.1.1 Safety Instructions 6

1.1.2 User Instructions for Battery 6

1.1.3 Anti-Static Protection 7

1.2 Operation and Maintenance Requirements 7

1.3 Environment Requirements 7

2 Overview 8

2.1 Product Introduction 8

2.1.1 Model Conﬁguration 8

2.1.2 Appearance 8

2.1.3 Operation panel 8

2.1.4 Fittings Illustration 10

2.2 Optionals 11

2.2.1 Distribution Module 11

3 Installation 13

3.1 Unpacking and Checking 13

3.2 Installation Preparation 13

3.2.1 Select Breaker & Wires 13

3.2.2 Select Input Breaker 13

3.2.3 Select Wires 14

3.3 Mechanical Installation 16

3.3.1 Tower-mounting 16

3.3.2 Rack-mounting 16

3.4 Electrical Connection 17

3.4.1 Wiring Operation of PREMIUS

Series (7.5kVA-20kVA) UPS 18

3.4.2 Wiring Between UPS and Battery Box 18

3.4.3 Wiring Between UPS and Distribution

Module of PREMIUS Series

(7.5kVA-20kVA) UPS 19

3.4.4 Wiring of Parallel System 20

4 Screen Operation 22

4.1 Menu Hierarchy 22

4.2 Main Page 23

4.3 System Working Status Display 23

4.4 Monitoring Page 24

4.5 Setting Page 24

4.6 Management Setting 25

4.6.1 Parameter Setting 25

4.6.2 Function Setting 26

4.6.3 Screen Setting 27

5 Use and Operation 29

5.1 Check Before Startup 29

5.2 Startup Operation 29

5.3 Shutdown Operation 29

5.4 Periodic Preventative Maintenance 29

5.5 Battery Maintenance 30

5.6 Troubleshooting 30

5.6.1 Common Fault 30

6 Package, Transportation and Storage 34

6.1 Package 34

6.2 Transportation 34

6.3 Storage 34

CONTENTS

Index

6PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

1 Safety Description

This chapter introduces the safety announcements. Prior to performing any work on the UPS, please read the

user manual carefully to avoid human injury and device damage by irregular operations.

1.1 Safety Announcements

This section introduces the safety announcements that must be complied with and pay special attention while

installing, using, maintenance and other relative operations.

CAUTION!

Before operating, please read the announcements and operation instructions in this

section carefully to avoid accident.

The DANGER, WARNING, CAUTION, etc. in the manual are not all the safety announcements

that you must abide by, they are just the supplements for the safety announcements

during operating.

NOTE!

Our company does not undertake the responsibility caused by violating common safety

operation requirements or the safety standard of design, manufacture, and use.

1.1.1 Safety Instructions

CAUTION!

There exists high temperature and high voltage inside the UPS. During usage, strictly

comply with all warnings and operation instructions on the UPS and in the user manual.

CAUTION!

The UPS is class C3 device. If it is used in residential purpose, it may cause wireless

interference. User should take actions to avoid the interference.

• No liquid or other objects should be allowed to enter the UPS.

• UPS must be well grounded.

• In case of ﬁre, please use dry powder ﬁre extinguisher. If liquid ﬁre extinguisher is used, it may cause

electric shock.

1.1.2 User Instructions for Battery

CAUTION!

Please use speciﬁed battery. Non-speciﬁed battery will damage the UPS.

• Only authorized professional can replace battery. Do not wear conductive objects, such as watches,

bracelets, and rings while handling. Wear rubber shoes and gloves and use tools with insulated

handle.

• Don't put tools or other conductive objects on the battery.

• Shorting the positive and negative poles of the battery or connecting them in reverse is prohibited.

This is done to prevent the risk of ﬁre or electric shock.

PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

• Before connecting or disconnecting the battery terminals, disconnect the charger ﬁrst.

• The battery must be of the same type, model and manufacturer.

• Battery should be kept away from ﬁre source or other electrical equipment that may easily cause

spark to avoid human injury.

• Don't open or destroy the battery. The electrolyte in the battery includes strong acid, which will be

harmful to skin and eyes. If you come in contact with the acid, clean it by running water immediately

and visit the hospital.

• The waste battery should be disposed according to the local regulations.

1.1.3 Anti-Static Protection

CAUTION!

The static electricity generated by human bodies may damage the electrostatic-

sensitive components on PCB. Before touching the sensitive component, please wear

anti-static device and connect the other end of the anti-static device to the ground.

1.2 Operation and Maintenance Requirements

CAUTION!

Only authorized professionals are allowed to open the UPS chassis, or it may cause

electric shock and failure of the UPS. This will make it out of warranty.

• If the UPS needs to be moved, rewired, or maintained, disconnect all electrical connections, including

AC power, battery power, etc., to isolate the power input. Do not work on the UPS until it has been

completely powered off (wait for at least 10 minutes). Otherwise, there may still be electricity present

in the output, which could lead to an electric shock.

• When dismantling the fan, avoid placing your ﬁngers or tools into the rotating fan to prevent damage

to the device or injury to yourself.

1.3 Environment Requirements

DANGER

Do not place the UPS in an environment where there is inﬂammable, explosive gas,

or smog. Avoid conducting any operations in such an environment.

• Avoid using the UPS in places with direct sunlight, rain, or moisture.

• The normal operating temperature range for the UPS is 0ºC to 40ºC, with a relative humidity of 0%

to 95%, and without condensation (the recommended operating temperature is 20ºC to 25ºC with a

humidity of about 50%).

• Place the UPS on a ﬂat, vibration-free surface with a vertical gradient of less than 5°. Ensure there

is good ventilation around the UPS. Maintain a clearance of at least 300mm to 500mm between the

rear or sides of the UPS and adjacent devices or walls. Insufﬁcient ventilation can lead to increased

temperatures inside the UPS, potentially reducing the lifespan of internal components and affecting

the overall UPS lifespan.

• The UPS must be operated at altitudes below 2000m. If the altitude exceeds 2000m, it is necessary to

reduce the rated power in accordance with IEC62040-3:2011 before usage.

8PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

2. Overview

This chapter primarily introduces the UPS, explaining its model signiﬁcance, features, structure, working

principle, and more.

2.1 Product Introduction

The PREMIUS series UPS is a high-frequency, pure online, double-conversion, intelligent product. This

comprehensive power solution offers exceptional security for ﬁle servers, enterprise servers, central servers,

microcomputers, concentrators, telecom systems, data centers, and other applications that demand high-

quality power protection. Its usage spans various critical business sectors, including postal services, ﬁnance,

networking, stock exchanges, railways, and more.

2.1.1 Model Conﬁguration

The PREMIUS series UPS, available in capacities ranging from 7.5kVA to 20kVA, provides support for both three-

phase input single-phase output (3:1) mode, designated as 31 mode UPS, and single-phase input single-phase

output (1:1) mode, referred to as 11 mode UPS.

2.1.2 Appearance 2.1.3 Operation panel

Figure1-1 Appearance Figure1-2 Operation panel

Table 1-1 Illustration for operation panel

No. Name Illustration

Illustration for operation panel

LCD display Shows the working status and system setting.

"<" page up button and power off

LED indicator

Short press "<" button, the LCD will enter previous page or previous

option.

" " function button and

breathing light

• Short press " " button to conﬁrm the command of the current

LCD page.

• Long press " " button for 3s, will entry the parameter and

function setting page.

• When UPS is on, " " button will be in a cycle of light up to fade

out.

">" page up button and power on

LED indicator Short press ">" button, the LCD will enter next setting page.

PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

Combination buttons operation instructions

Power off Press the "<" and " " button at the same time, the UPS off and the

corresponding indicate LED is on.

Power on Press the ">" and " " button at the same time, the UPS on and the

corresponding indicate LED is on.

Rear panel – PREMIUS series (7.5kVA-20kVA)

Parallel port (Optional)

RS485

Intelligent slot

EPO input dry contact

Maintenance bypass switch status

detection

Wiring terminal

Figure1-3 Rear panel of PREMIUS series (7.5 kVA – 20 kVA)

NOTE!

• The wiring terminals for the 31 mode exhibit slight differences. For speciﬁc

information regarding the wiring terminals for each mode, please refer to Section

3.4.1 Wiring Operations.

• The intelligent slot is an optional feature and includes the following components:

a built-in SNMP card, an RS485 + dry contact card, and a communication protocol

transfer card.

• If the BMD (Bypass Maintenance Device) and EPO (Emergency Power Off) detection

functions are not required, kindly short the ports using the provided 4P terminal.

When these functions need to be activated, remove the short wire from the BMD or

EPO port and connect it to the corresponding status signal input on the maintenance

bypass breaker or EPO system.

CAUTION!

• The UPS can operate normally only when both the bypass maintenance switch state

detection (BMD) and the EPO port are separately shorted.

• If the BMD port is disconnected, the UPS will switch to bypass power supply mode,

and simultaneously, the LCD will display a BMD fault notiﬁcation. Upon reconnecting

the port with a short connection, the fault will automatically clear.

• In the case of the EPO port being disconnected, the UPS will initiate a shutdown

of both the inverter and bypass output. Simultaneously, the LCD will indicate an

EPO fault. To rectify this, the UPS must be completely powered down, and the EPO

port should be short-circuited. Following this action, the fault will be automatically

cleared.

10 PREMIUS 7.5 KVA - 20 KVA UPS USER MANUAL

2.1.4 Fittings Illustration

• PREMIUS series (7.5 kVA – 20 kVA)

The PREMIUS series UPS (7.5 kVA – 20 kVA) and distribution module are equipped with four types of copper bars,

detailed in Table 1-2. Users have the ﬂexibility to connect the appropriate copper bar to the corresponding wiring

arrangement following the installation of the UPS or distribution module. This conﬁguration can be adjusted to

the 31 mode based on the user's requirements.

Table1-2 Copper bar illustration

Copper bar No. Illustration Sketch map

1# 2PIN copper bar

2# 2PIN copper bar

3# 3PIN copper bar

4# 3PIN copper bar

Figure1-4 Installation 31 mode copper bar position of PREMIUS series (7.5kVA-20kVA)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unión Postal Universal de LEGRAND

LEGRAND

LEGRAND KEOR MOD Manual de usuario

LEGRAND

LEGRAND Niky S 1 kVA Manual de usuario

LEGRAND

LEGRAND Seismic Kit Trimod HE Manual de usuario

LEGRAND

LEGRAND Inform SINUS EVO Manual de usuario

LEGRAND

LEGRAND KEOR T EVO 10-60 KVA Manual de usuario

LEGRAND

LEGRAND KEOR SPE R/T Manual de usuario

LEGRAND

LEGRAND MIDDLE ATLANTIC NEXSYS Manual de usuario

LEGRAND

LEGRAND KEOR T 208V 40 KVA Manual de usuario

LEGRAND

LEGRAND KEOR SPE TOWER Series Manual de usuario

LEGRAND

LEGRAND KEOR COMPACT Manual de usuario

LEGRAND

LEGRAND KEOR LP Manual de usuario

LEGRAND

LEGRAND DAKER DK Plus 3 101 73 Manual de usuario

LEGRAND

LEGRAND MyHOME F455 Manual de usuario

LEGRAND

LEGRAND 3 108 43 Manual de usuario

LEGRAND

LEGRAND NUMERIC 2000 HR-V IBB 28AH Manual de usuario

LEGRAND

LEGRAND Trimod HE Guía de referencia

LEGRAND

LEGRAND 430 557 Manual de usuario

LEGRAND

LEGRAND KEOR TOWER SPE Manual de usuario

LEGRAND

LEGRAND KEOR MOD Manual de usuario

LEGRAND

LEGRAND KEOR COMPACT Manual de usuario

LEGRAND

LEGRAND KEOR T Manual de usuario

LEGRAND

LEGRAND 678 135 Manual de usuario

LEGRAND

LEGRAND Trimod 10 kVA Manual de usuario

LEGRAND

LEGRAND 332 75 Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario

ZincFive

ZincFive BC Series Manual de usuario
