LEGRAND 0 676 95 Manual de usuario

Cat. No(s): 0 676 95

Technical data sheet: F03167EN/01 Updated: 13/01/2021 Created: 15/06/2020

1/2

Pocket remote control 4 scenarios

128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex

Tel: +33(0)5 55 06 87 87 - Fax: +33(0)5 55 06 88 88

www.legrand.com

4. FONCTIONNEMENT

5. TECHNICAL CHARACTERISTICS

 5.1 Mechanical characteristics

Protection against impacts: IK 02

Protection against solid bodies and liquids: IP 20

 5.2 Material characteristics

Housing and front cover: ABS

Halogen-free

UV resistant

 5.3 Electrical characteristics

Battery life: 8 years for 10 activations a day

Frequency band: 2.4 to 2.44835 GHz

Power level: < 100 mW

 5.4 Climate characteristics

Usage temperature: + 5°C to + 45°C

Storage temperature: 0°C to + 45°C

1. USAGE

Allows control of all connected wired controls (lights, appliances, roller

shutters).

Requires the prior installation of a starter pack for connected installation

or a Control modul.

With keychain hook.

3. DIMENSIONS (mm)

2. RANGE

A B C

76 50.5 21

B C

Description Graphite

Connected poket remote control, 4 congurable scenarios.

Supplied with battery.

With LED indicator (conguration) and RESET button

(hidden) used to return to factory settings.

0 676 95

RESET button used to

return to factory mode

LED indicators:

- useful during installation

- when pressed, burst flash red if

the battery power is low 1

Congurable

scenarios

2/2

Technical data sheet: F03167EN/01 Updated: 13/01/2021 Created: 15/06/2020

Cat. No(s): 0 676 95

Pocket remote control 4 scenarios

6. CARE

Clean the surface with a cloth.

Do not use acetone, tar-removing cleaning agents or trichloroethylene.

Resistant to the following products: Hexane (EN 60669-1), methylated

spirit, soapy water, diluted ammonia, bleach diluted to 10%, window-

cleaning products, pre-impregnated wipes.

Take care to recycle the battery appropriately

7. STANDARDS AND APPROVALS

The undersigned, LEGRAND, declares that the radio-electric equipment

type (0 676 95) complies with directive 2014/53/EU.

The full text of the EU declaration of conformity is available on the

following website: www.legrandoc.com.

Compliant with installation and manufacturing standards.

See e.catalogue.

Caution: Always test before using special cleaning products.
