Laserworld Ecoline Series Manual de usuario
Manual / Bedienungsanleitung /
Mode d´emploi
Ecoline Series
EL-350RG
Please spend a few minutes to read this manual fully
before operating this laser!
Bitte lesen Sie diese Bedienungsanleitung sorgfältig
vor Inbetriebnahme dieses Showlasersystems!
Avant d’utiliser cet appareil pour la première fois nous vous recommandons
de lire cette notice d’utilisation!
02/2016
English
Deutsch
Français
Manual: Ecoline Series EL-350RG
page 2 / 24
Rechtlicher Hinweis:
Die Firma Laserworld (Switzerland) AG behält sich das Recht vor, Änderungen an ih-
ren Produkten vorzunehmen, die der technischen Weiterentwicklung dienen. Die-
se Änderungen werden nicht notwendigerweise in jedem Einzelfall dokumentiert.
Diese Betriebsanleitung und die darin enthaltenen Informationen wurden mit der
gebotenen Sorgfalt zusammengestellt. Die Firma Laserworld (Switzerland) AG über-
nimmt jedoch keine Gewähr für Druckfehler, andere Fehler oder daraus entstehende
Schäden. Die in dieser Bedienungsanleitung genannten Marken und Produktnamen
sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Titelhalter.
Legal notice:
Thank you for purchasing this Laserworld
product. Due to continual product developments and technical improvements, La-
serworld (Switzerland) AG reserves the right to make modications to its products.
This manual and its content have been made with due care but Laserworld (Swit-
zerland) AG cannot however, take any responsibility for any errors, omissions or any
resulting damages forthwith. The brands and product names mentioned in this ma-
nual are trade marks or registered trade marks of their respective owners.
Information juridique :
L’entreprise Laserworld (Switzerland) AG se réserve le droit d’eectuer des modica-
tions concernant leurs produits et ainsi de répondre au développement technique.
Ces modications ne seront pas nécessairement annoncées en tout cas spécique.
Ce mode d’emploi et les informations contenues dedans ont été établis avec le soin
minutieux qui s’impose dans ce cas.
Laserworld (Switzerland) AG ne pourra pas être tenue responsable pour d’éventuelles
erreurs d’impression ou dommages en résultants.
En cas de doutes, veuillez toujours contacter Laserworld (Switzerland) AG . Les noms
de marques et de produits utilisés dans ce mode d’emploi sont des marques de fab-
rique ou des marques déposées.
L’utilisation est réservée à un usage professionnel selon décret n°2007-665 du
2 mai 2007 relatif à la sécurité des appareils à laser sortant!
Article 4 bis :
« Les usages spéciques autorisés pour les appareils à laser sortant d’une classe su-
périeure à 2 sont les usages professionnels suivants :
(…)
9° Spectacle et achage :
Toutes les applications de trajectoire, de visualisation, de projection ou de reproduc-
tion d’images en deux ou trois dimensions. »
Manual: Ecoline Series EL-350RG
page 3 / 24
Content:
1. Product and package contents
2. Preliminary warning notices
3. Initial operations, safety instructions
4. Working on the device
5. Service notes
6. Warnings and other notices on the device
7. Device connections
8. Operation
Final statement
Technical data sheet
Laser specications
Manual: Ecoline Series EL-350RG
page 4 / 24
1. Product and package contents
Please check if all listed parts are included and undamaged. Included in delivery:
1 x laser projector 1 x manual
1 x power cable 2 x key
3. Initial operations, safety instructions
1. Make sure to use correct voltage; see in-
formation on device & in this manual.
2. Make sure that the device is not connec-
ted to mains during installation.
3. Installation has to be done by technical
experienced and qualied persons ac-
cording to safety regulations of the res-
pective country.
4. Always ensure that maximum permis-
sible exposure (MPE) is not exceeded
in areas accessible to the public.
5. In some countries an additional ins-
pection by technical control institutes
could be necessary.
6. Connect an easily accessible inter-
lock connector or circuit breaker
to the projector.
7. The power supply should be easily acces-
sible.
8. When installing the laser mount it with
a minimum distance of 15 cm from walls
and objects.
9. For safe setup e.g. on walls or ceilings
please use a safety cord. The safety cord
should be able to withstand tenfold the
weight of the device. Please follow the
accident prevention regulations of pro-
fessional associations and/or comparable
regulations for accident prevention.
10. If the device has been exposed to great
temperature changes, do not switch it
on immediately. Condensation (or any
moisture/water formed) may damage de-
vice.
2. Preliminary warning notices
1. Please use this device only according to these operating instructions.
2. Do not use the device if there are any visible damages on housing, connector panels,
power supplies or power cords.
3. Never look directly into the light source of a laser projector. Danger of damage to the
eyes or even blindness in extreme circumstances!
4. Do not operate the device at high humidity, in the rain or in dusty environments.
5. Protect device against dripping or splashing water. Do not place any liquid lled
containers near to this device.
Any warranty claims are void if the warranty label is removed or tampered
with in any way.
Manual: Ecoline Series EL-350RG
page 5 / 24
11. Never use dimmer, RC or other electroni-
cally switched sockets. Whenever possib-
le, do not use the laser projector together
with large appliances (especially fog ma-
chines) on the same mains!
12. Ensure sucient ventilation and do not
place the device on any warm or heat ra-
diating surface. Especially the ventilati-
on openings must not be covered!
13. Ensure that device does not get over-
heated. Make sure that the device is not
exposed to spotlights (especially moving
heads). Heat of spotlights could overheat
laser in a little while and leads to a degra-
dation of performance.
14. This unit is intended for indoor use only.
4. Working on the device
1. This product has no user serviceable parts inside and should
only be maintained and serviced by a qualied engineer.
2. Be sure that the mains plug is not connected to the power
supply while installing or opening the device (e.g. for
cleaning).
3. Take o all reecting things like rings, watches etc. befo-
re starting to work with or at the projector.
4. Only use non-reecting tools to work on device.
5. Wear protective clothing (like goggles, gloves etc.) according to laser power and wave-
length of the laser.
5. Service notes
• Moisture and heat can reduce lifetime of
the laser system dramatically and expires
any warranty claim.
• Quick on/o switching of this device will
reduce durability of the laser diode dra-
matically.
• Avoid sharp knocks and shocks to this
device and ensure sucient protection
during transportation. Look after your La-
serworld product.
• To increase durability of your laser,
protect device against overheating:
-Always ensure sucient ventilation.
-Do not face spotlights (especially mo-
ving heads) to the device.
-Check temperature after approx. 30
minutes with each new installation.
If necessary install the projector at a
place with dierent temperature.
-Keep the device dry. Protect it from
moisture, rain and damp.
-Switch o device when it is not nee-
ded. Diodes are switched on and can
wear out even if there is no visible la-
ser output.
• If there are traces of fog uid in the pro-
jector, clean it and change the position of
the fog machine.
• The devices of Ecoline, Evolution, Club
and Proline Series are not meant for pro-
Manual: Ecoline Series EL-350RG
page 6 / 24
fessional applications. After approx. one
hour of operation, the device should cool
down for about 15 minutes.
• Removal of the warranty label as well
as damages to the device caused by
improper handling, neglect of the sa-
fety instructions and service notes will
void the warranty.
6. Warnings and other notices on the device
Laser radiation!
Avoid exposure
to beam.
Laser class 3b
Caution of
radiation if cover
is removed
Power supply
& consumption
Model type
Wavelength
Output power
Production
year
Please read manual before operation
Use in enclosed spaces only!
7. Device connections
connection for
power supply
DMX addressDMX out DMX in
Fan
Key switsch On-/O switsch
Interlock
Manual: Ecoline Series EL-350RG
page 7 / 24
8. Operation
1. Connect the power cable to the device and then to the mains
2. Insert key and turn it ‚ON‘ (depending on the device)
3. Your device runs in auto mode:
4. Your device runs in music mode:
Control the music-sensitivity by the trim pot at the front side of the device. The LED is
ashing when the device is triggered.
5. Your device runs in DMX mode if ‘10‘ is switched o:
Connect a DMX controller to operate the laser.
Use the switches 1 - 10 to set the DMX address of the laser. Each switch represents a
number. To dene a number use the preceding number and multiply it by 2:
The laser uses 9 DMX channels, so make sure that the next device uses an address that
doesn’t overlap with this range.
Switch 12345678910
Number 1 2 4 8 16 32 64 128 256 Mode Switch
Manual: Ecoline Series EL-350RG
page 8 / 24
Channel Value Function
1 0 - 63 Laser o
64 - 127 Sound mode
128 - 191 Automatic mode
192 - 255 DMX mode
2 0 - 255 Pattern selection
3 0 - 255 strobe eect
4 0 - 255 -
5 0 - 255 vertical movement
6 0 - 255 horizontal movement
7 0 - 255 size
8 1 - 101 red and green
102 - 199 red
200 - 255 green
9 >200 Reset above 200 (shortly)
10 0 - 255 rotation y-axis
11 0 - 255 rotation x-axis
12 0 - 255 rotation z-axis
Please note that not each pattern can be combined with each eect.
6. To turn o the device switch the key to‚OFF‘ (depending on the device) and disconnect
the power cable from the mains.
Manual: Ecoline Series EL-350RG
page 9 / 24
Final statement
Laserworld products are tested and product packaging is inspected before leaving
our warehouse. Users must to follow the local safety regulations and warnings within
this manual and adhere to any regulations within its place of use. Damages through
inappropriate use will void any liability or warranty of our products. Due to continual
product developments, please check for the latest update of this product
manual at www.laserworld.com. If you do have any further questions, then please
contact your dealer/place of purchase or use our contact section on our website.
For service issues, please contact your dealer/place of purchase and ensure only ge-
nuine Laserworld spare parts are used in any service repairs.
Errors and omissions excepted and products are subject to change.
Laserworld (Switzerland) AG
Kreuzlingerstrasse 5
8574 Lengwil
SWITZERLAND
Registered oce:
8574 Lengwil / Switzerland
Company number: CH-440.3.020.548-6
Commercial Registry Kanton Thurgau
CEO: Martin Werner
VAT no. (Switzerland): 683 180
UID (Switzerland): CHE-113.954.889
VAT no. (Germany): DE258030001
WEEE-Reg.-No. (Germany): DE 90759352
www.laserworld.com
representative according to EMVG:
Ray Technologies GmbH
Managing Director: Karl-Heinz Käs
Mühlbachweg 2
83626 Valley / Germany
Manual: Ecoline Series EL-350RG
page 10 / 24
Inhaltverzeichnis:
1. Lieferumfang & Hinweise
2. Einleitende Warnhinweise
3. Schritte zur Inbetriebnahme, Sicherheitshinweise
4. Sicherheitshinweise für Arbeiten am Gerät
5. Pege- und Wartungshinweise
6. Warnhinweise und Spezikationen am Gerät
7. Geräteanschlüsse & Bedienelemente
8. Bedienung
Abschließende Erklärung
Technische Daten
Laserleistungsdaten
Otros manuales para Ecoline Series
15
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Idiomas:
Otros manuales de Equipo de iluminación de Laserworld
Laserworld
Laserworld Evolution Series ES-800S RGB 3D Instrucciones de montaje
Laserworld
Laserworld EL-200S DMX Manual de usuario
Laserworld
Laserworld Proline PRO-800RGB Manual de usuario
Laserworld
Laserworld PRO-350R-650 Manual de usuario
Laserworld
Laserworld CS-4000RGB FX MK2 Manual de usuario
Laserworld
Laserworld GREEN-150A Manual de usuario
Laserworld
Laserworld GREEN-15000 Manual de usuario
Laserworld
Laserworld PL-4500 RGB US Manual de usuario
Laserworld
Laserworld Club Series Manual de usuario
Laserworld
Laserworld PL-5000G Manual de usuario
Laserworld
Laserworld EL-150B Manual de usuario
Laserworld
Laserworld BLUE-4500-445 Manual de usuario
Laserworld
Laserworld BLUE-300-473 Manual de usuario
Laserworld
Laserworld PL-2000RGB Manual de usuario
Laserworld
Laserworld EL-500RGB KeyTEX Manual de usuario
Laserworld
Laserworld CS-8000RGB FX MK2 Manual de usuario
Laserworld
Laserworld PRO-7000R/640 Manual de usuario
Laserworld
Laserworld GREEN-5000C Manual de usuario
Laserworld
Laserworld PRO-500G MH Manual de usuario
Laserworld
Laserworld EL-60 G Manual de usuario
Manuales populares de Equipo de iluminación de otras marcas
Commercial Electric
Commercial Electric 54568141 Manual de usuario
CREE LIGHTING
CREE LIGHTING 304 Series Manual de usuario
Goobay
Goobay 49867 Manual de usuario
ECOMAN ITALIA
ECOMAN ITALIA LED T8 Manual de usuario
Alkalite
Alkalite Krypton KT-81 Manual de usuario
Clas Ohlson
Clas Ohlson GU10 Manual de usuario
