Laser SPK-BT313 Manual de usuario
User Manual
Portable Mini Bluetooth TWS Speaker
SPK-BT313
SPK-ST40-972
Thank you
for your purchase!
Laser Corporation is 100% Australian owned &
operated. To get the most out of your product
please read the user manual carefully and keep
for future use.
For specific information relating to your product
such as Spare Parts, FAQs, Warranty claims, and
more, please scan the following QR code:
WHAT’S IN THE BOX
• SPK-BT313 Speaker
• USB Charging Cable
• User Manual
Bluetooth Version: 5.1
Bluetooth Range: 10 meters
Bluetooth Name: SPK-BT313
USB: Up to 32GB drives
in FAT32 format
Micro SD Card:
Speaker Size:
Speaker Quantity:
Frequency Response:
Signal to Noise Ratio:
Power Output:
Up to 32GB cards
in FAT32 format
Radio: FM only
52mm
4Ω/5W
120Hz – 20kHz
≥90dB
Battery: 3.7V, 500mAh
Battery Runtime: 3 hours at 50% volume
Charging Input:
Charging Time:
Up to 5V/500mA
3 hours
Product Dimensions: 100 x 40 x 78mm
Weight: 209g
1
SPECIFICATIONS
CONTROLS
1. USB Input Up to 32GB drives in FAT32 format.
Only MP3 files are supported.
-
3. DC 5V
Charging Input
Use the included USB charging cable
to charge the speaker.
A 5V/0.5A wall charger is
recommended.
Charging can also be done via a
computer USB port.
During FM Radio mode, insert cable
to increase reception.
-
-
-
-
-
2. Micro SD
Card Input
Up to 32GB cards in FAT32 format.
Only MP3 files are supported.
-
-
1
3
2
4 5 6 7
CONTROLS
4. Power Button Press and hold to turn speaker on/off.
During music playback, tap to
play/pause.
In FM Radio mode, tap to start
auto-channel search. The process will
take approx. 2 minutes to complete.
Tap during auto-channel search
to stop.
If connected to a mobile phone via.
Bluetooth, tap to answer incoming call.
During call, tap to hang up.
If connected to a mobile phone via
Bluetooth, double tap to call last
number dialled.
-
5. Mode Button
6. Down Button
Tap to switch between USB, Micro
SD Card, Bluetooth, and FM modes.
USB and Micro SD card modes will
only appear when a compatible
card/drive is inserted.
-
-
Press and hold to decrease volume.
During music playback, tap to skip
back to previous track.
-
7. Up Button Press and hold to increase volume.
During music playback, tap to skip
to next track.
-
-
-
-
-
-
-
-
-
Continued...
BLUETOOTH PAIRING
• Turn the speaker on and it will go into
Bluetooth pairing mode by default.
Alternatively tap the “Mode Button” to switch
to Bluetooth mode.
• Search for and select “SPK-BT313” under
the Bluetooth settings of device you are
connecting to e.g. smartphone or tablet.
• Once connected you will hear a tone
from the speaker.
TIP:
• If password is requested enter “0000” on
your smartphone/tablet.
• If speaker name is not appearing under
Bluetooth settings of device you are
connecting to then check it has not already
been connected to another device.
TIP:
TWS pairing will not work if either of the
speakers are already connected to a device
via Bluetooth. Please disconnect the
speakers from any Bluetooth connections
before using TWS.
• Turn on two identical speakers into their
Bluetooth pairing modes.
• Press and hold the “Mode Button” for
2 – 3 seconds on one of the speakers. A tone
will be heard when successfully paired.
• Search for and select “SPK-BT313” under
the Bluetooth settings of a device you are
connecting to e.g. smartphone or tablet.
• Once paired to a smart device any music
played will come out of both speakers in
separated stereo channel (dependent on
source material).
TWS PAIRING
TIP:
If Micro SD Card is not recognized, check
you are only using MP3 files for playback, or
if the card has been formatted to the FAT32
file system.
• Insert a Micro SD Card for playback of
MP3 files only.
• Up to 32GB cards formatted to the FAT32
file system are compatible.
• The speaker will automatically switch to
Micro SD Card playback when inserted.
• Remove the Micro SD Card to exit
this mode.
MICRO SD CARD
PLAYBACK
TIP:
If USB drive is not recognized, check you are
only using MP3 files for playback, or if the
drive has been formatted to the FAT32
file system.
• Insert a USB drive for playback of
MP3 files only.
• Up to 32GB drives formatted to the
FAT32 file system are compatible.
• The speaker will automatically switch to
USB playback when inserted.
• Remove the USB drive to exit this mode.
USB PLAYBACK
