Larson Electronics GL-3610-S-E Manual

Golight Stryker Boat Light

Wireless Handheld & Dash Remotes

Stanchion Mount

INSTRUCTION GUIDE

Part# GL-3610-S-E

Congratulations

You are now the owner of one of the ﬁnest remote control searchlights available today. Thank you for

letting Larson Electronics assist you in your lighting application needs. We're proud of our products and

the technology that we've developed to ensure our customers the most durable, versatile and powerful

searchlights in the lighting industry.

Please read these instructions before using your new Remote Control Spotlight from Larson Electronics.

The GL-3610 65 Watt motorized spot and flood light

combo that operates with a wireless hand held

remote control and a wireless dash mount remote

control. This particular model is available in awhite

finish and is mounted on a stanchion post with

red/green navigational running lights. It produces a

wide spot beam with an effective working beam of

700 feet and has a 5 million candlepower rating.

GL-3610 Hard Wired - Permanent Mount:

GL-3610 Searchlight

Wireless Remote Control

Wireless Dash Remote Control

2 A23 12V Batteries

Perko Socket/Mount

MOUNTING INSTRUCTIONS

Determine the location for the light on your vehicle or

boat. The small arrow on the base indicates the

normal forward direction of the light. The light will

rotate to the left of this arrow approximately 185 and

to the right approximately 185. The beam will angle

down about 45 and angles up to 90. The location

should take into consideration this beam movement

to ensure optimum usability.

Once the position and orientation are decided

upon—use the black rubber gasket as a footprint to

mark the mounting of base to vehicle. Drill 1/4 inch

hole though mounting surface in the middle of the

footprint for passage of the power cord. Use silicone

sealant to fill opening around power cord.

IMPORTANT: Allow 3” of cord to remain under the

light to ensure full 370 rotation.

You should choose screw or bolt fasteners

appropriate to the surface to which you intend to

attach the light. If you intend to use the four small

plastic caps provided to cover the screw heads once

installed, a #8 round head is recommended.

The black gasket should be installed on the lamp

base prior to attachment to the vehicle surface.

NOTE: The small drain hole in the edge of the

gasket should normally face opposite the forward

direction of the vehicle—opposite the arrow molded

in the front of the base. Silicone or other like

sealants should not be used around the base gasket

as it will limit the light’s ability to drain excess water

properly.

The 12 Volt DC power wire should be joined to the

leads under the lamp with appropriate automotive

wire attachments. It is critical that polarity be

observed. Connect vehicle positive (+) to spotlight

positive (+) wire. Connect vehicle ground (-) to

spotlight ground (-) wire. Power should be fused at

10 Amps and be on a dedicated circuit, or wired to an

appropriate automotive relay system.

PROGRAMMABLE REMOTE INSTRUCTIONS

The GL-3610 is controlled with a programmable

remote with 2187 different channels. This feature

allows you the freedom to change the channel

selection, and the receiver relearns the new selection.

PROGRAMMING THE TRANSMITTER.

This light has been pre-programmed at the factory, it

is not necessary to re-program the transmitter, but is

recommended.

PROGRAMMABLE REMOTE INSTRUCTIONS

The GL-3610 Light is controlled with a programmable

remote with 2187 different channels. This feature

allows you the freedom to change the channel

selection, and the receiver re- learns the new

selection. This light has been pre-programmed at the

factory, and it is not necessary to re-program the

transmitter, unless you experience outside

interference. To program transmitter:

1.IMPORTANT Disconnect power.

2.Remove battery cover from remote control.

3.Set the 7 dip switches to a selection of your

choice. There are 3 positions on each; positive,

negative and neutral. Use a small screwdriver and

select a position for each dip switch. *Please note

that the orientation of the +/- switch positions may

vary among different models of wireless remote

controls.

4.Insert both A23 12V batteries. Be sure batteries

have adequate charge.

5.Replace battery cover.

a. Depress the on/off button and hold it down.

Red LED will light.

b. While holding the on/off button down,

reinstall the power (replace fuse or connect

vehicle battery).

c. Keep on/off button depressed for 5-6

seconds, and then release. The light should

now be programmed.

WIRELESS DASH CONTROL

If you have a wireless dash control, please note that

it is vital for this to be attached to a flat / smooth

surface with the 4 mounting screws included. The

arrow under the rubber cover should point up.

OPERATION OF GL-3610

1. Using the remote control, turn on the light by

depressing the on/off button.

2. With the 4-way arrows on the remote control,

rotate your light to the desired location.

Depending upon conditions, the wireless remote

may be used up to 80 feet from the spotlight.

3. The speed of the light rotation can be controlled

by de-pressing the tortoise/hare button one time

and by depressing it again to restore the original

speed.

4. The spotlight should not be turned on when the

snap on lens cover (rockguard) is attached. (Not

applicapble for LED)

BATTERY INSTALLATION AND REMOVAL FOR

TRANSMITTER

Remove Battery Cover: remove the Phillips head

screw securing the battery cover then remove the

cover. With the battery compartment now exposed,

insert batteries according to correct polarity.

Remove the batteries by gripping the positive end of

each battery and lifting.

Use only 12v-A23 batteries in the Golight remote

control

USAGE:

» This light is intended for off-road and utility use only

» This light may only be disassembled and repaired

by an authorized representative

MISUSE:

» This light is not approved for road or highway use

» This light is not approved for underwater use

» This light is not approved for inverted mounting

» This light is not approved for use inside a vehicle or

enclosure and power should be disconnected prior to

placing the light in such circumstance

» This light may be damaged if operated in icing

conditions

» This light may only be dismantled by an authorized

Larson Electronics representative.

» Any violation of the above referenced misuses

will be considered grounds for warranty refusal

IMPORTANT SAFETY INFORMATION

This symbol is to alert you to important operating

or servicing instructions that appear in your

instructions.

Always follow basic safety

precautions when using

this product to reduce the

risk of injury, fire or electric shock.

This light is for off road and utility use only. It

is not designed for road use as a driving light.

The GL-3610 complies with Part. 15.105 of the

FCC Rules. This equipment has been tested and

found to comply with the limits for a Class B

digital device. These limits are designed to

provide reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses, and can radiate

radio frequency energy and, if not installed and

used in accordance with the instructions, may

cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning

the equipment off and on, the user is encouraged

to try to correct the interference by one or more

of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment

and receiver.

Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced

radio/TV technician for help.

FCC RULE Part. 15.21 - Changes or

modiﬁcations made by the user not expressly

approved by Larson Electronics, LLC. for

compliance could void the user’s authority to operate

theequipment.

PARTS / ACCESSORIES

Contact manufacturer for GL-3610 parts and

accessories.

PKS-1

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

1of 1

Black 2-Pin Perko Socket Mounting Base

Mounting information

Do not attempt operation until you are familiar with all warnings, precautions, and procedures outlined within this

instruction sheet. Read carefully before operating. Retain these instructions for future reference.

USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE.

WE RECOMMEND A LICENSED ELECTRICIAN INSTALL THIS PRODUCT.

INSTALLATION

1. For proper light selection, positioning and configuration, refer to A.B.Y.C. Standard A-16*, the '72 COLREGS*,

and the U.S. Inland Rules*.

2. These bases are designed to be mounted on a horizontal surface.

3. For Bi-Color lights, draw a 6" long reference line through the center of the selected mounting location and parallel

to the centerline of the boat.

4. Cut out the mounting template. Place it on the mounting surface such that the reference line (drawn above) is

directly underneath the reference line marked on the template.

5. Drill indicated holes through the template to accommodate #8 oval head mounting screws and socket as required.

6. Attach supply connections to the light, making sure to wire in accordance with both A.B.Y.C. Standard E-9* and

the U.S. Coast Guard Safety Standards for Boat Electrical Systems (33 CFR 183)*.

For 2-contact bases, the supply leads are coded as follows:

WHITE: Positive supply lead

BLACK: Negative supply lead (Caution: Negative lead connected to case. To avoid energizing case, observe

polarity.)

Electrical connections must be made such that the forward compartment is switched in conjunction with the

other running light(s); aft compartment should be switched with Ignition (or permanently energized), as a

push switch is provided on top of the light. NOTE: All light circuits must be circuit protected. Use a 1/2 Amp

fuse (or breaker) for the courtesy light circuit and a 2 Amp fuse (or breaker) for the combination light circuit.

7. Setup for Operation: As pole engages with base, make sure alignment screw in pole slides into the notch in the

base. Push pole until it engages the electrical connector and lock by rotating the locking collar clockwise.

*The above referenced standards can be obtained from

American Boat & Yacht Council, Inc.

U.S. Coast Guard

613 Third Street, Suite 10

Washington D.C. 20593

Annapolis, MD 21403 (or your local C.G. Office)

<< PRINT ACTUAL SIZE (100% SCALE) FOR CORRECT DIMENSIONS.

Otros manuales de Destacar de Larson Electronics

Larson Electronics

Larson Electronics HID-X970-SA Manual de usuario

Larson Electronics

Larson Electronics GL-8130-M Manual de usuario

Larson Electronics

Larson Electronics GL5150-12IR Manual

Larson Electronics

Larson Electronics Golight 51674 Manual

Larson Electronics

Larson Electronics HML-5M-RC Manual de usuario

Larson Electronics

Larson Electronics GL-4600-XD Manual

Larson Electronics

Larson Electronics LE-217 Manual de usuario

Larson Electronics

Larson Electronics GL-30514-S-E Manual

Larson Electronics

Larson Electronics Golight GL-2 GT Series Manual

Larson Electronics

Larson Electronics RL-20 Manual de usuario

Larson Electronics

Larson Electronics Golight Stryker GL-30064ST Manual de usuario

Larson Electronics

Larson Electronics HUL-18 Manual de usuario

Larson Electronics

Larson Electronics GL-30675-F Manual de usuario

Larson Electronics

Larson Electronics EXPRA-06R-LED Manual de usuario

Larson Electronics

Larson Electronics HUL-LED25WRE-12.3-50GCR-24I Manual de usuario

Larson Electronics

Larson Electronics HAL-RA-48-6L-LED Manual de usuario

Larson Electronics

Larson Electronics GL-2000-S-E Manual

Larson Electronics

Larson Electronics Golight GL-3000-24-M Manual de usuario

Larson Electronics

Larson Electronics Golight RadioRay GL-7 GT Series Manual de usuario

Larson Electronics

Larson Electronics HL-85-LED-CPR Manual de usuario

Larson Electronics

Larson Electronics Golight Radioray GL-2081-M Manual

Larson Electronics

Larson Electronics GL-9100H-S Manual

Larson Electronics

Larson Electronics HL-85-HID-CPR Manual de usuario

Larson Electronics

Larson Electronics APM-GL20004 Manual de usuario

Manuales populares de Destacar de otras marcas

Guangzhou Yinhe Lighting&Sound Equipment Factory

Guangzhou Yinhe Lighting&Sound Equipment Factory NE-204 Manual de usuario

LIVARNO home

LIVARNO home 375304 2101 Instrucciones originales

Cameo

Cameo CLQS40WW Manual de usuario

Leviton

Leviton Ellipsoid 5/50 Manual de usuario

Monacor

Monacor img Stage Line PARL-56PDX/CR Manual de usuario

Vector

Vector SL3AKV Manual de usuario

Quantum

Quantum Q262 Manual operacional

Philips

Philips Vari-lite VL3015LT Manual de usuario

EUROSPOT

EUROSPOT C51 Manual de usuario

DTS

DTS MINI BRICK ARC Manual de usuario

Federal Signal Corporation

Federal Signal Corporation VISIBEAM II Manual

ACME

ACME LED-MS350B Manual de usuario

EuroLite

EuroLite Akku flat light 1 Manual de usuario

Commercial Electric

Commercial Electric SPTM-1401 Manual de usuario

Vision & Control

Vision & Control SLB-500-W5K7-P-SL Manual de usuario

Teknik

Teknik FLEXI Manual de usuario

Craftsman

Craftsman CMXLSB10 Manual de usuario

EuroLite

EuroLite LED SLS-144 UV Floor Spot Manual de usuario
