Larson Electronics HL-85-HID-CPR Manual de usuario

HL-85-HID-CPR

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

1of 3

30 Million Candlepower Handheld Spotlight

7" Lens - 55 Watt HID - 5000 Lumens - Spot / Flood Combo

ASSEMBLY

Instruction Manual

Thank you for your purchase of the Larson Electronics HL-85-HID-CPR.

)

WARNING:

READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

CRITICAL SAFETY INSTRUCTIONS:

•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY

RELEVANT LOCAL BUILDING CODES.

•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL

SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.

•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP

OBJECTS. SUITABLE FOR DAMP LOCATIONS.

IMPORTANT

READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. THE HL-85-HID-CPR MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE

AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.

WE STRONGLY ENCOURAGE ONLY ALICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS

PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,

CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.

WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE

INSTALLATION OR PERFORMING ANY MAINTENANCE.

RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.

RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.

RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.

Never place spotlight face down when light is on. Doing so could burn/ignite surfaces such as seats, carpeting, etc. and

cause major property damage. Always turn spotlight off when not in use.

Avoid direct eye exposure the light source when light is on. DO NOT shine light into the face of someone else.

DO NOT touch lens of light when on or recently on. The lens/cooling fins will be hot after long periods.

DO NOT allow children to handle or operate this light.

DO NOT use this product for other than its intended use.

DO NOT operate in close proximity of combustible or flammable materials.

DO NOT attempt to operate this light if cord, plug, battery, lens or any part of the light is damaged or corroded.

WARNING:

USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE. THIS LINE

CORD IS INTENDED TO ALLOW OPERATORS TO EXTEND POWER TO EQUIPMENT WHEN STATIONARY OUTLETS ARE NOT

READILY AVAILABLE.

IMPROPER USE OF THIS CORD, PLUG, AND RECEPTACLE CAN LEAD TO SERIOUS INJURIES OR DEATH TO

PERSONNEL.

PERIODIC INSPECTION OF THE CORD IS NECESSARY.

THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND,

THE CORD MUST BE REPLACED BEFORE RESUMING USE.

When your number one priority is simply getting as much light as possible to an area, HID lights can`t be beat. The HL-85-HID-CPR

super bright handheld spotlight boasts an intense 5,000 lumen output and a tightly focused beam that reaches over 5,000 feet.

Rustproof, shockproof, and IP65 rated waterproof, the HL-85-HID-CPR is ideal hunting, hiking, camping, security and military

applications as well as for boating and marine use. Larson Electronics offers this light in a 7" reflector size. This light operates on 12 or

24 volts DC and includes a 16 foot coil cord with cigarette plug for connection to vehicles, boats ATV`s and similar vehicles.

HL-85-HID-CPR

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

2of 3

ASSEMBLY

WIRING

Standard pigtail(flying leads) wiring

We strongly encourage a licensed electrician install this product,in all locations especially in outdoor areas

where weatherproofing may be required. Universal voltage driver permits operation at 12/24V DC.

Warning: Check product label for correct input voltage!

Attach supply line wires to the appropriate light fixture wires as shown

in thediagram 

Secure each pair of wires according to the diagram. Utilize a junction box or

similar device and take precautionary steps for weatherproofing all

connections if installed in a location where water may come in contact with the

unit. Ensure the unit is properly grounded and that wiring is done according to

all local and national electrical/building codes.

Standard Cord Cap

This unit comes pre-wired from factory with the selected cord cap. Take

precautionary steps for weatherproofing all connections if installed in a

location where water may come in contact with the unit. All outdoor

installations and indoor installations near a wet location require the use of a

GFCI device for safety, according to the National Electrical Code® (NEC).

Ensure the unit is properly grounded.

Low Voltage DC

Connect power to power supply outputting low voltage between 9-42 Volts DC.

This variable voltage allows greater versatility without affecting light output. Ensure

deutsch connectors are properly connected (If applicable)

DETACHABLE CORDS

•Cord is attached via a weatherproof 2-pin Deutsch connector.

•The cord is detachable by depressing the tab on the top of the connectors. This enables the

operator to remove and store the light while leaving the cord connected to the power source.

•Additional or replacement cords can be ordered from our website. Contact us or visit LarsonElectronics.com for more

information.

POWER

1. The spotlight can be plugged into a cigarette plug socket, attached directly to

low voltage DC batteries, etc.

2. Each unit is designed to work on 12-24 volts DC. This variable voltage allows

the light to be connected to consumer vehicles and other non-standard power

supplies such as military vehicles and heavy equipment.

PLEASE NOTE: There is no difference in light output between voltages.

3. Power transformers (DCP-11-DP) can be purchased through our website to run

this spotlight from household wall outlets.

-LENS

REFLECTOR

-ON/OFF

SWITCH

-HANDLE

3/8” FASTENER

QUICK DISCONNECT

DEUTSCHE CONNECTOR

CIGARETTE PLUG

IN CONNECTOR

16FT COIL CORD

MOUNTING

1. These units are handheld via the pistol grip handle, but can be mounted via

the 3/8-16" brass nut fastener embedded into the base of the handle.

2. We offer a 100LB magnetic base (MM-2) for magnetic mounting, and a

permanent mounting plate with swiveling and tilting bracket (PMB-4X4) for

permanent mounting.

HL-85-HID-CPR

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

3of 3

ASSEMBLY

MAINTENANCE

Caution: To avoidpersonal injury, disconnect power to the light and allow the unit to cool downbeforeperforming maintenance.

Warning:No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will voidthe warranty.

1. Perform visual,mechanical and electrical inspections on a regular basis.We recommend routine checks to be made on a

yearly basis. Frequency of use and environment shoulddetermine this. It is recommendedto follow an Electrical Preventive

Maintenance Program as described in NFPA 70B: Recommendedpractice for Electrical Equipment.

2. The lens should be cleaned periodically as neededto ensure continued photometric performance. Clean the lens with a

damp, non-abrasive,lint-free cloth. If not sufficient, use mild soapor a liquid cleaner.

3. Inspect the cooling fins on the luminaire to ensure that they are free of any obstructions or contamination (i.e.excessive

dust build-up). Clean with a non-abrasive clothif needed.

4. Do not operate if the lens is cracked or damaged. All fasteners shouldbe properly seated.

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The HL-85-HID-CPR is designed to provide years of reliable performance. Should the need for replacement parts arise,

please contact Larson Electronics.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
