Lamona LAM3303 Guía

Built in Single Fan-Assisted Oven LAM3303

Instructions & Installation

www.howdens.com/appliance-registration

See back page for product serial number

Exclusive to Howdens Joinery.co Page _ 3

User manual LAM3303

Dear Customer,

Congratulations on your choice of oven.

The user manual will help you use your product quickly and safely.

•Please read this user manual before installing and using the oven.

•Always follow the safety instructions.

•Keep this user manual within easy reach for future reference.

•Please read any other documents supplied with the product.

Explanation of symbols

Throughout this user manual the following symbols are used:

Important information or useful tips about usage.

Warning for possible hazards to health and property.

Warning possibility of electric shock.

Product information correct at the time of publication in January 2017.

The company has a policy of continuous product development and reserves the right to change any

products and specifications given in this manual.

The appliance is marked according to the European Directive 2012/19/EU on waste

Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of

correctly you will help prevent potential negative consequences for the environment and

human health. The symbol on this product indicates that this product may not be treated

as household waste. Instead it should be handed over to the applicable collection point

for recycling of electronic equipment. Disposal must be carried out in accordance with

local environmental regulations for waste disposal. For more detailed information please

contact your local council household waste site.

www.howdens.com

Page _ 4

LAMONA Appliances

Index

Before using the oven & Safety 05

General Safety 05

Safety for children 05

Safety when working with electricity 08

Safety and cleaning 08

Shelf positions 09

General information 10

Oven layout 10

Control panel layout 10

Accessories 10

Operation modes 11

Operating modes 11

Preparation 12

First cleaning of the appliance 12

Initial heating 12

Tips for energy saving 12

How to operate the main oven 13

How to use the main oven 13

Select a temperature and operating mode 13

Shelf positions 13

Switch off the oven 13

Cooking and baking advice 14

Cooking table 15

Oven cooking table 15

Grill cooking table 16

Care and maintenance 17

General information 17

Cleaning the control panel 17

Cleaning the door 17

Removal of the oven door 17

Removing the inner door glass 18

Replacing the oven Lamp 19

Installation 20

Before installation 20

Electrical Connections 21

Cooling Fan 22

Technical specification 23

Troubleshooting 24

Your Guarantee 25

Exclusive to Howdens Joinery.co Page _ 5

User manual LAM3303

•Make sure that you have removed all packaging, wrappings, stickers and films from the oven’s

surface.

•It is recommended that you clean and wash the oven’s surface before using for the first time.

01 - Before using the Oven

02 - Safety

•This appliance is for

domestic cooking purposes

only. It must not be used for

other purposes, e.g room

heating, or drying towels and

dish cloths over the handle.

Commercial use will void the

guarantee (see guarantee

page).

•The manufacturer shall not

be liable for any damage

caused by improper use or

ha ndling errors.

General

•This product is not intended

to be used by persons

with physical, sensory

or mental disorders or

unlearned or inexperienced

people (including children)

unless they are supervised

by a person who will be

responsible for their safety

or who will instruct them

accordingly in the use of the

product.

Safety for children

•Children must be supervised

to prevent them from playing

with the product.

•Electrical products can

be dangerous to children.

Keep children away from

the product when it is

operating and do not allow

them to play with or near the

product.

•CAUTION: Accessible

parts of the oven may

become hot when the oven

or grill is in use. Children

should be kept away until

the product has cooled

down.”

•Do not store any items

above the appliance that

children may reach for.

•When the door is open, do

not load any heavy object on

it and do not allow children

to sit on it. The door or door

hinges may be damaged.

•The packaging materials will

be dangerous for children.

Keep the packaging

materials away from

children. Please dispose of

all parts of the packaging

according to environmental

www.howdens.com

Page _ 6

LAMONA Appliances

•Accessible parts may

become hot during use.

To avoid burns, children

less than 8 years of age

should be kept away unless

continuously supervised.

•This appliance can be used

by children aged 8 years

and above, persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge,

if they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved.

•Cleaning and user

maintenance must not be

made by children without

supervision.

•Connect the product to an

earthed outlet protected by

a fuse of suitable capacity

as stated in the “Technical

specifi cations” table. Our

company shall not be liable

for any problems arising

due to the product not being

earthed in accordance with

the local regulations.

•Do not operate the product if

the power cable is damaged.

Replace with a suitable

cable by a qualified person.

•Do not operate the product

if it is defective or has any

visible damage.

•Do not carry out any repairs

or modfications to the

product.

•Never wash down the

product with excessive

water, as there is the risk of

electric shock!

•Never use the product

when your judgment or

coordination is impaired by

the use of alcohol and/or

drugs.

•Product must be

disconnected from the

mains during installation,

maintenance, cleaning and

repair procedures.

•Repair procedures must

always be performed by

qualified persons. The

manufacturer shall not

be held responsible for

damages arising from

procedures carried out

by unauthorised persons,

which may also void the

guarantee.

•Be careful when using

alcoholic drinks in your

dishes. Alcohol evaporates

at high temperatures and

may ignite when it comes

into contact with hot

surfaces.

•Do not heat closed tins and

glass jars in the oven. The

pressure that would build-up

in the tin/jar may cause it to

burst.

Exclusive to Howdens Joinery.co Page _ 7

User manual LAM3303

•Do not place any materials

close to the product as

the sides may become hot

during use.

•WARNING FIRE RISK

- Do not place aluminium

foil, baking trays or cook on

the base of this oven, doing

so will cause permanent

damage to your appliance

and cabinetry with the

potential risk of fire.

•Parts of the oven may

become hot during or

immediately after use.

Care should be taken to

avoid touching the heating

elements, and components

inside the oven which maybe

hot. Always allow oven to

cool.

•If the door seal is very

dirty this can prevent the

door from closing properly

during use, resulting in

possible damage to adjacent

furniture and poor efficiency.

Always ensure the door seal

is clean.

•Product may become hot

when it is in use. Please be

careful not to touch these

hot surfaces.

•Always use heat resistant

oven gloves when putting

dishes in or removing dishes

from the hot oven.

•Do not use the product if

any door glass is removed or

damaged.

•Always use heat resistant

oven gloves when putting

dishes in or removing dishes

from the hot oven.

•Rear surface of the oven

may get hot when it is in

use. Make sure that the

electrical connections do

not contact the rear surface;

otherwise, connections may

be damaged.

•Do not trap the mains cable

and do not route it over

hot surfaces. The cable

insulation may melt and

cause a short circuit.

•Product must be installed

by a qualified person

in accordance with the

regulations in force.

Otherwise, the guarantee

may become void.

•When hot and cold air

meet, condensation can

form. The outer door is air

cooled and the inner glass

will become hot during

cooking, therefore some

condensation might form.

This is perfectly normal. All

condensation will disappear

as the oven reaches cooking

temperature.

•Make sure that the product

control knobs are switched

off after every use.

www.howdens.com

Page _ 8

LAMONA Appliances

Safety when working with

electricity

•Any work on electrical

equipment and systems

should only be carried out

by authorised or qualified

persons.

•In case of any damage,

switch off the product and

disconnect it from the

mains. To do this, turn off at

the fuse box.

•The appliance must be

installed so that it can be

completely disconnected

from the mains easily after

installation by the isolation

switch.

•Do not bend or trap cable

against hot surfaces during

install.

•Make sure that fuse rating is

compatible with the product.

•Do not switch the oven off

at the mains isolation switch

immediately after cooking.

Cooling fan continues to

run for up to 20-30 minutes

(approx) even after the oven

control is turned off.

•Keep all ventilation slots

clear of obstructions, as this

may cause premature failure

of the oven element.

•Do not allow the oven to cool

with the door open. Even if

the appliances door is only

open a little, front panels

become damaged over time.

of adjacent units could

become damaged over time.

Safety and cleaning

•Do not use harsh

abrasive cleaners or sharp

metal scrapers to clean the

oven door since they can

scratch the surface, which

may result in the shattering

of the glass.

•WARNING: Ensure that

the appliance is switched off

before replacing the lamp

to avoid the possibility of an

electric shock.

•Do not use oven light

for household room

illumination.

•Do not use steam

cleaners for cleaning.

•The appliance must not

be installed behind a

decorative door.

Exclusive to Howdens Joinery.co Page _ 9

User manual LAM3303

Shelf Positions

•The oven has 5 shelf

positions. It is important

to position the wire shelf

into the runners correctly

before placing items on the

shelf. Do not insert shelves

forcefully.

www.howdens.com

Page _ 10

LAMONA Appliances

a. Control panel

b. Handle

c. Oven Door

General Information

d. Heating element

e. Light

f. Oven shelf positions

a Oven/ grill function knob

b 0ven / grill temperature indicator

c Oven/grill temperature control knob

Oven tray / grill pan Grill pan wire rack / trivet Oven shelf (x2 included)

Oven layout

Control panel layout

Accessories

100

150200

250

Max

°C

Tabla de contenidos

Otros manuales de Horno de Lamona

Lamona

Lamona HJA 3240 Instrucciones de montaje

Lamona

Lamona LAM3676 Guía

Lamona

Lamona LAM3708 Guía

Lamona

Lamona LAM3301 Guía de solución de problemas

Lamona

Lamona LAM4602 Manual de usuario

Lamona

Lamona LAM3214 Guía

Lamona

Lamona LAM4401 Guía de solución de problemas

Lamona

Lamona LAM3100 Guía de solución de problemas

Lamona

Lamona LAM3204 Guía de solución de problemas

Lamona

Lamona LAM3700 Manual de usuario

Lamona

Lamona LAM4601 Manual

Lamona

Lamona LAM4403-1 Manual de usuario

Lamona

Lamona LAM3201 Guía de solución de problemas

Lamona

Lamona LAM3601 Guía

Lamona

Lamona LAM3405 Manual de usuario

Lamona

Lamona LAM4403 Manual de usuario

Lamona

Lamona LAM3208 Manual de usuario

Lamona

Lamona LAM3600 Guía de solución de problemas

Lamona

Lamona LAM4405 Guía

Lamona

Lamona LAM4406 Manual de usuario

Lamona

Lamona LAM3710 Guía

Lamona

Lamona LAM3410 Guía

Lamona

Lamona LAM3301 Guía de solución de problemas

Lamona

Lamona LAM3501 Guía de solución de problemas

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
