Laird Sentrius RG1 Series Manual de usuario

Version 3.0

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

Version

Date

Notes

Contributor(s)

Approver

1.0

20 July 2017

Initial Release

Jonathan Kaye

1.1

28 July 2017

Minor fixes

Dave Drogowski

1.2

3 Aug 2017

Clarified web interface URL in section 3: Log

into the Gateway. Identified separate mDNS

address.

Shewan Yitayew

2.0

29 Nov 2017

Update info for compatibility with GA2

(93.7.2.x) firmware.

Ryan Erickson

2.1

19 April 2018

Minor typo correction

Shewan Yitayew

2.2

15 May 2019

Update RM1xx DVK Configuration and RG1xx

Packet Forwarder setup for current firmware

Seokwoo Yoon

2.3

21 Oct. 2019

Updated for AS923 Region Support

Robert Gosewehr

Jonathan Kaye

2.4

16 Jan 2020

Revised to address the module firmware and

sample application updates

Rikki Horrigan

Jonathan Kaye

3.0

04 Feb 2020

Updated for GA5

Adam Ruehl

Chris Boorman

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

1Overview .............................................................................................................................................................................4

1.1 Product Overview.......................................................................................................................................................4

2Connect the Hardware.........................................................................................................................................................5

2.1 Connect the Gateway.................................................................................................................................................5

2.1.1 Antenna Configuration..........................................................................................................................................5

2.1.2 Wi-Fi Quick Config................................................................................................................................................6

3Log into the Gateway...........................................................................................................................................................6

4Connecting the Gateway to the Internet..............................................................................................................................8

4.1 Setting Up Ethernet....................................................................................................................................................8

4.2 Setting Up Wi-Fi.........................................................................................................................................................8

5LoRa Packet Forwarding Set Up.........................................................................................................................................9

6Configuration with The Things Network.............................................................................................................................11

6.1 Set up your account with The Things Network.........................................................................................................11

6.2 Create an Application with TTN................................................................................................................................14

6.3 Register Your End-device with TTN.........................................................................................................................15

7Appendix ...........................................................................................................................................................................17

7.1 Sending Data to the Cloud –Setup..........................................................................................................................17

8View DVK-RM1xx Data in the Cloud .................................................................................................................................23

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

This quick start guide describes how to configure the SentriusTM gateway to forward LoRaWAN data to a cloud platform. The

steps listed in this guide use the RG191 (US version) gateway and an RM191 (US version) module. The steps for using an

RG186 and RM186 are similar.

Note: This guide uses The Things Network (TTN) to show how to register your Gateway and visualize the incoming

data on a Network server. If you are working with other network server vendors, please consult their user

guide for help with configuring the network server.

For more detailed information on how to use all the features of the Sentrius gateway, please see the SentriusTM RG1xx User

Manual, available from documentation tab at: https://www.lairdconnect.com/wireless-modules/lorawan-solutions/sentrius-

rg1xx-lora-enabled-gateway-wi-fi-ethernetAbout the Gateway

The Sentrius™ RG1xx LoRa-Enabled Gateway from Laird is the ultimate in secure, scalable, robust

LoRa solutions for end-to-end control of your private LoRaWAN network. Leveraging Laird’s

field-proven and reliable 50 Series “Wireless Bridge” certified module, it also offers

enterprise dual-band Wi-Fi, BT v4.0 (BLE and Classic) and wired Ethernet for complete design

freedom. Based on the Semtech SX1301/SX1257 chipset designs, it offers a LoRa range up to 10

miles and pre-loaded LoRa Packet Forwarder software, perfect for highly scalable, flexible IoT

networks. The SentriusTM RG1xx Gateway works with Laird’s SentriusTM RM1xx

Series LoRa+BLE certified modules for simple out-of-the-box integration and is compatible with

3rd party Cloud and LoRa partners, as well as any LoRaWAN certified client devices.

Figure 1: Top of the Sentrius™ RG1xx gateway

1. LoRa and Wi-Fi antennas

2. LEDs

3. Mounting holes

4. User button

Figure 2: Back panel of the Sentrius™ RG1xx gateway

1. DC power input

2. User button

3. Reset button

4. SD card slot

5. Ethernet connector

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

To use the gateway, you must power up the gateway and access the web interface via the Ethernet port. To do this, complete

the following steps:

1. Follow the label on the box and connect the three antennas. Refer to Antenna Configuration for additional information.

2. Connect the power supply (see #2 in Figure 3).

3. Connect the gateway to your router (#3 in Figure 3) using the Ethernet cable (#1 in Figure 3).

Figure 3: Connecting the gateway

To configure the antenna properly, complete the following steps:

1. Attach the two shorter antennas to the 2.4/5.5 GHz (Wi-Fi) ports.

2. Attach the third and longer antenna to the 868 MHz/900 MHz (LoRa) port.

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

The gateway includes a mode to allow you to configure without ethernet access, in the case that you wish to join a wireless

network.

Apply power to the gateway and allow to start, then perform the following:

1. Depress and hold the user button (see #2 in Figure 2) for 7 seconds.

2. From a wirelessly enabled device perform a scan.

3. Connect to the access point rg1xx29378B, where “29378B” are the last six digits of the Ethernet MAC address found on

the label on the bottom of the gateway (Figure 4).

The network is secured with WPA2 with a password that is the same as the SSID. It is recommended that the default

password is changed for security reasons. The password can be changed on the Wi-Fi -> Advanced web page.

Upon logout or client disassociation, Wi-Fi Quick Config will shut down and normal operation will resume.

To log into the gateway web interface, follow these steps:

1. Determine the last three bytes of your gateway’s Ethernet MAC address. This can be found on the label on the bottom

of the gateway; the last three bytes are highlighted (Figure 4).

Figure 4: Bottom label (Standard GW –Left, AS923 & AU915 Region Supported/Latest Version –Right)–last three bytes of the Ethernet MAC

address highlighted

2. Enter the URL into the web browser to access the web interface. For example, for the gateway used in this guide, the

URL is https://rg1xx29378B.local., where “29378B” are the last 6 digits of the Ethernet MAC address. In Wi-Fi quick

config mode, the gateway can also be accessed via the IP address at https://192.168.1.1

3. Accept the self-signed security certificate in the browser.

4. Click Advanced (Figure 5).

Figure 5: Web interface –first screen

5. Click Proceed (Figure 6).

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

Figure 6: Web interface –second screen

6. Log on using the following default credentials (Figure 7):

Username: sentrius

Password: RG1xx

Figure 7: Gateway interface login screen

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

By default, the Ethernet port is set up for DHCP addressing. Connect the Ethernet cable to a network with internet access. If

more advanced Ethernet configuration is needed, please see the SentriusTM RG1xx User Manual in the documentation tab of

the RG1xx product page at https://www.lairdconnect.com/wireless-modules/lorawan-solutions/sentrius-rg1xx-lora-enabled-

gateway-wi-fi-ethernet

By default, the Wi-Fi in the gateway is not configured to connect to a Wi-Fi network. You must access the web interface on the

gateway via the Ethernet interface to setup the Wi-Fi connection.

To set up the Wi-Fi, follow these steps:

1. Once logged into the web interface, navigate to the Wi-Fi page (Figure 8).

Figure 8: Wi-Fi page

2. To connect to a Wi-Fi network, click Scan to scan for nearby Wi-Fi networks (Figure 9). Scanning continues until you

click Stop or select one of the scan results in the list.

Figure 9: Wi-Fi scan results

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

3. Click on the applicable scan result.

4. Enter the information for the Wi-Fi network (Figure 10).

Figure 10: Wi-Fi profile dialog

5. Click Connect.

To set up LoRa packet forwarding on the gateway, follow these steps:

1. Click the LoRa tab in the main menu (Figure 11).

2. In the dropdown labeled Select Preset, select the preset for The Things Network Legacy (TTN).

3. Click Apply.

Figure 11: LoRa page –TTN preset

Note: In addition to the TTN, Laird currently supports presets for other LoRa network servers.

https://www.lairdconnect.com/wireless-

modules/ramp-ism-modules

Americas: +1-800-492-2320

Europe: +44-1628-858-940

Hong Kong: +852 2923 0610

Figure 12: LoRa presets

Note: If operating with a network server that is not available as a preset, you may also manually configure the

forwarder in the Forwarder page, available in the left menu. More information on this is available in the

RG1xx User Guide, available in the documentation tab of the RG1xx product page at

lhttps://www.lairdconnect.com/wireless-modules/lorawan-solutions/sentrius-rg1xx-lora-enabled-gateway-wi-fi-

ethernet

The network server must be compatible with the packet forwarder being used on the gateway. The packet forwarder can be

custom configured on the forwarder, radios, and advanced pages.

If the LoRa network operated on a different channel plan it is also necessary to program this into the gateway on the radios

page.
