LaCie 2big DOCK Manual de usuario

design by neil poulton

Quick Install Guide

2big DOCK

Professional Desktop RAID Storage | Advanced Docking Solution

Ports

CFexpress B

DisplayPort 1.4

Thunderbolt™3

(host)

Thunderbolt 3

(peripheral/daisy chain)

Sleep/Wake

Power input

UHS-II SDXCUSB 3.2 Gen 2 hub CFast 2.0

1Connect power cable

2Connect Thunderbolt cable

The included Thunderbolt cable can be used to connect

2big Dock to USB-C host ports that support Thunderbolt

or USB.

IMPORTANT: Your computer must be connected to the host port to power on

and access 2big Dock.

Mac®/ PC

3Install Toolkit

Launch Start Here from your drive to register LaCie 2big Dock and download the Toolkit

software installer.

Start Here Mac

LaCie

File

Start Here Win

Mac

®Windows®

LaCie 2big Dock is configured RAID 0 for full storage capacity and formatted exFAT for

compatibility with macOS and Windows. Install Toolkit to help you configure the drives for

performance or protection. You can also use Toolkit to easily sync between your computer

and 2big Dock, archive previous versions of files, and much more.

Mac: For Time Machine, 2big Dock must be reformatted for Mac. Reformatting will delete all

data previously stored on the drive.

Review details of your 2big Dock’s warranty by opening the LaCie Limited Warranty Statement on

your drive or go to www.lacie.com/warranty. To request warranty service, contact an authorized

LaCie service center or refer to www.lacie.com/support/2big-dock for more information regarding

customer support within your jurisdiction.

CLASS B

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential

installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.

For Australian Customers Only.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled

to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality

and the failure does not amount to a major failure. Revision - July 1, 2020

Ports

Hub USB 3.2 Gen 2 Thunderbolt 3 (hôte)

CFast 2.0 Thunderbolt 3 (périphérique/en série)

UHS-II SDXC DisplayPort 1.4

CFexpress B Veille/Sortie de veille

Entrée d’alimentation

1Branchement du câble d’alimentation

2Branchement du câble Thunderbolt 3

IMPORTANT : Pour mettre votre disque 2big Dock sous tension et y accéder,

votre ordinateur doit être connecté au port hôte.

Le câble Thunderbolt inclus permet de raccorder le 2big Dock à des ports USB-C hôtes

prenant en charge Thunderbolt ou USB.

3Installation de Toolkit

Lancez Start Here sur votre disque pour enregistrer LaCie 2big Dock et téléchargez le

programme d’installation du logiciel Toolkit.

Start Here Mac

LaCie

File

Start Here Win

Mac

®Windows®

LaCie 2big Dock est configuré en RAID 0 pour optimiser ses capacités de stockage et

formaté en exFAT pour assurer sa compatibilité avec macOS et Windows. Installez Toolkit

pour faciliter la configuration des disques de manière à optimiser leurs performances et

garantir leur protection. Vous pouvez également utiliser Toolkit pour synchroniser votre

ordinateur et le disque 2big Dock, archiver les versions antérieures des fichiers, etc.

Mac : Dans le cas de Time Machine, le 2big Dock doit être reformaté pour Mac. Lors du

reformatage, toutes les données stockées au préalable sur le disque seront effacées.

Pour connaître les conditions de garantie de votre 2big Dock, ouvrez la déclaration de garantie

limitée LaCie sur votre disque ou consultez la page www.lacie.com/warranty. Pour toute demande

d’intervention sous garantie, contactez un centre de réparation agréé LaCie clientèle ou consultez le site

www.lacie.com/support/2big-dock pour obtenir de plus amples informations sur le support clientèle

dont vous dépendez.

Porte

Hub USB 3.2 Gen 2 Thunderbolt 3 (host)

CFast 2.0 Thunderbolt 3 (periferica/concatenazione)

UHS-II SDXC DisplayPort 1.4

CFexpress B Pulsante di sospensione/riattivazione

Ingresso alimentazione

1Collegare il cavo di alimentazione

2Collegare il cavo Thunderbolt 3

IMPORTANTE: Il computer deve essere collegato alla porta host per accendersi e

accedere a 2big Dock.

Il cavo Thunderbolt incluso può essere utilizzato per collegare il sistema 2big Dock a porte

host USB-C che supportano Thunderbolt o USB.

3Installazione del Toolkit

Cliccare Start Here dall’unità per registrare LaCie 2big Dock e scaricare il programma di

installazione del Toolkit.

Start Here Mac

LaCie

File

Start Here Win

Mac

®Windows®

LaCie 2big Dock è configurata con RAID 0 per garantire una capacità di archiviazione

completa e formattata exFAT per essere compatibile con macOS e Windows. Installare il

Toolkit per configurare le funzioni di prestazioni e di protezione delle unità. È possibile

usare il Toolkit anche per sincronizzare facilmente il computer e 2big Dock, per archiviare

le versioni precedenti dei file e non solo.

Mac: Per poter utilizzare Time Machine, è necessario riformattare l’unità 2big Dock per

Mac. La riformattazione comporterà la cancellazione di tutti i dati precedentemente salvati

sull’unità.

Controllare i dettagli della garanzia del vostro 2big Dock aprendo la Garanzia Limitata di LaCie

Informativa presente sulla vostra unità o su www.lacie.com/warranty. Per richiedere un servizio

coperto da garanzia contattare un centro di assistenza autorizzato LaCie o fare riferimento a

www.lacie.com/support/2big-dock per maggiori informazioni in merito all’assistenza clienti

presente nel vostro territorio.
