Labconco Logic+ A2 Manual de usuario

Logic+®and Cell Logic+®A2 | B2 Biosafety Cabinets

Axiom®C1 Biosafety Cabinets

PuriCare®Procedure Stations

LABCONCO CORPORATION

8811 Prospect Avenue

Kansas City, MO 64132

(800) 821-5525 I +1 (816) 333-8811

labconco.com

Please read user’s manual before

operating equipment

Original Instructions

Technical Manual

Logic+® Type A2 Biosafety Cabinets

30231xxx1 30241xxx1 30251xxx1 30261xxx1

30238xxx1 30248xxx1 30258xxx1 30268xxx1

30242xxx1 30252xxx1 30262xxx1

PuriCare®Procedure Stations

31241xxx1 31261xxx1 31242xxx1 31252xxx1 31262xxx1

Logic+® Type B2 Biosafety Cabinets

30348xxx1 30368xxx1

Cell Logic+® Type A2 Biosafety Cabinets

32239xxx1 33239xxx1 34239xxx1

32249xxx1 33249xxx1 34249xxx1

32259xxx1 33259xxx1 34259xxx1

32269xxx1 33269xxx1 34269xxx1

Cell Logic+® Type B2 Biosafety Cabinets

32348xxx1 33348xxx1 34348xxx1

32368xxx1 33368xxx1 34368xxx1

Axiom®Type C1 Biosafety Cabinets

30441xxx1 30448xxx1 30461xxx1 30468xxx1

Labconco Corporation. Labconco Corporation reserves the right to make periodic design changes without obligation to notify any person or entity of such change.

Warranty

Labconco Corporation provides a warranty to the original buyer for the repair or replacement of parts and reasonable labor as a result of normal and proper use of

the equipment with compatible chemicals. Broken glassware and maintenance items, such as filters, gaskets, light bulbs, finishes and lubrication are not

warranted. Excluded from warranty are products with improper installation, erratic electrical or utility supply, unauthorized repair, use with incompatible chemicals,

or non-factory modifications to the original product.

Purifier® Logic®+ and AxiomTM Biological Safety Cabinets and PuriCare® Procedure Stations carry a five-year warranty from date of installation or six years from

date of shipment from Labconco, whichever is sooner. Warranty is non-transferable and only applies to the owner (organization) of record.

Buyer is exclusively responsible for the set-up, installation, verification, decontamination or calibration of equipment. This limited warranty covers parts and labor,

but not transportation and insurance charges. If the failure is determined to be covered under this warranty, the dealer or Labconco Corporation will authorize

repair or replacement of all defective parts to restore the unit to operation. Repairs may be completed by 3rd party service agents approved by Labconco

Corporation. Labconco Corporation reserves the rights to limit this warranty based on a service agent’s travel, working hours, the site’s entry restrictions and

unobstructed access to serviceable components of the product.

Under no circumstances shall Labconco Corporation be liable for indirect, consequential, or special damages of any kind. This warranty is exclusive and in lieu of

all other warranties whether oral, or implied.

Returned or Damaged Goods

Do not return goods without the prior authorization from Labconco. Unauthorized returns will not be accepted. If your shipment was damaged in transit, you must

file a claim directly with the freight carrier. Labconco Corporation and its dealers are not responsible for shipping damages.

The United States Interstate Commerce Commission rules require that claims be filed with the delivery carrier within fifteen (15) days of delivery.

Limitation of Liability

The disposal and/or emission of substances used in connection with this equipment may be governed by various federal, state, or local regulations. All users of

this equipment are required to become familiar with any regulations that apply in the user’s area concerning the dumping of waste materials in or upon water, land,

or air and to comply with such regulations. Labconco Corporation is held harmless with respect to user’s compliance with such regulations.

For additional questions or support:

Labconco Customer Care +1 (816) 333-8811

Labconco Technical Support (800) 821-5525

Hours 7:30 a.m.-5:30 p.m. CST

Part #3849920 Rev. E

ECO M149

4


Table of Contents

1: INTRODUCTION 11
Contacting Labconco 11
About This Manual 12
Theory of Operation 12
Type A2 12
Type B2 13
Type C1 –A mode 13
Type C1 –B mode 14
2: SAFETY PRECAUTIONS 15
Typographical Conventions 15
General Safety Precautions 17
Safety Precautions for this Product 19
3: CATALOG NUMBER CONFIGURATOR 21
4: SERIAL TAG 22
Serial Tag Location 22
Serial Tag Information 23
Primary Serial Tag 23
Secondary Serial Tag 23
5: FACTORY TEST REPORT 24
Test Report Location 24
Test Report Information 25
6: ADDITIONAL PRODUCT INFORMATION 26
Data Plate Location 26

5

Data Plate Information 27
7: EXHAUST SYSTEM CONNECTIONS 28
Exhaust Connection Best Practices 28
Air-Tight Damper 30
Exhaust System Requirements 31
Type A2 Models 31
Cell Logic+ Type A2 Models 32
Type B2 Models 32
Type C1 Models 33
8: CONFIGURATION 34
Current Configuration 34
Change Configuration 36
9: CALIBRATION 40
Certifier Password 40
Adjusting Blower Speed 41
Adjusting the Internal Air Damper 43
Setting the Filter Life Gauge 45
Type A2 (8-inch through 10-inch sash) and Type B2 45
Type A2 (12-inch sash) and Type C1 46
Airflow Sensor Calibration 47
Type A2 and Type C1 47
Type B2 48
Zero Point Calibration 50
Vacuum Start Switch Calibration (Type C1 only) 51
10: CERTIFICATION 53
Certifier Password 53
Type A2 HEPA Filter Leak Test Preparation 53
Theoretical Upstream Concentration 54
Upstream Concentration Sampling 54

6

Type A2 Supply HEPA Filter Leak Test 56
Acceptance Criteria 57
Type A2 Exhaust HEPA Filter Leak Test 58
Acceptance Criteria 59
Type B2 Supply HEPA Filter Leak Test Preparation 60
Theoretical Upstream Concentration 60
Upstream Concentration Sampling 60
Type B2 Supply HEPA Filter Leak Test 62
Acceptance Criteria 63
Type B2 Exhaust HEPA Filter Leak Test Preparation 64
Theoretical Upstream Concentration 64
Type B2 Exhaust HEPA Filter Leak Test 65
Acceptance Criteria 65
Type C1 Supply HEPA Filter Leak Test Preparation 66
Theoretical Upstream Concentration 66
Upstream Concentration Sampling 66
Type C1 Supply HEPA Filter Leak Test 68
Acceptance Criteria 69
Type C1 Exhaust HEPA Filter Leak Test Preparation 70
Theoretical Upstream Concentration 70
Type C1 Exhaust HEPA Filter Leak Test 72
Acceptance Criteria 73
Downflow Velocity 74
Acceptance Criteria 75
Inflow Velocity 76
Primary Method 76
Acceptance Criteria 78
Secondary Method 79
Acceptance Criteria 83
Work Area Air Cleanliness Test (optional) 84
Acceptance Criteria 84
Lighting Test (optional) 85
Acceptance Criteria 85
Noise Test (optional) 86
Acceptance Criteria 86
Vibration Test (optional) 86
Acceptance Criteria 86

7

UV Light Intensity Test (optional) 87
Acceptance Criteria 87
Ground Fault Circuit Interrupter (GFCI) Test 88
Acceptance Criteria 88
11: QUICKCHARTS 89
QuickChart –Type A2 3-ft & 4-ft 90
QuickChart –Type A2 5-ft & 6-ft 91
Type A2 Footnotes 92
QuickChart –Type B2 93
Type B2 Footnotes 94
QuickChart –Type C1 95
Type C1 Footnotes 96
12: ADVANCED SERVICE PROCEDURES 97
Tools 97
Required 97
Optional 97
Removal of External Dress Panels 98
Dress Panel 98
Side Panels 99
Front Sash 100
Sash Level Adjustment 100
Sash Sensor Adjustment or Replacement 101
HEPA Filter Replacement 104
Type A2 (8, 9, 10-inch sash) 104
Type A2 (12-inch sash) 107
Type B2 110
Type C1 114
Blower/Motor Replacement 117
Type A2 (8, 9, 10-inch sash) & B2 117
Type A2 (12-inch sash) & C1 Supply Blower/Motor 121
Type A2 (12-inch sash) & C1 Exhaust Blower/Motor 124
Changing the LED Lamps 129
LED Lamp Socket Cap Replacement 131
Changing the Optional UV Lamp 132

8

UV Lamp Socket Replacement 133
Type B2 Prefilter Replacement 134
Air-Tight Damper Adjustment 135
Preparing the Biosafety Cabinet for Gaseous Sterilization 136
Service Fixture Installation & Service Connection 137
13: ELECTRICAL COMPONENTS 140
Electronics Module 140
Electronic Module Components 141
Resetting a Circuit Breaker 142
Power Supply Board 143
Display Board 144
Speaker 145
Blower Motor 146
Wiring Diagrams 148
100-115V 148
208-240V 149
14: TROUBLESHOOTING 150
Blower and Lights not working 150
Blower only will not start 151
Lights only will not illuminate 152
UV Light will not illuminate 153
Airflow Alert activating 154
Filter Life Gauge not at 100% when new 155
Contamination in the work area 156
15: DIAGNOSTICS 157
Sash Sensors 157
Keypad 158

9

Airflow Sensor (optional) 159
Canopy (optional) 160
16: BMS DATA OUTPUT CONNECTION 161
Connection Type 161
Data Output Format 162
Data Output Rate 162
Data Output String Definition 163
Data Output Software Requirements 164
17: VENTUSTM CANOPY CONNECTION KIT 165
Kit Catalog Numbers 166
Installation Procedure 166
Exhaust Damper Installation Procedure 167
Canopy Switch Wiring Connection 168
Calibrate for Operation 169
18: AIRFLOW SENSOR KIT 171
Installation –Type A2 without Ventus Canopy 171
Installation –Type A2 with Ventus Canopy 173
Connection to Electronics Module 175
Configuration (new install only) 176
Calibration 178
19: UV LAMP KIT 181
Kit Catalog Numbers 181
Installation 181
Configuration 183

10

20: IV BAR KIT 185
Kit Catalog Numbers 185
Installation 185
21: PREFILTER KIT 187
Kit Catalog Numbers (Type A2 and B2 only) 187
Installation 187
Attach Prefilter(s) to Towel Catch –G4 Paper 188
Attach Prefilter(s) to Towel Catch –Aluminum Washable 189
22: EN ALARM/RELAY CONTACT KIT 190
Installation 190
Example 1 –Blower Relay Contact (Single Phase AC) 194
Example 2 –Blower Relay Contact (Three Phase AC) 195
23: PARTS LIST 196
Type A2 Consumables 196
Type B2 Consumables 197
Type C1 Consumables 198
Advanced Service Components 199
