SET UP GUIDE

MODELS: S75617 & 308-147

Wireless Weather Station

with Atomic Time + Date

Table of Contents

Power Up

Outdoor Sensor Search

Low Battery Indicator

Settings Menu

HI/LO Temp Records

Button Function

Stay in Touch

We’re Here to Help

Care & Maintenance

Speciﬁcations

Warning

Warranty Info

FCC Statement

POWERUP & TROUBLE SHOOTING MAIN WEATHER STATION

APPENDIX

BONUS STATION

Setting Menu

Atomic Time

Adjustable Backlight

Auto-Dim Settings

Indoor Comfort Level

Moon Phase

Seasonal Foliage

Forecast Icons

Pressure Number

Pressure History Graph

History Records

Customizable Alerts

Extra Sensor Area

Button Functions

1. Insert 2-AA batteries into your Outdoor Sensor.

2. Insert the 5.0V Power Adapter into a working outlet. Then insert the

Power Jack end into the back of the Weather Station.

Optional: Insert 3 “AA” batteries for backup.

3. Insert 2 “AAA” batteries into you Bonus Station.

4. Once the sensor is reading to both stations, place it outside in a shaded

location to protect it from the sun’s heat.

Watch our sensor mounting video: bit.ly/th_sensor_mounting

Outdoor Sensor

TX141TH-Bv3

AAA

Bonus Station

308-147

Power Up

Basics

Weather Station

S75617

Main Weather Station

1. Hold the SET button to enter the Settings Menu.

2. Use the +/- buttons to adjust values.

3. Press SET to conﬁrm values and move to the next setting.

4. Press the LIGHT button at any time to save and exit.

Settings Menu Order:

• Greeting

• Language (English, Spanish, French, German)

• Beep ON/OFF

• Atomic ON/OFF

• DST: AUTOMATIC ON/ALWAYS ON/ALWAYS OFF

(Change Spring/Fall) (Standard Time all year) (DST all year)

• Time Zone

• 12HR/24HR

• Hour

• Minute

• Year

• Month

• Date

• Fahrenheit/Celsius

• Decimal/No Decimal (Temperature Reading)

• Pressure: InHg / hPa

• Pressure number setting

7 Time Zones

Settings Menu

Language: The language selected in this menu will control other menu

items, as well as your full weekday readout.

Atomic OFF: When Atomic OFF is selected, you will move directly to 12/24

Hour setting.

DST: Select Automatic ON for correct daylight saving time adjustments.

Weekday: Will set automatically when your Year, Month, and Date are set.

• Your station will automatically search for the Atomic Time Signal at UTC

7:00, 8:00, 9:00, 10:00, and 11:00.

• Press the SET button to manually start or stop a search for the WWVB

Atomic Time Signal.

• The Tower Icon will ﬂash while searching, and remain solid on screen

when the WWVB Signal is received.

• For information about WWVB Atomic Time visit: bit.ly/AtomicTime

Atomic Time

• Press the LIGHT button to adjust the backlight intensity.

• There are 4 brightness levels, plus an o option.

Adjustable Backlight

Note: Only the hour can be set.

Auto-Dim Settings

1. Hold the LIGHT button to enter the

Auto-Dim Settings Menu.

Program your display to automatically dim during preselected times.

2. Press the +/- buttons to turn the Auto-Dim

feature on or o. Press LIGHT to conﬁrm.

3. Press the +/- buttons to adjust the starting

hour. Press LIGHT to conﬁrm.

4. Press the +/- buttons to adjust the

stopping hour. Press LIGHT to conﬁrm and

exit.

Using relative humidity, these arrows will indicate your indoor comfort level.

A feature that can help keep your home safe and comfortable.

40%RH to 75%RH26%RH to 39%RH 76%RH to 83%RH10%RH to 25%RH 84%RH to 99%RH

COMFORT LEVEL COMFORT LEVELCOMFORT LEVEL COMFORT LEVELCOMFORT LEVEL

Indoor Comfort Level

Note: Indoor Humidity may not change frequently.

The moon phase is based on the Lunar Calendar and the year, month, and date

settings.

Small Waxing

Gibbous

New

Moon

Large Waxing

Gibbous

First

Quarter

Large Waxing

Crescent

Small Waxing

Crescent

Full

Moon

Small Waning

Crescent

Large Waning

Crescent

Last

Quarter

Small Waning

Gibbous

Large Waning

Gibbous

Moon Phase

Seasonal Trees Changes

The foliage scene in the forecast section changes seasonally.

The dates are pre-programmed.

Spring (March 20th to June 20th)Summer (June 21st to Sept. 20th)

Fall (Sept. 21st to Dec. 20th)Winter (Dec. 21st to March 19th)

Seasonal Foliage

• The forecast icons use the station’s internal barometer

to predict conditions to come within the next 12 hours.

• The Snow Icon will show when temperatures are below

32°F (0°C) and rain or storms are predicted.

• The Sun Icon will show in daylight hours (7am to 6:59pm) and

the Moon Icon will show during nighttime (7pm to 6:59am) for

clear or partly clear forecasts.

FORECAST

SUN SNOWT-STORMRAINCLOUDSPARTLY SUNNY

FORECAST FORECAST FORECAST

Forecast Icons

Pressure Number

Your Relative Pressure reading will come from your

station’s internal barometer. Allow up to 10 days for

automatic calibration. Or you can program your local

pressure value in the Settings Menu. The arrows on

the left represent rising and falling tendency.

Pressure History Graph

Read from left to right, the Pressure History Graph

indicates the rise and fall in air pressure over the

past 24 hours.

Pressure

BAROMETRIC

PRESSURE

History Records

From normal time display, press and release the HISTORY button to toggle

through indoor/outdoor temperature and humidity records with time and

date stamps.

Records Viewing Order

•Outdoor High Temperature

•Outdoor Low Temperature

•Outdoor High Humidity

•Outdoor Low Humidity

•Indoor High Temperature

•Indoor Low Temperature

•Indoor High Humidity

•Indoor Low Humidity

•Heat Index

•Dew Point

MOON PHASE COMFORT LEVEL

HUMDITY HUMDITY

BAROMETRIC

PRESSURE

MOON PHASE COMFORT LEVEL

HUMDITY HUMDITY

BAROMETRIC

PRESSURE

Resetting Individual Records

1. Press the HISTORY button until viewing the value you’d like reset.

2. Hold the (-) MINUS button until dashes appear, indicating that value has

been reset to your current readings.

Note: When an add-on Rain Sensor is connected, the Rain History will show

ﬁrst when the HISTORY button is pressed. There is no history for add-on

Temperature/Humidity sensors.

Rain History: 1 Hour, 24 Hours, 7 Days, 1 Month, Year, and Total. 8

Customizable Alerts

Alerts Setting Order

Outdoor Low Temperature •Outdoor High Temperature •Outdoor Low Humidity

Outdoor High Humidity •Indoor Low Temperature •Indoor High Temperature

Indoor Low Humidity •Indoor High Humidity

Activating/Deactivating Alerts

•When alert value is reached, station will beep 5 times each minute, until

out of alert range.

•When the armed alert value is reached, the station will beep and the icon will

ﬂash. Press any button to stop the alert sound.

•The Alert Icon will remain ﬂashing until out of the alert range.

Alert Sounds

Setting Custom Alerts

MOON PHASE COMFORT LEVEL

HUMDITY HUMDITY

BAROMETRIC

PRESSURE

1. Hold the ALERTS button to enter the Alert

Settings Menu.

2. Use the +/- buttons to activate/deactivate

and adjust alerts settings. Press ALERTS to

conﬁrm your selection.

3. Your programmed alerts are active when the

and / icon appear on the LCD.

When in the Alerts Settings Menu, use the +/- buttons to activate or

deactivate alerts. Indicated by the icons in that section.
