La Crosse Technology 308-1409BTV4 Manual de usuario

SET UP GUIDE

MODEL: 308-1409BTv4

Wireless Thermometer

1. Insert 2-AA batteries into your Outdoor Sensor.

2. Insert 2-AAA batteries Into your Thermometer.

3. Enter the Settings Menu to adjust your time.

4. Once the sensor is reading to your thermometer, place the sensor

outside in a shaded location. View our sensor mounting video here:

bit.ly/th_sensor_mounting

POWER UP

Thermometer

308-1409BTv4

Outdoor Sensor

TX141-Bv4

AAA

FAHRENHEIT OR CELSIUS

· Press +/°F/°C to select Fahrenheit or Celsius Temperature Display

1. Hold the SET/HI/LO button until the display changes to enter the

Settings Menu. Press and release the +/°F/°C button to adjust values.

Hold to adjust quickly.

2. Press and release the SET/HI/LO button to conﬁrm values and move to

the next setting or exit the menu.

SETTINGS MENU

HI/LO TEMPERATURE RECORDS

Press the SET/HI/LO button to view the HI then the LO

Temperature Records.

Reset HI /LO Records:

1. Press the SET/HI/LO button to view records

2. When viewing HI/LO records, hold the

SET/HI/LO button for ﬁve seconds to reset all records

at one time.

3. HI/LO readings will reset to current temperature.

Note: The records will automatically reset daily at 12:00AM.

LO Records

HI Records

TEMPERATURE TREND ARROWS

The arrows next to the temperature readings indicate if the

temperature is rising, falling, or remaining steady.

Temperature has risen (2°F / 1°C)

Temperature has not changed

Temperature has fallen (2°F / 1°C)

SEARCH FOR OUTDOOR SENSOR

• If the sensor loses connection to the thermometer for any reason, the hermometer

will show dashes after 30 minutes.

• The thermometer will automatically search for 3 minutes every hour to try and

reestablish the sensor connection.

• To manually search for your Outdoor Sensor, hold the +/°F/°C button until the

Reception Icon begins to ﬂash.

• When the sensor is connected, the Reception Icon will be solid.

• If your thermometer is unable to reconnect on its own, a Restart may be necessary.

RESTART

1. Bring your sensor inside next to the thermometer and remove batteries from

both devices.

2. Press any button at least 20 times, and then wait 15 minutes.

3. After the wait, install fresh batteries into both your sensor and thermometer. Your

outdoor temperature should return within the next few minutes.

4. Keep your sensor next to the thermometer for another 15 minutes to

establish a strong connection.

5. Once connection is reestablished, place it back outside in a shaded location.

Note: Pressing the TX button inside the sensor’s battery compartment will help

force a transmission.

LOW BATTERY INDICATOR

Low Battery Icon by Outdoor Temperature, replace batteries in the Outdoor

Sensor.

Low Battery Icon by the Indoor Temperature, replace batteries in the

Thermometer.

SENSOR WEATHER SHIELD-NOT INCLUDED

• The Sensor Weather Shield is designed to protect your outdoor sensor

from rain and snow. Optional.

• This shield will oer limited protection from the sun’s heat.

• Optional Purchase at: bit.ly/925-1418

SPECIFICATIONS

308-1409BTv4:

Temperature Range:

32°F to 122°F (0°C to 50°C)

Humidity Range: 10% to 99% RH

Power Requirements:

2 “AAA” LR3 Batteries (not included)

Battery Life: Over 24 months with reputable

batteries

TX141-Bv4

Temperature Range:

-40°F to 140°F (-40°C to 60°C)

Transmission Range: over 330 feet

(100 meters) in open air RF 433MHz

Power Requirements: 2 “AA” LR6 Batteries

(not included)

Battery Life: Over 24 months with reputable

batteries

CARE AND MAINTENANCE

When batteries of dierent brand or type are used

together, or new and old batteries are used together,

some batteries may be over-discharged due to a

dierence of voltage or capacity. This can result

in venting, leakage, and rupture and may cause

personal injury.

•Do not mix Alkaline, Lithium, standard, or

rechargeable battteries.

•Always purchase the correct size and grade of

battery most suitable for the intended use.

•Always replace the whole set of batteries at one

time, taking care not to mix old and new ones, or

batteries of dierent types.

•Clean the battery contacts and also those of the

device prior to battery installation.

•Ensure the batteries are installed correctly with

regard to polarity (+ and -).

•Remove batteries from product during periods of

non-use. Battery leakage can cause corrosion and

damage to this product.

•Remove used batteries promptly.

•For recycling and disposal of batteries, and

to protect the environment, please check the

internet or your local phone directory for local

recycling centers and/or follow local government

regulations.

Ask questions, watch setup videos, and

provide feedback on our social media outlets.

Follow La Crosse Technology on YouTube,

Twitter, Facebook and Instagram.

STAY IN TOUCH!

WE’RE HERE TO HELP

If you require additional support, call our

friendly customer support team based out of

La Crosse, Wisconsin.

Self Help: bit.ly/308-1409btv4_support

Phone: 1.608.782.1610

Online: bit.ly/contact_techsupport

Our knowledgeable customer support team is

available: Monday-Friday, 8am-6pm CST.

This product can expose you to chemicals including

acrylonitrile, butadiene, and styrene, which are

known to the State of California to cause cancer and

birth defects or other reproductive harm. For more

information, go to: www.P65Warnings.gov

CA WARNING:

Scan for

Support

WARRANTY

La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product

relating to manufacturing defects in materials & workmanship.

La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601

For Full Warranty Details, Visit: www.lacrossetechnology.com/support

Patents: www.lacrossetechnology.com/patents

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

•Increase separation between equipment & receiver.

•Consult the dealer or an experienced radio/TV technician for help.

This device must not be co-located or operating in conjunction with any other antenna or transmitter.

Operation is subject to the following two conditions:

(1 ) This device may not cause harmful interference, and (2) This device must accept any interference

received, including interference that may cause undesired operation.

CAUTION!

The manufacturer is not responsible for any radio or TV interference caused by unauthorized changes or

modifications to this equipment. Such changes or modifications could void the user authority to operate the

equipment.

processed using electronic, mechanical or chemical process without the written permission

of the publisher. This booklet may contain errors or misprints. The information it contains is regularly

checked and corrections are included in subsequent editions. We disclaim any responsibility for any

technical error or printing error, or their consequences. All trademarks and patents are recognized.

Designed in La Crosse, Wisconsin •Made in China •Printed in China •DC 012323

DOUBLE YOUR WARRANTY

Scan Here

Scan the QR Code or visit:

bit.ly/308-1409btv4_register

to register your product and double the

standard 1-year warranty fo free by opting

to recieve occasional product emails.

GUIDE D’INSTRUCTIONS

MODÈLES: 308-1409BTv4

THERMOMÈTRE SANS FIL

1. Insérer 2 piles AA dans votre capteur extérieur.

2. Insérer 2 piles AAA dans votre thermomètre sans ﬁl.

3. Ajuster les paramètres d’heure et de date sur le thermomètre.

4. Une fois que le capteur extérieur lit votre thermomètre, placez-

le à l’extérieur dans un endroit ombragé.

Regarder la vidéo de montage du capteur: bit.ly/th_sensor_mounting

MISE SOUS TENSION

Thermomètre sans ﬁl

308-1409BTv4

Capteur extérieur

TX141-Bv4

AAA

FAHRENHEIT OU CELSIUS

Appuyez sur + / ° F / ° C pour sélectionner l’affichage de la température

Fahrenheit ou Celsius
