La Crosse Technology C86224 Manual de usuario

Model: C86224

Instructional Manual

DC:032416

Alarm Clock Charging Station

with 2 USB Charging Ports

Table of Contents

Buttons (on top) ..............................................................................

LCD Features ...................................................................................

Setup .............................................................................................

Settings: Language, Time, Date, etc. ..................................................

Nap Feature .....................................................................................

Backlight (HI-LOW-OFF).......................................................................

USB Charge Ports .............................................................................

Included USB to Micro or Lightning Cable ............................................

Cable Hooks ....................................................................................

Time Alarm .....................................................................................

Alarm Type Indicators .......................................................................

Activate/Deactivate Alarm .................................................................

Snooze ...........................................................................................

Low Battery Icon ..............................................................................

Care and Maintenance .......................................................................

Specifications ..................................................................................

Warranty and Support .......................................................................

LCD Features

Time (manual set)

Low Battery Icon

Alarm Icon (M-F)

Weekday, Nap duration, or

Snooze duration

Month/Date

Indoor Temperature

Indoor Humidity

11 USB 2 Charge Port 2 Amp

USB 1 Charge Port 1 Amp

USB 2 Charge Indicator

USB 1 Charge Indicator

1. Insert the 5.0 volt power cable

into the outlet, then into the

clock.

2. (Optional), Insert 2 AAA

batteries (included) into the

clock.

3. Set language, time, calendar,

temperature unit and snooze

duration.

AAA

Buttons (on top)

PLUS MINUS ALARM NAP SET SNZ/LIGHT

lacrossetechnology.com/support Page | 1

Setup

10 11

1 Amp 2 Amp

Settings: Language, Time, Date, etc.

• Hold the SET button to enter time set mode.

• Press the +/- buttons to adjust the values.

• Press the SET button to conrm adjustments and move to the

next item.

• Press the SNZ/LIGHT button at any time to exit.

Time set order:

1. Language (English or Spanish)

2. Beep ON/OFF

3. Hour

4. Minutes

5. Year

6. Month

7. Date

8. Fahrenheit/Celsius

9. Snooze duration (5 minutes-120 minutes)

.lacrossetechnology.com/support C86224

Begin: Hold the SET button for 3 seconds. ENGLISH will show.

When Español

is selected, the

instructions on

screen will be

in Spanish.

Language: English or Espanol

BEEP ON/OFF Hour then Minutes

Year then Month then Date

lacrossetechnology.com/support Page | 3

Nap Feature

Sometimes, we just want a quick nap without having to set a new

alarm. Set the nap duration one time, then, a simple press of the

NAP button starts the nap countdown.

Set Nap Duration:

1. Hold the NAP button for 3 seconds. NAP and the duration will show

(default is 10 minutes).

2. Use the +/- buttons to select a nap duration (up to 120 minutes).

3. Press the NAP button to conrm and start nap count down to zero.

4. Press the SNZ/LIGHT button at any time to exit.

Fahrenheit or Celsius Snooze Time 5-120 minutes

Ready for a Nap? Press the NAP button once, and the clock will wake

you at the preselected time.

• From normal time display, press the NAP button once to start the

nap feature for the preset time. NAP will show with the preset

duration.

• Minutes and seconds will countdown.

• When the alarm sounds NAP and 0m will ash. The alarm will

sound for two minutes and then stop if no buttons are pressed.

• Press any button except SNZ/LIGHT, at any time to exit nap mode.

PM PM

.lacrossetechnology.com/support C86224

Backlight (HI-LOW-OFF)

• When operating with the power cable, the backlight is adjustable:

HI-LOW-OFF.

• Press and release the SNZ/LIGHT button to adjust the backlight.

• When operating on batteries only, the backlight will come on

briey when the SNZ/LIGHT button is pressed.

USB Charge Ports

USB Output:

• Charge devices that self-regulate.

• Do not charge multiple devices from the same

USB port.

• For Tablets and other high power devices, use the

USB port on the right (2 Amp).

• Must operate clock with power cable to charge

other devices.

• Plug your device into one of the USB ports on the

front of the clock.

• The clock will show HELLO for 3 seconds.

• The lightning bolt will ash while charging.

• When no device is connected, no battery will show.

• As your device becomes full and less current is

drawn, solid battery icon may show, before the

charge is complete.

Note: The FULL icon will show when full. After charging, the

clock will provide a trickle charge and show the charging icon.

Your device may not show fully charged.

Charging Not Connected Full Not Connected

Included USB to Micro USB or Lightning Cable

• The included USB cord offers a

Micro USB connection or a

Lightning connection on the

same cord.

• Use your own charge cord or

the included cord to charge your

device.

• Place your cord in the handy

hook on the back of the clock.

lacrossetechnology.com/support Page | 5

Cable Hooks

• On the back of the clock there are two cable hooks to secure your

charging cables.

• Simply slide your cable into the hook and the end of your cable will

be easy to nd every time.

Time Alarm

• Press and release the ALARM button to view alarm time.

• With alarm time showing, hold the ALARM button for 3 seconds to

enter alarm settings.

• Set the time then select alarm type:

(Single alarm, Mon-Fri alarm, or Weekend alarm)

• Setting and activating the alarm are separate functions.

Alarm Type (choose the type for each alarm):

•

Daily/Single

-Will alarm at the same time every day when active.

•

Mon-Fri-

Will only alarm Monday through Friday when active.

•

Weekend

- Will only alarm Saturday and Sunday when active.

Set Alarm:

1. Press and release the ALARM button to view alarm time.

2. With alarm time showing, hold the ALARM button for 3 seconds to

enter alarm time set mode.

3. Press the +/- buttons to adjust the alarm hour.

4. Press the ALARM button to conrm and move to the minutes.

5. Press the +/- buttons to adjust the alarm minutes.

6. Press the ALARM button to conrm and move to alarm type.

7. Use the +/– to select SINGLE, MON-FRI or WEEKEND alarm.

8. Press the ALARM button to conrm and exit.

Note: This is a crescendo alarm. It will sound for two minutes

then shut off completely if no buttons are pressed.

.lacrossetechnology.com/support C86224

Alarm Type

Daily / Single Mon-Fri Weekend

Activate/Deactivate Alarm

• When you nish settings, the alarm is active.

• From the normal time display, press and release the ALARM button

to view alarm.

• Press and release the ALARM button to deactivate or to activate the

alarm.

• When active the alarm clock icon will show.

• The clock icon will not show if the alarm is not active.

Alarm Hour then Minutes

Alarm Type:

•

Daily/Single: Clock icon only

•

Mon-Fri: Clock icon with 5 lines below

•

Weekend

:Clock icon with 2 lines below

Alarm Type Indicator

Daily / Single Mon-Fri Weekend

Snooze

• When the alarm sounds, press the SNZ/LIGHT button. The alarm

will be silent for the preselected snooze duration.

• SNOOZE - duration will show, and the snooze time will count down.

• When alarm sounds again, the SNOOZE - 0 will ash.

AM AM

acrossetechnology.com/support Page | 7

• Do not mix old and new batteries.

• Do not mix Alkaline, Standard, Lithium, or Rechargeable Batteries.

• Always purchase the correct size and grade of battery most suitable for

intended use.

• Replace all batteries of a set at the same time.

• Clean the battery contacts and also those of the device prior to battery

installation.

• Ensure the batteries are installed with correct polarity (+ and -).

• Remove batteries from equipment when it is not used for extended

period.

• Promptly remove expired batteries.

Care and Maintenance

Low Battery Icon

• The low battery icon will appear between the hour and minutes.

• This icon indicates it is time to replace the batteries.

Warranty and Support

La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date

of purchase) on this product relating to manufacturing defects in materials &

workmanship.

Before returning a product, please contact our friendly customer

support with questions or visit our online help:

Phone: 1-877-408-2678

Online Product Support:

www.lacrossetechnology.com/support

Product Registration:

www.lacrossetechnology.com/support/register

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

Warranty Address:

La Crosse Technology, Ltd

2830 S. 26th St.

La Crosse, WI 54601

Specications

Temperature Range: 32 °F to 122°F (0°C to 50°C)

Humidity Range: 10%RH to 99%RH

Power: 5.0V AC6: HX36-0503500AU

Optional-2-AAA, IEC, LR3 batteries (included)

USB Output: 1 Amp and 2 Amp

Battery Life: Battery life is over 24 months with reputable batteries

Dimensions: 3.74” W x 2.40” D x 5.24” H (95 x 61 x 133 mm)

Tabla de contenidos

Otros manuales de Reloj de La Crosse Technology

La Crosse Technology

La Crosse Technology 513-1419 Dimensiones

La Crosse Technology

La Crosse Technology 404-1220 Manual de usuario

La Crosse Technology

La Crosse Technology 513-1419v4-WA Manual de usuario

La Crosse Technology

La Crosse Technology 513-1417H-AL Dimensiones

La Crosse Technology

La Crosse Technology Clock Manual de usuario

La Crosse Technology

La Crosse Technology Radio Controlled Analog Clock Manual

La Crosse Technology

La Crosse Technology WT-8002U Manual de usuario

La Crosse Technology

La Crosse Technology W88631 Dimensiones

La Crosse Technology

La Crosse Technology C86279 Manual de operación y mantenimiento

La Crosse Technology

La Crosse Technology WS-8120U Manual de usuario

La Crosse Technology

La Crosse Technology WS-8055U Manual de usuario

La Crosse Technology

La Crosse Technology WT-3102B Manual de usuario

La Crosse Technology

La Crosse Technology 404-3840FL Manual de usuario

La Crosse Technology

La Crosse Technology BBB87269 Manual de usuario

La Crosse Technology

La Crosse Technology WT-3181PLX1 Dimensiones

La Crosse Technology

La Crosse Technology W86111V2 Manual de usuario

La Crosse Technology

La Crosse Technology WT-8005U Manual de usuario

La Crosse Technology

La Crosse Technology WS-8256-AL Manual de usuario

La Crosse Technology

La Crosse Technology 404-3229A Manual de usuario

La Crosse Technology

La Crosse Technology 513-1417v4 Manual de usuario

La Crosse Technology

La Crosse Technology W86111V2 Manual de usuario

La Crosse Technology

La Crosse Technology WS-6118AL-IT Manual de usuario

La Crosse Technology

La Crosse Technology WS-8007U Manual de usuario

La Crosse Technology

La Crosse Technology C75723-AU Manual de usuario

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

Sharp

Sharp SPC900 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario

IKEA

IKEA ROTBLÖTA Manual de usuario

U-Line

U-Line Н-2811 Manual de usuario

Digiview

Digiview RC305EL Manual de usuario
