SET UP GUIDE

MODEL: 513-1918S

ATOMIC DIGITAL WALL CLOCK

WITH INDOOR/OUTDOOR TEMPERATURE

1. Insert 2-AA batteries into your Temperature Sensor.

2. Insert 3-AAA batteries into your Atomic Clock.

3. Once the sensor is reading your Clock, place the sensor outside.

Watch our sensor mounting video: bit.ly/th_sensor_mounting

TH Sensor

TX191

Power Up

Atomic Clock

513-1918S

The buttons are located at the top of your clock.

Buttons

AAA

SNOOZE Press to exit Settings Menu.

When Alarm Sounds press to Snooze Alarm for 10 minutes.

ALARM Hold to enter Alarm Settings. Press to activate/deactivate alarm.

Alarm Icon will show when alarm is active.

SET Hold to enter the Settings Menu.

Press to change Date Display.

PLUS +

Hold to search for Outdoor Sensor.

Press to manually search for the WWVB Atomic Time Signal.

Settings Menu: Press to increase value. Hold to increase quickly.

MINUS  Settings Menu: Press to decrease value. Hold to decrease quickly.

Settings Menu

1. Hold the SET button until the display changes to enter the Settings

Menu.

2. Press and release the +or -button to adjust values.

3. Press the SET button to confirm and move to next item.

Settings Menu Order:

• Language English | Spanish | French

• Beep ON | OFF

• Atomic ON | OFF

• Daylight Saving Time

- DST AUTO ON (Gain 1 hour in spring, lose 1 hour in fall)

- DST OFF (Remain in Standard Time all year long)

- DST ON (Remain in Daylight Saving Time all year long)

• Time Zone

• Hour

• Minutes

• Year

• Month

• Date

• Fahrenheit | Celsius

Language: Whichever language is selected, the following instructions and

weekday will be presented in that language.

Atomic O: When Atomic O is selected, you will move directly to the Hour

setting.

Weekday: Weekday will set automatically when Year, Month and Date are

set.

TIME ZONES

AST = Atlantic

EST = Eastern

CST = Central

MST = Mountain

PST = Paciﬁc

AKT = Alaska

HAT = Hawaii

Atomic Time

•Your Clock will automatically search for the Atomic Time Signal at UTC

7:00, 8:00, 9:00, 10:00, and 11:00.

•Press the PLUS (+) button to manually start or stop search for the WWVB

Atomic Time Signal.

•While searching, the Tower Icon will ﬂash. The Tower Icon will be solid

when the WWVB Signal is received by your clock.

•For information about WWVB Atomic Time visit: bit.ly/atomic_time

TIME ALARM

Set Alarm:

1. Hold the ALARM button to enter the Alarm Settings Menu.

2. Press and release the + or - button to adjust the ﬂashing values.

3. Press the ALARM button to conﬁrm and move forward.

Press and release the SET button to change the Custom Date Display.

Custom Date Display

Activate/Deactivate Alarm:

The alarm is active when set.

Press and release the ALARM button to deactivate or activate the alarm.

The Alarm Time will show brieﬂy.

The Alarm Icon will show only when alarm is active.

Silence a sounding alarm:

Press any button except SNOOZE to silence alarm for 24 hours.

Snooze:

When the alarm sounds, press the SNOOZE button to silence the alarm

for 10 minutes. The Alarm Icon will flash.

Note: The alarm will sound with increasing frequency for two minutes,

then shut off completely if not deactivated.

Search for Sensors

If you are seeing “NO” or dashes for any sensor readings, please try the

following steps:

1. Hold the PLUS (+) button to search for all sensors.

The Reception Indicator will begin to animate.

2. If after 3 minutes the sensor still isn’t connected, bring the sensor inside next

to the display and remove power from the sensor and station.

3. Press any button on the station 20 times and leave the parts sit for a few

moments with the power o.

4. Install a new set of alkaline batteries into the sensor, then power up your

station again.

5. If your sensor data is still not appearing after these steps, please contact our

support sta. For additional help visit: bit.ly/basic_restart

Sensor Placement & Mounting

For Accurate Temperature/Humidity Measurements

•Insert a mounting screw through the hole at the top to securely mount

the sensor. It can also hang from the back using a nail.

•Mount the sensor vertically in a protected well-shaded area. Keeping

it out of direct weather elements such as sunlight, rain, snow, etc. will

help avoid inaccurate readings.

•For additional protection against weather elements, a Sensor Weather

Shield: bit.ly/weather-shield can be purchased separately.

•The maximum wireless transmission range to the station is up to 330ft

(100m) in open air. This does not include walls, ﬂoors, or other large

obstructions.

•For online video instructions, visit: bit.ly/th_sensor_mounting

Low Battery Icons

Low Battery Icon by the Time, replace batteries in the Clock.

Low Battery Icon by Outdoor Temperature, replace batteries in the Outdoor

Sensor.

• The Sensor Weather Shield is designed to protect your outdoor

sensor from rain and snow.

• This shield will oer limited protection from the sun’s heat.

• Optional purchase at: bit.ly/weather-shield

*Not included

Sensor Weather Shield

Atomic Clock (513-1918S)

Temperature Range: 32ºF to 122ºF (0ºC to 50ºC)

Update Interval: About every 30 seconds

Power: 3-AA, IEC, LR3 batteries (not included)

Battery Life: Over 18 months

Dimensions: 8.97” W x 0.94” D x 7.12” H (22.78cm W x 2.38cm D x 18.08cm H)

Speciﬁcations

Temp. Sensor (TX191)

Temperature Range: -40°F to 140°F (-40°C to 60°C)

Transmission Range: Over 330 feet (100 meters) in

open air RF 433MHz

Update Interval: About every 51 seconds

Power: 2-AA, IEC, LR6 batteries (not included)

Battery Life: Over 18 months

Dimensions: 1.57” W x 0.95” D x 4.49” H

(3.98 L x 2.41 W x 11.40 H cm)

3.13”

7.95cm

0.94”

2.38cm

8.97”

22.78cm

7.12”

18.08cm

4.99”

12.67cm

0.95”

2.41cm

1.57”

3.98cm

4.49”

11.40cm

If you require additional assistance, get in touch with our

friendly customer support team based in La Crosse, WI.

Self Help: bit.ly/513-1918s_support

Online: bit.ly/contact_techsupport

Phone: 1.608.782.1610

Our knowledgable customer support team is available:

Mon-Fri 8am-6pm CST

We’re Here to Help SCAN HERE

Additional Info

and Support

Ask questions, watch setup videos, and provide feedback on our social media

outlets. Follow La Crosse Technology on YouTube, Twitter, Facebook and Instagram.

Stay in Touch!

Warranty & Patents

La Crosse Technology, Ltd. provides a 1-year limited time warranty

(from date of purchase) on this product relating to manufacturing defects in materials

& workmanship.

La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601

For Full Warranty Details, Visit: www.lacrossetechnology.com/pages/warranty

Patents: www.lacrossetechnology.com/pages/patents

Designed in La Crosse, Wisconsin •Made in China •Printed in China •DC0601323

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation.

Caution!

Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority

to operate the equipment.

mechanical or chemical process without the written permission of the publisher. This booklet may contain errors or misprints.

The information it contains is regularly checked and corrections are included in subsequent editions. We disclaim any

responsibility for any technical error or printing error, or their consequences. All trademarks and patents are recognized.

The manufacturer is not responsible for any radio or TV interference caused by unauthorized changes or modiﬁcations to this

equipment. Such changes or modiﬁcations could void the user authority to operate the equipment.

FCC Statement

Care & Maintenance

When batteries of dierent brand or type are used together, or new and old batteries are used together, some batteries may

be over-discharged due to a dierence of voltage or capacity. This can result in venting, leakage, and rupture and may cause

personal injury.

•Do not mix Alkaline, Lithium, standard, or rechargeable battteries.

•Always purchase the correct size and grade of battery most suitable for the intended use.

•Always replace the whole set of batteries at one time, taking care not to mix old and new ones, or batteries of dierent

types.

•Clean the battery contacts and also those of the device prior to battery installation.

•Ensure the batteries are installed correctly with regard to polarity (+ and -).

•Remove batteries from product during periods of non-use. Battery leakage can cause corrosion and damage to this

product.

•Remove used batteries promptly.

•For recycling and disposal of batteries, and to protect the environment, please check the internet or your local phone

directory for local recycling centers and/or follow local government regulations.

This product can expose you to chemicals including acrylonitrile, butadiene, and styrene, which are known to the State of

California to cause cancer and birth defects or other reproductive harm. For more information, go to:

www.P65Warnings.gov

CA WARNING:

DOUBLE YOUR WARRANTY

Scan Here

Scan the QR Code or visit:

bit.ly/513-1918s_register

to register your product and double the

standard 1-year warranty for free by opting

to recieve occasional product emails.

Otros manuales para 513-1918S

Tabla de contenidos

Otros manuales de Reloj de La Crosse Technology

La Crosse Technology

La Crosse Technology WS-8117U-IT Manual de usuario

La Crosse Technology

La Crosse Technology 513-1417BS Manual de usuario

La Crosse Technology

La Crosse Technology WS-8001U Manual de usuario

La Crosse Technology

La Crosse Technology WS-8115U Manual de usuario

La Crosse Technology

La Crosse Technology 513-1419BLV3 Manual de usuario

La Crosse Technology

La Crosse Technology C86279 Manual de operación y mantenimiento

La Crosse Technology

La Crosse Technology WS-8418AL-IT Manual de usuario

La Crosse Technology

La Crosse Technology W86111V2 Manual de usuario

La Crosse Technology

La Crosse Technology 513-1417CHv2 Manual de usuario

La Crosse Technology

La Crosse Technology 404-1220 Manual de usuario

La Crosse Technology

La Crosse Technology BBB87740 Manual de usuario

La Crosse Technology

La Crosse Technology WT-8005U Dimensiones

La Crosse Technology

La Crosse Technology 513-1419BL-WA Manual de usuario

La Crosse Technology

La Crosse Technology 513-1918B Manual de usuario

La Crosse Technology

La Crosse Technology WT-3143A Manual de usuario

La Crosse Technology

La Crosse Technology WS-8236U Manual de usuario

La Crosse Technology

La Crosse Technology 513-1918S Manual de usuario

La Crosse Technology

La Crosse Technology 513-1429 Dimensiones

La Crosse Technology

La Crosse Technology M78786 Manual de usuario

La Crosse Technology

La Crosse Technology BBB86088v2 Manual de usuario

La Crosse Technology

La Crosse Technology WT-8002Uv2 Manual de usuario

La Crosse Technology

La Crosse Technology WT-3122H Manual

La Crosse Technology

La Crosse Technology WS-8055U Manual de usuario

La Crosse Technology

La Crosse Technology WS-8120U Manual de usuario

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

Sharp

Sharp SPC900 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario

IKEA

IKEA ROTBLÖTA Manual de usuario

U-Line

U-Line Н-2811 Manual de usuario

Digiview

Digiview RC305EL Manual de usuario
