Kyocera Ci1000 Manual de usuario

Operating Instructions for the Ci1000 Color

Printer

FINAL Draft August 6, 1998

i General

(FCC) and Safety Information

General

Warning

• To prevent ﬁre or shock hazard, do not expose this product to rain or any type

of moisture.

Caution

• Do not open covers and do not attempt to repair the unit yourself. Refer

servicing to qualiﬁed personnel.

Power source

Warning

• The power source voltage of this unit is listed on the nameplate. Only plug the

unit into an outlet with the proper voltage.When you operate this equipment,

the outlet should be near the equipment and accessible.

• To ensure safe operation the AC cord supplied must be inserted into standard

three-prong AC outlet which is effectively grounded (earthed) through the

normal wiring.

• The fact that the equipment operates satisfactorily does not imply that the

power point is grounded(earthed) and that the installation is completely safe.

For your safety, if in any doubt about the effective grounding (earthing) of the

power point, consult a qualiﬁed electrician.

• If the plug cannot be inserted into the AC outlet, contact a licensed electrician

to replace the outlet with a properly grounded (earthed) one. Do not defeat the

purpose of the grounding (earthing) plug (ex. do not use a conversion plug).

Laser safety

Caution

• This printer utilizes a laser. Use of controls or adjustments or performance of

procedures other than those speciﬁed here may result in hazardous radiation

exposure.

For Your

Safety

ii General

Ozone release

Warning

• Make sure that the printer is installed in a well ventilated room so as not to

increase density of ozone in the air. Since ozone is heavier than air, it is

recommended that air at ﬂoor level be ventilated.

Moving the unit

The printer weighs approximately 47.9 kg {105.5 lb}. It must be handled by two

people.Turn the power off and remove the power cord when handling the unit.

iii General

Caution labels

ATTENTION:

SURFACE

CHAUDE

CI-INTERIEUR

VORSICHT:

HEISSE FLÄCHE

INTERN

ATENCION:

SUPERFICIE

CALIENTE

EN EL INTERNO

CAUTION:

HOT SURFACE

INSIDE

CAUTION:

HOT SURFACE INSIDE

CAUTION:HOT SURFACE BELOW

ATTENTION:SURFACE CHAUDE CI-DESSOUS

VORSICHT:HEIßE OBERFLÄCHE DARUNTER

ATENCION:SUPERFICIE CALIENTE ABAJO

CLASS

KLASSE

CLASSE

CLASE

1 LASER PRODUCT

1 LASER PRODUKT

1 LASER PRODUIT

1 LÁSER PRODUCTO

ATTENTION:

Rayonnement laser invisible

dangereux en cas

d'ouverture et lorsque

la sécurité est neutralisée.

EXPOSITION DANGEREUSE

AU FAISCEAU.

VARNING:

Osynlig laser-

strålning när denna

del är öppnad och

spärrar är

urkopplade.

STRÅLEN

ÄR FARLIG.

VARO!:

Näkymätöntä

avattaessa ja

suojalukitus

ohitettaessa olet

alttiina lasersäteilylle.

ÄLÄ KATSO

SÄTEESEEN.

VARNING:

Osynlig laserstrålning

när denna del är

öppnad och spärren är

urkopplad.

BETRAKTA EJ

STRÅLEN.

ADVARSEL:

Usynlig laserstråling

ved åbning når

sikkerhedsafbrydere

er ude af funktion.

UNDGÅ

UDSÆTTELSE FOR

STRÅLING.

PELIGRO:

Cuando se abre y se

invalida el bloqueo, se

producen radiaciones

invisibles de láser.

EVÍTESE LA

EXPOSICIÓN

A TALES RAYOS.

DANGER:

Invisible laser radiation

when open and interlock

defeated.

AVOID DIRECT

EXPOSURE TO BEAM.

CAUTION:

Invisible laser radiation

when open and

interlocks defeated.

AVOID EXPOSURE

TO BEAM.

VORSICHT:

Unsichtbare Laserstrahlung,

wenn Abdeckung geöffnet

und Sicherheitsverriegelung

überbrückt.

NICHT DEM STRAHL

AUSSETZEN.

ADVARSEL:

Usynlig laserstråling

når deksel åpnes og

sikkerhedslas brytes.

UNNGÅ

EKSPONERING

FOR STRÅLEN.

(220-240 VAC equipment)

Laser diode properties

Laser output : 5 mW max

Wavelength : 780 nm

Emission duration : Continuous

iv General

FOR USERS IN U.K.

IMPORTANT:

FOR YOUR SAFETY PLEASE READTHE FOLLOWING TEXT

CAREFULLY

This printer is supplied with a moulded three pin mains plug each for your safety

and convenience. A 13 amp fuse is ﬁtted in this plug. Should the fuse need to be

replaced please ensure that the replacement fuse has a rating of 13 amps and that

it is approved by ASTA or BSI to BS 1362.

Check for the ASTA mark or the BSI mark on the body of the

fuse.

If the plug contains a removable fuse cover you must ensure that it is reﬁtted when

the fuse is replaced. If you lose the fuse cover the plug must not be used until a

replacement cover is obtained. A replacement fuse cover can be purchased from

your local Panasonic Dealer.

IFTHE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET

OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED

ANDTHE PLUG CUT OFF AND DISPOSED OF SAFELY.THERE IS A

DANGER OF SEVERE ELECTRICAL SHOCK IFTHE CUT OFF PLUG IS

INSERTED INTO ANY 13 AMP SOCKET.

If a new plug is to be ﬁtted please observe the wiring code as shown below. If in

any doubt please consult a qualiﬁed electrician.

WARNING:THIS APPLIANCE MUST BE EARTHED.

IMPORTANT: The wires in this mains lead are coloured in accordance with the

following code.

Green-and-Yellow: Earth Blue: Neutral Brown: Live

ASA

v General

As the colours of the wire in the mains lead of this appliance may not correspond

with the coloured markings identifying the terminals in your plug, proceed as

follows.

The wire which is coloured GREEN-AND-YELLOW must be connected to the

terminal in the plug which is marked with the letter E or by the Earth symbol

, or coloured GREEN or GREEN-AND-YELLOW.

The wire which is coloured BLUE must be connected to the terminal in the plug

which is marked with the letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal in the

plug which is marked with the letter L or coloured RED.

How to replace the fuse: Open the fuse compartment with a screwdriver and

replace the fuse.

FOR USERS IN AUSTRALIA

This mark shows that the product complies with AS/NZS 3548.

vi General

Contents

For Your Safety

General

Power source i

Laser safety i

Ozone release ii

Moving the unit ii

Caution labels iii

FOR USERS IN U.K. iv

FOR USERS IN AUSTRALIA v

Chapter 1: Before You Start

Cautions

1-1

CD-ROM 1-2

Static electricity damage 1-3

Interface cable 1-3

Waste disposal method 1-3

System requirements

1-4

With a Windows computer 1-4

With a Macintosh computer 1-4

Features of the Ci1000

1-5

High quality 1-5

High speed 1-5

Easy operation 1-5

Networking and client capabilities 1-5

Color capabilities 1-6

Color management 1-6

Fiery WebTools 1-7

Minimum space requirements

1-7

Power source

1-8

Unpacking

1-8

viii Contents

Part names

1-9

Front side view 1-9

Rear side view 1-9

Control panel overview

1-10

Activity Lights 1-10

Buttons 1-10

Chapter 2: Printer Setup

Setting up the printer

2-1

Preparing the imaging unit 2-1

Setting up the output tray 2-2

Installing the toner cartridges 2-3

Loading media 2-5

Connecting the printer to a computer 2-7

Using a parallel interface cable 2-8

Using the control panel

2-15

Status messages 2-15

Error messages 2-16

Top-level menus 2-16

Printing pages from the control panel 2-18

Chapter 3: Connecting the Printer to a Network

Network connections

3-1

Ethernet network connections 3-1

Token Ring network connections 3-3

Parallel cable connection

3-3

Setting up TCP/IP printing

3-4

Setting up the printing environment 3-5

UNIX server print queues 3-5

Verifying theTCP/IP network connection 3-9

Setting upTCP/IP clients for printing 3-10

Setting upTCP/IP clients for running Fiery WebTools 3-11

Printing and administering print jobs 3-11

Otros manuales para Ci1000
